Summary of Contents for Shomar P873MDBI
- Page 1 Built In Fridge Freezer P873MDBI INSTRUCTIONS: Please read and keep safe for future use.
- Page 2 Installation and User Instructions Features…………………………….……………………………………………………………….. Transportation Instructions..............Introduction & Safety Warnings............Electrical Requirements …………………............Installation / Door Reversal……………………………………………………………….. Food Storage……………………………............Defrosting..................... Arrangement of Food……………….………………………………………………………… Temperature Control ....……………………………......Cleaning and care ……………………..………………….……………………….…………… Replacing the interior light bulb/Top Tips………………………….………………… Problem Solving..................Health and Safety..................Warranty Information................
- Page 3 Features...
- Page 4 Transportation of your Appliance • When transporting, never tilt the appliance to more than 45 degrees. • The appliance should be transported only in a vertical upright position • The packaging as supplied must be intact during transportation • If during the course of transport the appliance has to be transported horizontally, it must only be laid on its left hand side when standing in front of the appliance.
-
Page 5: Before First Use
Before First Use IMPORTANT! DO NOT connect your appliance to the electricity supply until all Packing and transit protectors have been removed. • Leave to stand for at least 4 hours before switching on to allow compressor oil to settle if transported horizontally •... -
Page 6: Important Warning
Should the mains lead of the appliance become damaged or should it need Replacing at any time, it must be replaced by a special purpose made mains Lead which can only be obtained from Shomar Ltd. WARNING! THIS APPLIANCE MUST BE EARTHED If the fitted plug is not suitable for your socket, then the plug should be removed and an appropriate plug fitted. -
Page 7: Installation Instructions
Installation Instructions 1. Install the refrigerator on a flat surface in order to prevent vibration and noise. 2. Choose a dry well-ventilated place. A space of no less than 10 cm must be left around the refrigerator. 3. The minimum space in the room where the refrigerator is being installed is 10 cubic metres. - Page 8 Minimum space underneath refrigerator 200 cm ² 8. Ensure that there is sufficient ventilation and that the cabinet is of adequate size. 9. Slowly and carefully push the appliance inside the cabinet. Push the appliance into the cabinet and adjust it to make sure the edge on the top baffle completely touches the top edge of the cabinet and the limit hook for the supporting leg completely touches the bottom edge of the cabinet.
- Page 9 Open the lower door of the cabinet to maximum angle than open the lower freezer door to the corresponding position. Slide the block into position and ensure inner edge aligns with the lower edge of the refrigerator door than fix the block door screw and cover with screw caps. Fix Upper refrigerator door to the cabinet door in the same way Take out Sealing Strip from accessory bag and press in the gap between the cabinet and the refrigerator.
-
Page 10: Door Reversal Instructions
Door Reversal instructions Tools Required Philips screwdriver Putty Knife Flathead screwdriver 5/16’’ socket & ratchet Masking Tape 1. Power off the appliance and remove all items from door trays 2. Remove the upper hinge and the hole cap 3. Remove the refrigerator door and bottom hinge and hole cover 4. - Page 11 6. Remove the upper hinge from the freezer door 7. Remove the freezer door , the bottom hinge and hole caps 8. Exchange the bottom front hinge and upper front hinge, then install them according to the steps below , and install the top hole cover and lower hole caps 9.
-
Page 12: Food Storage
Check the temperature with an accurate thermometer and wait 24 hours Before placing food in the fridge or freezer NOTE: If it is a requirement that the freezer door is to be reversed please contact our customer services department for further information (see contact details below) Food Storage How to Use the Refrigerator Compartment:... -
Page 13: Making Ice Cubes
Freezing Fresh Food: • Do not freeze too large a quantity at any one time. The quality of the food is best preserved when it is frozen right through as quickly as possible • Do not exceed the freezing capacity of your appliance in 24 h which is 4 kg (9 lb) •... -
Page 14: Defrosting The Freezer Compartment
Is maximum +5 degrees C [41 degrees F] once the ice build-up disappear And the appliance starts auto defrosting again as normal, then you may increase The thermostat setting, if required. DEFROSTINGTHE FREEZER COMPARTMENT Switch off the appliance and pull out the mains plug. Remove and wrap all food and store in a cool place, ideally another freezer. - Page 15 Arrangement of Food in the Fridge/Freezer The following are guidelines to obtain the best results: 1. The fridge compartment is for the short term storage of fresh food and drinks. 2. The freezer compartment is rated and suitable for the freezing and storage of pre frozen food.
-
Page 16: Temperature Control
Temperature Control Set Button Repeatedly press to change the set temperature between 2, 4, 6 and 8 degrees. The temperature set will be shown by the illuminated number above the button. The Fridge will start to operate at the new temperature after a 15 second delay. -
Page 17: Cleaning And Care
When the appliance is switched on for the first time, the setting should be Adjusted so that after 24 hours, the average fridge temperature is no higher Than +5 degrees Celsius. Some sections of the fridge may be cooler or warmer (such as the salad crisper and the top part of the cabinet) which is quite normal. -
Page 18: Replacing The Interior Light Bulb
If you are going away on holiday or for any other reason, wish to leave the refrigerator idle for any period of time, proceed as follows: • Disconnect the refrigerator from the electric power supply by removing the plug from the wall socket •... - Page 19 • Don't store bananas or melon in your fridge compartment • Don't store poisonous, flammable or dangerous substances in your appliance • Don't consume food which has been stored for an excessive time in the fridge • Don't leave the door open for long periods as this will make the appliance more costly to run and cause excessive ice formation •...
-
Page 20: Energy Saving Tips
That the plug is wired correctly if you have changed the fitted plug If the appliance is still not operating after the above checks, please contact Shomar Ltd, see contact details. Please ensure that the above checks have been made as a charge will be made If no fault is found. - Page 21 In high humidity the outer surface of the refrigerator may be covered with condensation that should simply be wiped away • The compressor and the rear condenser will become hot and should not be touched. If after checking all of the above and the problem persists contact the Shomar Service Department.
-
Page 22: Health And Safety
Health & Safety The use of any electrical appliance requires the following common sense safety rules. There is danger of injury or death and damage to the appliance. Location • This appliance is intended to be used in household and residential type environments. - Page 23 • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities Children • Children should be supervised to ensure that they do not play with this appliance • Teach children to be aware of dangers in the kitchen •...
-
Page 24: Warranty
28 days of purchase with the supplier Shomar Ltd. If you do not register the product with Shomar Ltd within 28 days, your product is guaranteed for 1 year. To validate your 2 year guarantee register with us by completing the online Form here. -
Page 25: Contact Details
Exclusions Shomar Ltd shall not be liable to replace or repair the goods under the terms of the guarantee where: 1. The fault has been caused or is attributable to accidental use, misuse, negligent use or used contrary to the manufacturer’s recommendations or where the fault has been caused by power surges or damage caused in transit.
