A.H. Systems SAS-585 Standard Gain Horn Antenna
SAS-585
Standard Gain Horn
Operation Manual
© A.H. Systems inc. – June 2014
1
REV A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAS-585 and is the answer not in the manual?

Questions and answers

Summary of Contents for A.H. Systems SAS-585

  • Page 1 A.H. Systems SAS-585 Standard Gain Horn Antenna SAS-585 Standard Gain Horn Operation Manual © A.H. Systems inc. – June 2014 REV A...
  • Page 2: Table Of Contents

    A.H. Systems SAS-585 Standard Gain Horn Antenna TABLE OF CONTENTS INTRODUCTION Introduction ........................ 3 Intended Purposes ...................... 4 Optional Equipment ....................5 OPERATING INSTRUCTIONS Assembly Instructions ....................6 Mounting Instructions ....................6 Operating Instructions ....................6 SPECIFICATIONS Specifications ......................8 Typical Data ........................
  • Page 3: Introduction

    A.H. Systems SAS-585 Standard Gain Horn Antenna INTRODUCTION The SAS-585 Standard Gain Horn Antenna is designed specifically for utilization in emissions and immunity testing over the frequency range of 8.2 GHz to 12.4 GHz. X-band This horn antenna is linearly polarized and has medium gain, low VSWR, and a constant antenna factor.
  • Page 4: Intended Purposes

    A.H. Systems SAS-585 Standard Gain Horn Antenna INTENDED PURPOSES The standard gain horn antenna is intended for general laboratory use in a wide variety of industrial and scientific applications. It has been designed to be used in the process of generating, controlling and measuring high levels of electromagnetic Radio Frequency (RF) energy.
  • Page 5: Optional Equipment

    A.H. Systems SAS-585 Standard Gain Horn Antenna OPTIONAL EQUIPMENT The following is a recommend accessory list for the SAS-585 Standard Gain Horn Antenna: CONNECTING ACCESSORIES: PAM-0118 This preamplifier has a broad frequency range and high gain, designed to match the double ridge guide horn antenna. An ideal solution for improving overall system sensitivity.
  • Page 6: Assembly Instructions

    A.H. Systems SAS-585 Standard Gain Horn Antenna OPERATING INSTRUCTIONS ASSEMBLY INSTRUCTIONS There is no assembly required, the SAS-585 Horn antenna is supplied with an attached waveguide to coax adapter and tripod mount. MOUNTING INSTRUCTIONS The antenna should be firmly mounted to a tripod with a 1/4-20 male stud.
  • Page 7 A.H. Systems SAS-585 Standard Gain Horn Antenna OPERATING INSTRUCTIONS Once the antenna is mounted to a mast or tripod, connect a N-type coaxial cable from the horn antenna to a receiver or RF generator. The cable should be matched to 50 ohms, and it is recommended to use a high-frequency low-loss cable (i.e., SAC-18G-3 Low Loss cable).
  • Page 8: Specifications

    A.H. Systems SAS-585 Standard Gain Horn Antenna SPECIFICATIONS The SAS-585 Horn Antenna specifications: ELECTRICAL Frequency Range ..............8.2 GHz – 12.4 GHz Antenna Factor ..................34.6 dB/m Average Gain ....................15.6 dBi Maximum Continuous Power ..............250 Watts Maximum Radiated Field: ................500 V/m Average Beamwidth (E-Field) ................
  • Page 9: Typical Data

    A.H. Systems SAS-585 Standard Gain Horn Antenna TYPICAL DATA © A.H. Systems inc. – June 2014 REV A...
  • Page 10: Calculations

    CALCULATIONS EMISSIONS TESTING Individual calibration data for the SAS-585 horn antenna is supplied at a 1-meter separation distance. For emissions measurements, add the antenna factor plus cable loss to receiver reading in dBV to convert to field strength in dBV/meter.
  • Page 11 A.H. Systems SAS-585 Standard Gain Horn Antenna TYPICAL CONVERSION FORMULAS LOG -> LINEAR VOLTAGE FIELD STRENGTH & POWER DENSITY ((dB  V – 120) / 20) (((dB  V/m) -120) / 20) dBV to Volts V = 10 dBV/m to V/m V/m = 10 Volts to dBV...
  • Page 12: Maintenance

    At least once a month it is a good idea to wipe down the antenna with a damp rag. ANNUAL CALIBRATION To ensure reliable and repeatable long-term performance, annual re-calibration of your antennas, preamplifiers and current probes by A.H. Systems experienced technicians is recommended. Our staff can calibrate almost any type or brand of antenna.
  • Page 13: Warranty

    A.H. Systems SAS-585 Standard Gain Horn Antenna WARRANTY INFORMATION A.H. Systems Inc., warrants that our Antennas, Sensors and Probes will be free from defects in materials and workmanship for a period of three (3) years. All other products delivered under contract will be warranted for a period of two (2) years. Damage caused by excessive signals at the product's input is not covered under the warranty.
