User Manual

SP24 AXPERT MAX 8KW TWIN

SOLAR INVERTER / CHARGER

Version: 1.0

Table of Contents

Need help?

Do you have a question about the SP24 and is the answer not in the manual?

Questions and answers

Summary of Contents for SolarPower24 SP24

Page 1 User Manual SP24 AXPERT MAX 8KW TWIN SOLAR INVERTER / CHARGER Version: 1.0...
Page 2: Table Of Contents
Table of Contents ABOUT THIS MANUAL ............................2 Purpose ................................2 Scope ................................2 SAFETY INSTRUCTIONS ........................... 2 INTRODUCTION ..............................4 Features ................................4 Basic System Architecture ..........................4 Product Overview ............................. 5 INSTALLATION ..............................6 Unpacking and Inspection ..........................6 Preparation ..............................
Page 3 Appendix I: Parallel function .......................... 50 Appendix II: BMS Communication Installation ..................... 63 Appendix III: The Wi-Fi Operation Guide in Remote Panel ................. 70 Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 4: About This Manual
16. ATTENTION IN CASE OF MALFUNCTION OF THE PRODUCT PLEASE CONTACT US BY EMAIL AT assistenza@solarpower24.it WITH THE SERIAL NUMBER OF PRODUCT, EXACT MODEL, Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 5 NOT BE OPENED IN ANY WAY AND THAT OPENING WITH THE CONSEQUENT BREAKING OF THE WARRANTY SEAL VOIDS WARRANTY ON THE PRODUCT. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 6: Introduction
This inverter can power various appliances in home or office environment, including motor-type appliances such as tube light, fan, refrigerator and air conditioners. Figure 1 Basic hybrid PV System Overview Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 7: Product Overview
19. RGB LED bar (refer to LCD Setting section for the details) Port 20. 12V DC output connectors Current sharing port 21. Power switch for DC output Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 8: Installation
SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-COMBUSTIBLE SURFACE ONLY. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 9: Battery Connection
5 Nm. Make sure polarity at both the battery and the inverter/charge is correctly connected and ring terminals are tightly screwed to the battery terminals. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 10: Ac Input/Output Connection
4. Insert AC input wires according to polarities indicated on terminal block and tighten the terminal screws. Be sure to connect PE protective conductor ( ) first. →Ground (yellow-green) L→LINE (brown or black) N→Neutral (blue) Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 11 Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 12: Pv Connection
Insert assembled cable into male connector housing as shown below. Then, use spanner to screw pressure dome tightly to female connector and male connector as shown below. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 13 7pcs in series, 2 strings 28pcs 7000W 8pcs in series, 2 strings 8pcs in series, 2 strings 32pcs 8000W Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 14 7pcs in series 7pcs 3885W 7pcs in series 7pcs 3885W 7pcs in series 7pcs in series 14pcs 7770W Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 15: Final Assembly
Step 1. Remove the screw on the bottom of LCD module and pull down the module from the case. Detach the cable from the original communication port. Be sure to replace the retention plate back to the inverter. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 16: Dc Output Connectors
CD and follow the on-screen instructions to complete your installation. For detailed software operation, refer to the software user manual on the bundled CD. Wi-Fi Connection Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 17: Dry Contact Signal
It is recommended to purchase a special communication cable if you are connecting to Lithium-Ion battery banks. Please refer to Appendix II- BMS Communication Installation for details. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 18: Operation
Output is powered by battery in battery mode Status Solid On Battery is fully charged indicators Green Flashing Battery is charging. Solid On Fault mode Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 19: Lcd Display Icons
The ICON flashing that indicate the unit with AC output and setting Programs 60, 61 or 62 different to default setting. Battery Information Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 20 Indicates the DC/AC inverter circuit is working. Indicates unit alarm is disabled. Indicates USB disk is connected. Indicates timer setting or time display Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 21: Lcd Setting
Increment of each click is 10A. (Max. charging current = utility charging current + solar charging current) Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 22 If selected, programs of 02, 26, 27 and 29 will be automatically set up. No need for further setting. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 23 Restart enable Auto restart when over temperature occurs 50Hz (default) 60Hz Output frequency 220V 230V (default) Output voltage 240V Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 24 To configure charger source Utility will charge battery only priority when solar energy is not available. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 25 If selected, the display screen will stay at latest screen user finally switches. Backlight on (default) Backlight off Backlight control Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 26 AC output mode *This setting is only available when the inverter is in standby mode (Switch off). Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 27 58.4V Setting range is from 48.0V to 62.0V. Increment of each click is 0.1V. Battery equalization voltage Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 28 If selected, battery discharge Disable (Default) protection is disabled. Maximum battery discharging current Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 29 LED lighting function. Normal (default) Brightness of RGB LED High Normal (default) Lighting speed of RGB LED High Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 30 28. program 61 and the program 60 function is not triggered, the output will be turned off. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 31 30 minutes 60 minutes For minute setting, the range is from 0 to 59. Time setting – Minute Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 32 This function is to upgrade inverter firmware. If firmware upgrade is needed, please check with Upgrade your dealer or installer for detail instructions. firmware Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 33 ” button to select “No” to return to main screen.  If no button is pressed for 1 minute, it will automatically return to main screen. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 34 Step 2: Press “ ”, “ ” or “ ” button to enter the selectable programs (detail descriptions in Step 3). Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 35: Lcd Display
Input Voltage=230V, output voltage=230V Input voltage/Output voltage (Default Display Screen) Input frequency=50Hz Input frequency PV1 voltage=260V PV voltage Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 36 PV1 current = 2.5A PV current PV2 current = 2.5A PV1 power = 500W PV power PV2 power = 500W Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 37 AC and PV charging power=500W PV charging power=500W Charging power AC charging power=500W Battery voltage=25.5V, output voltage=230V Battery voltage and output voltage Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 38 Load in Watt When load is larger than 1kW (≧1KW), load in W will present x.xkW like below chart. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 39 This PV year energy = 3.88MWh, Load year energy = 9.88MWh. PV energy generated this year and Load output energy this year. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 40 Main CPU version checking. Secondary CPU version 00012.03. Secondary CPU version checking. Secondary Wi-Fi version 00000.24. Secondary Wi-Fi version checking. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 41: Operating Mode Description
