- Page 1 Technical Service Manual (Including Parts and Exploded Views) Electric Cooktops 15 Inch 30 Inch 36 Inch © WOLF APPLIANCE, INC. 2008 ALL RIGHTS RESERVED Job Aid #802986 Revision E - 2008...
- Page 3 General Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s SECTION 1 GENERAL INFORMATION...
-
Page 4: Introduction
Technicians. The information and images are the copyright property of Wolf Appliance, Inc., an affiliate of Sub-Zero, Inc. Neither this manual nor any information or images contained herein may be copied or used in whole or in part without the express written permission of Wolf Appliance, Inc., an affiliate of Sub-Zero, Inc. -
Page 5: Table Of Contents
General Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s TABLE OF CONTENTS Page # Page # Section 1 - General Information Section 5 -Troubleshooting Guide (Continued) Introduction................. -
Page 6: Warranty Information
E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s WARRANTY INFORMATION This page contains a summary of the 2 & 5 Year Warranty that is supplied with every Wolf product, fol- lowed by details and notes about the warranties. Wolf Appliance Company, LLC TWO &... -
Page 7: Model Number Key
General Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s MODEL NUMBER KEY Refer to this key for an example of the model numbers. Model: CT 36 E / S Product Type... -
Page 8: Model Configurations
E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s MODEL CONFIGURATIONS 15” Electric Model Numbers Descriptions CT15E/S Cooktop 15” Electric Stainless Steel Trim • Two heating elements with three zones • Dual element 2200W outer / 750W inner •... -
Page 9: Model Features
General Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s MODEL FEATURES • Ribbon-type radiant heating elements in various sizes. •... - Page 10 Gerneral Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s...
-
Page 11: Section 2 - Installation Information
Installation Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s SECTION 2 INSTALLATION INFORMATION... -
Page 12: Electrical Requirements
This section of the manual covers some of the installation issues a service technician may need to know when serv- icing a Wolf Electric Cooktop. If additional information is needed after reviewing this section of the manual, please refer to the Installation Guide or contact the Wolf Appliance Customer Service Department. -
Page 13: Pre-Installation Specifications
Installation Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s PRE-INSTALLATION SPECIFICATIONS Countertop Location Dimension Description A Minimum flat countertop surface. -
Page 14: Installation Dimensions
Installation Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s INSTALLATION DIMENSIONS - Top Mount 4" "* (10.2) Models: CT15E - CT30E - CT30EU - CT36E - CT36EU... -
Page 15: Installation Procedures
Installation Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s INSTALLATION PROCEDURE cooktop • Insert cooktop into countertop opening and center cooktop. - Page 16 Installation Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s INSTALLATION DIMENSIONS - CT30EU FLUSHMOUNT R 1- 5/16" * 30 1/8"...
- Page 17 Installation Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s INSTALLATION DIMENSIONS - CT36EU FLUSHMOUNT 36 1/8" * R 1- 5/16"...
- Page 18 Installation Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s FLUSHMOUNT INSTALLATION INSTRUCTIONS - CT30EU & CT36EU Be sure to follow counter top manufacturers recommendations for cutting the countertop surface.
-
Page 19: Filler Strip Installation Procedure
Installation Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s FILLER STRIP INSTALLATION PROCEDURE These instructions contain procedural information to install the Integrated Filler Strip Kit into countertop installations. 1. -
Page 20: Support Kit For Downdraft Installation Procedure
Installation Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s SUPPORT KIT FOR DOWNDRAFT INSTALLATION PROCEDURE These instructions contain procedural information to install the Integrated Cooktop Support Kit for downdraft ventilation installations. -
Page 21: Section 3 - Operation Information
Operation Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s SECTION 3 OPERATION INFORMATION... -
Page 22: Control Operation
E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s ELECTRIC COOKTOP OPERATION Control Operation The Wolf electric glass ceramic cooktop operates by automatically cycling the heating elements between zero power and full power. As the heat is increased on... -
Page 23: Single Element Operation
Operation Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s Single Element Operation To activate a heating element, you must first touch the corresponding "OFF ON" area of the desired element. The power indicator bar graph will begin to blink and show a half power status. -
Page 24: Cookware Selection
Operation Information E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s COOKWARE SELECTION Although cooktops equipped with glass ceramic surfaces do not require special pots and pans, cookware will affect the overall efficiency of the system. -
Page 25: Section 4 - Component Access And Removal
Component Access and Removal E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s SECTION 4 COMPONENT ACCESS AND REMOVAL... -
Page 26: Warnings And Cautions
COMPONENT ACCESS AND REMOVAL This section explains how to access and remove components from a Wolf electric cooktop. Depending on which component you are going to access or remove in the following sections, you may have to remove some components first. -
Page 27: Flushmount Installation Removal
Component Access and Removal E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s Flushmount Installation Removal The following instructions are for Models CT30EU and CT36EU installed in a flushmount application only. Access to the underside of the unit is required. -
Page 28: Glass Top
Component Access and Removal E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s Glass Top Assembly Removal The cooktop will have to be removed from its installa- tion in order to remove the glass top assembly. -
Page 29: Power Board
Component Access and Removal E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s Power Board Removal First, the glass top assembly, surface units, insulation and inner burner box need to be removed. - Page 30 Component Access and Removal E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s...
