ASLE-70-10D

Attenuation

Range / Resolution
0 to 40dB / 0.5dB
Setup Procedures
① Press [Atten] key to setup attenuation. The pointer [▶] appears as shown in
[Figure 4-11].
② Press numeric values of attenuation (valid range: 0 to 40dB, 0.5dB steps). If
attenuation step is greater than 0.5dB, it is not necessary to press the [.] key.
☞ [Figure 4-12] is an example for 5.5dB.
ㆍ Press the [ESC] key to edit numeric values of attenuation.
☞ The Attenuation field changes to blank as shown in [Figure 4-13].
[Figure 4-11]
[Figure 4-12]
[Figure 4-13]