It will Line Mode Charging by utility. also charge the battery at line mode. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 42 The unit will provide output available. Battery Mode power from battery and/or PV power. Power from battery only. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 43: Faults Reference Code
Inverter soft start failed Over DC voltage in AC output Current sensor failed Output voltage is too low Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 44: Warning Indicator
BUS soft start Communication failure between None inverter and remote display panel Battery equalization None Battery is not connected None Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 45: Battery Equalization
If battery voltage is still lower than battery equalization voltage when battery equalized timeout setting is over, the charge controller will stop equalization and return to float stage. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 46 Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 47: Specifications
20ms typical (Appliances) Output power de-rating: When AC input voltage under 170V the output power will be de-rated. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 48 DC Voltage Accuracy +/-0.3V@ no load THDV <5% for linear load,<10% for non-linear load @ nominal voltage DC Offset ≦100mV Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 49 90Vdc~450Vdc Max. Input Current 27A x 2 (MAX 40A) Max. Charging Current 120A Start-up Voltage 80V +/- 5Vdc Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 50 Transfer time in parallel mode Max 50ms Parallel Kit Note: Parallel feature will be disabled when only PV power is available. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 51 Bus voltage is too low. happens again, please return to repair center. Fault code 55 Output voltage is unbalanced. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 52 CAUTION!! Please install the breaker at the battery and AC input side. This will ensure the inverter can be securely disconnected during maintenance and fully protected from over current of battery or AC input. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 53 WARNING! Be sure that all inverters will share the same battery bank. Otherwise, the inverters will transfer to fault mode. 4-1. Parallel Operation in Single phase Two inverters in parallel: Power Connection Communication Connection Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 54 Three inverters in parallel: Power Connection Communication Connection Four inverters in parallel: Power Connection Communication Connection Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 55 Five inverters in parallel: Power Connection Communication Connection Six inverters in parallel: Power Connection Communication Connection Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 56 Communication Connection Four inverters in one phase and one inverter for the other two phases: Power Connection Communication Connection Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 57 Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 58 Three inverters in one phase and only one inverter for the remaining two phases: Power Connection Communication Connection Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 59 Communication Connection Two inverters in one phase and only one inverter for the remaining phases: Power Connection Communication Connection Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 60 5. PV Connection Please refer to user manual of single unit for PV Connection. CAUTION: Each inverter should connect to PV modules separately. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 61 Do NOT connect share current cable between units on different phases. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 62 Step 4: Switch on all AC breakers of Line wires in AC input. It’s better to have all inverters connect to utility at Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 63 Note 2: Transfer time for this operation exists. Power interruption may happen to critical devices, which cannot bear transfer time. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 64 For upporting three-phase system, make sure no “PAL” is set on #28. If the problem remains, please contact your installer. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 65 ID switch. From number 0 to 9, the number can be random; no particular order. Maximum 10 battery modules can be operated in parallel. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 66 Step 1: Use supplied RJ11 signal cable to connect into the extension port ( P1 or P2 ). Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 67 *If the manual button cannot be approached, just simply turn on the inverter module. The battery module will be automatically turned on. Step 5: Turn on the inverter. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 68 Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 69 Lithium battery. Simply set this inverter battery type to “PYL” in LCD program 5. Others should be “USE”. Step 2. Switch on Lithium battery. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 70 LCD display Battery pack numbers & Battery Battery pack numbers = 3, battery group numbers = 1 group numbers Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 71 71 to stop discharging battery. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 72 “Register” to access “User Registration” page. Fill in all required information and scan the remote box PN by tapping icon. Or you can simply enter PN directly. Then, tap “Register” button. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 73 Wi-Fi PN number and enter default password “12345678”. Then, return to WatchPower APP and tap “ ” button when Wi-Fi module is connected successfully. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 74 It will show repair suggestion. Please follow it to fix the problem. Then, repeat the steps in the chapter 4.2 to re-set network setting. After all setting, tap “Rediagnosis” to re-connect again. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 75 After login is successfully, you can access “Overview” page to have overview of your monitoring devices, including overall operation situation and Energy information for Current power and Today power as below diagram. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 76 For more information about Device List, please refer to the section 2.4. In ME page, users can modify “My information”, including【User’s Photo】,【Account security】, 【Modify password】,【Clear cache】,and【Log-out】, shown as below diagrams. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 77 【Line Mode】Inverter will power the load from the utility with or without PV charging. Qualified utility or PV source can charge battery. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it...
Page 78 Device Information Data Users can check up 【Basic Information】,【Product Information】,【Rated information】,【History】, and 【Wi-Fi Module Information】by swiping left. Swipe left Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 79 Please see product manual for the recommended voltage or SOC range based on connected battery type. Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 80 Battery Cut off To set the battery stop discharging voltage or SOC on L2 output. output) setting Voltage/SOC L2 Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
Page 81 Adjust color combination to show energy source an battery status Restore to the This function is to restore all settings back to default settings. default Solarpower24.it by Barba S.r.l. – via Locchi, 3F – 47122-Forlì – Italia Tel/What’s up +39 05431995799 – web www.solarpower24.it – email solarpower24@solarpower24.it...
