Device Information - Smartbox Grid Pad 15 HeadMouse Nano Installation Manual

6

Device information

Product name
HeadMouse Nano and mount
Description
The HeadMouse Nano is an infrared optical sensor that tracks
side-to-side and up-and-down head movements. It then filters
and transforms these movements to control the mouse pointer
position on the screen of a computer, tablet or communication
device.
The HeadMouse Nano uses infrared light to track a tiny reflective
dot that is placed on the user's forehead or glasses.
Switches can be connected directly to HeadMouse Nano through
a 3.5 mm stereo jack located next to the USB connector.
Technical specification
Operating wave band:
Power consumption:
Field of view:
Measurement rate:
USB interface:
14
Grid Pad 15 headmouse nano - guide - D - UK.indd 14 Grid Pad 15 headmouse nano - guide - D - UK.indd 14
Near Infrared
1/2 watt (typical)
72 degree by 45 degree
80Hz
Full speed
