Thank you for purchasing a Shelti product. All of us at Shelti want you to be completely satis ed with
your Pro Foos game, so feel free to contact us for help with the assembly of your product, Shelti parts,
or other information you may require.
Tools Required:
1/2" Wrench
3/4" Wrench
Hammer
Phillips screwdriver
Level
STEP #1
Remove the following parts from the Pro Foos II accessory box.
Description
Shelti Soccer Leg Assembly
Goalie Rod Assembly
5 - Man Rod Assembly
3 - Man Rod Assembly
2 - Man Rod Assembly
C - Accessories Bag
C - Assembly Instructions
Shelti Rubber Bumper
Shelti Soccer Man Red
Shelti Soccer Man Black
Spirol Pin
5/16" Flat Washer
5/16" Hex Nuts
Score Posts
Score Rods
Red Score Beads
Black Score Beads
#8 x 2" Wood Screw
Spirol Pin Punch
Super Lube Tube
Balls
Rod Block
Assembly Instructions
Part Number
CS-SSL-0
CS-GRA-0
CS-5RA-0
CS-3RA-0
CS-2RA-0
CS-ASA-0
210-0001-0
203-0001-0
201-0001-0
201-0005-0
205-0006-0
303-0002-0
302-0002-0
201-0006-0
205-0007-0
003-0002-0
003-0003-0
304-0005-0
210-0012-0
210-0002-0
201-0007-0
102-0070-0
CS-B-FM
Quantity
4
2
2
2
2
1
1
16
13
13
26
8
8
4
2
5
5
4
1
1
3
1
Advertisement
Related Manuals for Shelti Pro Foos II
Summary of Contents for Shelti Pro Foos II
- Page 1 Assembly Instructions Thank you for purchasing a Shelti product. All of us at Shelti want you to be completely satis ed with your Pro Foos game, so feel free to contact us for help with the assembly of your product, Shelti parts, or other information you may require.
- Page 2 STEP #2 – Leg Assembly Carefully lay the table upside down on a cushioned surface (carpeting, blanket, etc.) to prevent damaging the cabinet laminate. Assemble the legs using the holes in the leg pads. Tighten nuts with a 1/2" wrench. For Installing Optional Commercial Duty 3½"...
- Page 3 STEP #3 – Rods, Bumper And Men Assembly • Once the table legs are secure, (using two people) pick the table up and turn it over onto its legs. • Locate the five man rods… These two rods will be located in the center of the game as illustrated below.
- Page 4 STEP #4 – Score Post & Rod Assembly • Assemble the score posts - score rod - beads. • Screw the score posts to the top of the game. • The black scoring assembly contains 4 black beads and 1 red bead and should be placed at the end of the table where the black goalies are located.
- Page 5 STEP #6 – Lubricate The Rods / Bearings • Push the rod away from you until the bumper hits the opposite wall. Apply two or three drops of lubricate on the face of the bearing and rod using the Super Lube Tube furnished with the game. Rotate the rod while pulling the rod toward you to evenly spread the lubricant on the rod.