-
Page 31: Section 5 -Troubleshooting Guide
Troubleshooting Guide E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s SECTION 5 TROUBLESHOOTING GUIDE... -
Page 32: Mode 4 Checking The Ambient Temperature Of Thermistor On Power Board
Troubleshooting Guide E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s DIAGNOSTIC MODE - NOTE: Diagnostic Mode is not available in the 30” Model at time of print. Diagnostic mode allows the Service Technician to inspect the functions of the cooktop controls. -
Page 33: Mode 5 Checking Heat Sink Thermistor On Power Board
Troubleshooting Guide E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s Mode 5 - Checking Heat Sink Thermistor on Power Board To enter Mode 5 while engaged in diagnostic mode, touch the “+”... -
Page 34: Interpreting Hex Decimal Code
Troubleshooting Guide E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s INTERPRETING HEX DECIMAL CODE The bar lights located on the control panel are divided into four different groups. -
Page 35: Temperature °C / Hex Decimal Chart
Troubleshooting Guide E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s Temperature °C / Hex Decimal Chart 10.1 28.7 40.7... -
Page 36: Possible Error Codes
Troubleshooting Guide E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s POSSIBLE ERROR CODES Error 1: Ambient Temperature High The ambient temperature read by the control exceeds the ERROR TEMPERATURE limit (85°C + x) specified in EEPROM, or the temperature sensor input has failed. -
Page 37: Troubleshooting Guide
TROUBLESHOOTING GUIDE This section of the manual contains the Troubleshooting Guide which will help the Service Technician troubleshoot a Wolf Electric Cooktop. How to Use the Troubleshooting Guide The troubleshooting guide table of contents shows how the troubleshooting guide is laid out. The troubleshooting guide is organized into component areas with the most common problems listed first. -
Page 38: A.glass Top Assembly
Troubleshooting Guide E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s PROBLEM POSSIBLE CAUSE TEST / ACTION A. -
Page 39: Cooling Fan Does Not Come On
Troubleshooting Guide E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s PROBLEM POSSIBLE CAUSE TEST / ACTION H. - Page 40 Troubleshooting Guide E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s PROBLEM POSSIBLE CAUSE TEST / ACTION S.
-
Page 41: Section 6 - Technical Data
Technical Data E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s SECTION 6 TECHNICAL DATA... -
Page 42: Wattage / Ohm Data Chart
Technical Data E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s Wattage / Ohm Data Chart Units Full Wattage Simmer Wattage Melt Wattage... -
Page 43: Section 7 - Wiring Diagrams
Wiring Diagrams E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s SECTION 7 WIRING DIAGRAMS... - Page 44 Wiring Diagrams E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s 15" Electric Cooktop WHITE PURPLE 2200W 700W PURPLE PURPLE...
- Page 45 Wiring Diagrams E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s...
- Page 46 Wiring Diagrams E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s...
- Page 47 Parts List & Exploded Views E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s SECTION 8 PARTS LIST WITH EXPLODED VIEWS...
-
Page 48: Ct15E Parts Lis
E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s Parts List & Exploded Views CT15E PARTS LIST Ref # Part # Description... -
Page 49: Ct15E Exploded View
Parts List & Exploded Views E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s CT15E EXPLODED VIEW... -
Page 50: Ct30E Parts List
E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s Parts List & Exploded Views CT30E PARTS LIST Ref # Part # Description... -
Page 51: Ct30E Exploded View
Parts List & Exploded Views E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s CT30E EXPLODED VIEW... -
Page 52: Ct36E Parts Lis
E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s Parts List & Exploded Views CT36E PARTS LIST Ref # Part # Description... -
Page 53: Ct36E Exploded View
Parts List & Exploded Views E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s CT36E EXPLODED VIEW... -
Page 54: Ct30Eu Parts List
E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s Parts List & Exploded Views CT30EU PARTS LIST Ref # Part # Description... - Page 55 Parts List & Exploded Views E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s CT30EU PARTS LIST...
-
Page 56: Ct36Eu Parts List
E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s Parts List & Exploded Views CT36EU PARTS LIST Ref # Part # Description... - Page 57 Parts List & Exploded Views E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s CT36EU PARTS LIST 8-11...
- Page 58 E E l l e e c c t t r r i i c c C C o o o o k k t t o o p p s s Parts List & Exploded Views 8-12...
