- Page 1 OPERATOR’S MANUAL & PARTS LIST MULTI-drill MODEL ND-120 FIRST PRODUCTS INC. 164 Oakridge Church Road Tifton, Georgia 31794 U.S.A. Phone (229) 382-4768 1-800-363-8780 Fax (229) 382-0506 ND-120 SER. 1004 thru ___ Web: Email: www.1stproducts.com Sales@1stproducts.com Printed in U.S.A. PBREV 0623...
-
Page 2: Introduction
INTRODUCTION Thank you for purchasing a First Products Multi-Drill. This piece of equipment has been carefully engineered and manufactured to provide years of reliable service. The Multi-Drill is one of the most unique and versatile pieces of equipment on the market today. -
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ........1 CLEANING ..........17 TABLE OF CONTENTS ......2 After Each Use ........17 GENERAL INFORMATION ..... 3 Periodic or Before Extended Storage ..17 SPECIFICATIONS for ND-144 ....3 WARRANTY INFORMATION ....18 SAFETY SYMBOLS........4 Parts Book .......... -
Page 4: General Information
GENERAL INFORMATION The purpose of this manual is to assist you in operating and maintaining your Multi-Drill. Read it carefully. It furnishes information and istructions that will help you achieve years of dependable performance. These instructions have been compiled from extensive field experience and engineering data. -
Page 5: Safety Symbols
SAFETY SYMBOLS ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! This is a standard safety alert symbol meaning CAUTION Indicates hazardous situation, injury occur, used to alert against carelessness. WARNING Indicates potentially hazardous situation. Death or serious injury may occur if proper procedures are not followed. -
Page 6: Safety Rules
SAFETY RULES Safety is a primary concern in the design and manufacturing of our products. However, our efforts to provide safe equipment can be avoided by an operator’s careless act. Accident prevention ultimately is dependent upon the awareness, concern, judgement, and proper training of the personnel involved in the operation, transport, maintenance, and storage of the equipment. -
Page 7: Transportation
Securely fasten seat belt, place transmission Always raise unit and install transport lock in neutral, engage brake, and ensure all other before transporting. Leak down or failure of controls are disengaged before starting mechanical or hydraulic systems can cause power unit engine. equipment to drop. -
Page 8: Storage
pins are installed securely to ensure Storage equipment is in a safe condition before Block equipment securely for storage. putting unit into service. Cover with tarp included with seeder. Make sure all safety decals are installed. Keep children and bystanders away from Replace if damaged. - Page 9 2 – Operator Warning (DS50-068) 1 – General Warning (DS50-067) 3 – No Riders (AG50-089) 4 – Hydraulic Pressure (AE50-194) 8 ...
-
Page 10: Operation
OPERATION The operator is responsible for the safe operation of this seeder. The operator must be properly trained. Operators should be familiar with the equipment, the tractor, and all safety practices before starting operation. Read the safety rules and safety decals provided in this operator’s manual. -
Page 11: Front Coulter Disc Shaft
Front Coulter Disc Shaft The Multi-Drill is equipped with a coulter disc shaft mounted to the front of the frame. The function of this shaft is to cut a narrow slit in the ground in preparation for the seed delivery to follow. The cutting depth of the shaft is manipulated using the gauge wheels on the sides of the frame. -
Page 12: Attaching Multi-Drill
which are specified in the calibration instructions. A handheld control harness tethered to the seeders opens and closes the seed openings using a cutoff plate. When the seeder is energized, an electric actuator opens the bottom of the seeder exposing the outlets while a hydraulic motor powers an agitator ... -
Page 13: Seeder Setup
Seeder Setup The Multi-Drill is capable of planting a wide variety of seeds over a wide range of seeding rates. Several variables have to be taken into account when planting: seed depth, ground speed, and seed rate. These all have to come together in order to achieve the optimum stand desired. -
Page 14: Setting Seed Depth
3. Check seed depth and adjust Setting Seed Depth Once the frame is level and the desired After hitching Multi-drill and making all depth of cut is obtained, a short pass can be necessary connections (see previous made operating the seeder at the desired sections), the seed depth must be set before speed (wait until seeder calibration is done seed calibration is addressed. -
Page 15: Seeder Calibration
starting position, and choosing the agitator shaft Seeder Calibration speed. Before operating the seeder, calibration has to be done in order to take all variables into If the Quick Start Setting Guide is not helpful for account and maximize efficiency of the selecting a seed plate, below is a list of common seeder. - Page 16 The seed should flow through this process. Don’t fill hopper until calibration is complete. Figure 13. ND-120 Calibration Chart used for Step 4 15 ...
- Page 17 Changing Seed Plates The seed plates are strategically positioned between the hopper’s outlet holes (seen when the hopper is empty) and the “cutoff plate” which the linear actuator shuttles back and forth to start and stop seed flow. Each set of plates are labeled with laser etching on one side: “left”, “right”, and their respective sizes.
-
Page 18: Cleaning
Remove large debris such as clumps of dirt, Sand down scratches and the edges of area of grass, crop residue, etc. from machine. missing parts and coat with First Products spray Inspect machine and replace worn or damaged paint of matching color. -
Page 19: Warranty Information
WARRANTY INFORMATION ONE YEAR LIMITED WARRANTY FIRST PRODUCTS INC. WARRANTS THIS PRODUCT TO BE FREE OF DEFECTS IN MATERIALS AND WORKMANSHIP FOR A PERIOD OF TWELVE MONTHS FROM THE ORIGINAL DELIVERY DATE. THIS WARRANTY DOES NOT COVER PARTS CAUSED TO BE DEFICIENT DUE TO NORMAL WEAR, MISUSE, ACCIDENTS, OR LACK OF PROPER MAINTENANCE. - Page 21 FIRST PRODUCTS INC. CUSTOMER’S RECORD WARRANTY REGISTRATION CARD MODEL NUMBER______________ WARRANTY VOID IF THIS CARD IS NOT ON FILE AT FIRST PRODUCTS INC. SERIAL NUMBER______________ DATE OF SALE___________________________________________________ DATE PURCHASED____________ MODEL NUMBER___________________SERIAL NUMBER____________ CUSTOMBER INFORMATION NAME__________________________________________________________ FIRST PRODUCTS INC. ADDRESS_______________________________________________________...
- Page 68 BOLT TORQUE SPECIFICATIONS GRADE 2 GRADE 5 GRADE 8 DIAMETER THD/INCH 37 IN-LBS 86 IN-LBS 122 IN-LBS 5/16 11 FT-LBS 26 FT-LBS 37 FT-LBS 7/16 9/16 1 1/4 1545 1 1/2 1657 2688 42 IN-LBS 99 IN-LBS 139 IN-LBS 5/16 13 FT-LBS 30 FT-LBS 42 FT-LBS...
