Retro Rocket
Aeration System
Installation Manual
This manual applies to:
GRS–7004 / GRS-7006
Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
Part Number: RNF-2666 R0
Revised: June 2023
Original Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Retro Rocket and is the answer not in the manual?

Questions and answers

Related Manuals for AGI Retro Rocket

Summary of Contents for AGI Retro Rocket

  • Page 1 Retro Rocket Aeration System Installation Manual This manual applies to: GRS–7004 / GRS-7006 Read this manual before using product. Failure to Part Number: RNF-2666 R0 follow instructions and safety precautions can Revised: June 2023 result in serious injury, death, or property Original Instructions damage.
  • Page 2 RETRO ROCKET – AERATION SYSTEM RNF-2666 R0...

  • Page 3: Table Of Contents

    3.5.1 Hopper Bins with Small Access Opening ..............8 3.5.2 Hopper Bins with Large Access Opening ..............10 3.6 Attach the Weatherstripping on the Panels ................11 3.7 Unfold the Retro Rocket ......................13 3.8 Attach the Retro Rocket......................15 3.9 Attach the Air Inlet ........................15 3.10 Attach the Duct Elbow ......................

  • Page 4: Introduction

    General Description The AGI Retro Rocket is an excellent addition to any new or existing hopper bottom bin that does not presently include an aeration system. It can allow you to harvest in damp conditions, maintain stored grain in peak condition, and reduce the likelihood of mould growth and insect infestations.

  • Page 5: Safety

    • Follow a health and safety program for your worksite. Contact your local occupational health and safety organization for information. • Contact your local representative or AGI if you need assistance or additional information. • Always follow applicable local codes and regulations.

  • Page 6: Safety Equipment

    2. SAFETY RETRO ROCKET – AERATION SYSTEM Safety Glasses • Wear safety glasses at all times to protect eyes from debris. Steel-Toe Boots • Wear steel-toe boots to protect feet from falling debris. Hard Hat • Wear a hard hat to help protect your head.

  • Page 7: Installation

    3.4. Location Requirements All models of the AGI Retro Rocket are designed to be installed in the center of hopper-bottom bins with the rocket center aligned with the center of hopper cone. To ensure structural integrity and proper airflow, the bin must be level and the rocket installed completely vertical.

  • Page 8: Methods Of Installation

    Review both methods and confirm which will work best for your application. Also note that with the right lifting equipment, the Retro Rocket could also be inserted into the bin through the filler cap or inspection hatch.
  • Page 9 RETRO ROCKET – AERATION SYSTEM 3. INSTALLATION Figure 1. Panels and Hinge Bolts Figure 2. Panels inside the Bin RNF-2666 R0...

  • Page 10: Hopper Bins With Large Access Opening

    3. INSTALLATION RETRO ROCKET – AERATION SYSTEM 3.5.2 Hopper Bins with Large Access Opening Required minimum opening: • Square: 18.5” • Round: 22” • Oval or rectangle: 16” x 19” 1. Attach a lifting cable onto the lugs located on the 2nd and 5th panels.

  • Page 11: Attach The Weatherstripping On The Panels

    RETRO ROCKET – AERATION SYSTEM 3. INSTALLATION Figure 4. Lifting Panels inside the Bin To prevent personal injury or damage to equipment: • Do not drop the panels • Use a winching device with minimum load rating of 700lbs 3.6. Attach the Weatherstripping on the Panels Note Weatherstripping can be applied prior to lifting rocket into the bin.
  • Page 12 3. INSTALLATION RETRO ROCKET – AERATION SYSTEM Figure 5. Weatherstripping Locations Figure 6. Weatherstripping RNF-2666 R0...

  • Page 13: Unfold The Retro Rocket

    RETRO ROCKET – AERATION SYSTEM 3. INSTALLATION 3.7. Unfold the Retro Rocket Below is a suggested sequence to unfold the rocket. Pinching Hazard • Hold swinging sections firmly to prevent loss of grip and to prevent panels closing together too quickly.
  • Page 14 3. INSTALLATION RETRO ROCKET – AERATION SYSTEM 4. Insert a 5/16” x 1” bolt through the top flanges (A) of panels 2 and 3. 5. Swing the panels 5 and 6 together until the edge surfaces of panels 4 and 5 are in contact.

  • Page 15: Attach The Retro Rocket

    RETRO ROCKET – AERATION SYSTEM 3. INSTALLATION 3.8. Attach the Retro Rocket 1. Orient the inlet opening towards the desired fan location. 2. Lower the rocket assembly while ensuring that it is centered over the discharge at the bottom cone and aligned vertically.

  • Page 16: Attach The Duct Elbow

    3. INSTALLATION RETRO ROCKET – AERATION SYSTEM 11. Ensure the straight duct is aligned with the cut hole. 12. Attach the straight duct to the air inlet using twelve #14 x 1” sheet metal screws (four on sides, two on top and bottom).
  • Page 17 RETRO ROCKET – AERATION SYSTEM 3. INSTALLATION Figure 9. Retro Rocket Hardware “Where Used” Illustration RNF-2666 R0...

  • Page 18: Specifications

    4. SPECIFICATIONS RETRO ROCKET – AERATION SYSTEM 4. Specifications Maximum Rocket Airflow Part Air Inlet Sidewall Dimensions Capacity Bin Size Size Height (outer/inner) (CFM) GRS- 1,500 to 5,000 5,000 30’ 9” x 14” 30”/20” 7004 GRS- 30’ up to 7,000 bu 7,000 9”...

  • Page 19: Appendix

    RETRO ROCKET – AERATION SYSTEM 5. APPENDIX 5. Appendix 5.1. Aeration System Parts List GRS-7004 Item Description Quantity Part Number Call for Parts 4’ Rocket body RZF-7294 9” x 14” Inlet RZA-7232 15–1/8” Rectangular Duct RGA-5032 9” x 14” Elbow Angle Frame RZA-7230 9”...
  • Page 20 5. APPENDIX RETRO ROCKET – AERATION SYSTEM GRS-7006 Item Description Quantity Part Number Call for Parts 6’ Rocket body RZF-7294 9” x 14” Inlet RZA-7232 15–1/8” Rectangular Duct RGA-5032 9” x 14” Elbow Angle Frame RZA-7230 9” x 14” Elbow Assembly (includes Weather Cap) GGA-8618 9”...

  • Page 21: Warranty

    5. APPENDIX 6. Warranty Except as expressly provided in this agreement, AGI Nobleford (hereinafter called the Manufacturer) excludes all express or implied warranties, conditions, and obligations of the Manufacturer, whether statutory or otherwise, concerning the quality of the units or their fitness for any purpose.
  • Page 22 AGI is a leading provider of equipment solutions for agriculture bulk commodities including seed, fertilizer, grain, and feed systems with a growing platform in providing equipment and solutions for food processing facilities. AGI has manufacturing facilities in Canada, the United States, the United Kingdom, Brazil, South Africa, India and Italy and distributes its products globally.
