Augmented Reality Tactical Assault Kit

Oculus Quest 2

User Manual

Table of Contents

Need help?

Do you have a question about the Oculus Quest 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for ARTAK Oculus Quest 2

Page 1 Augmented Reality Tactical Assault Kit Oculus Quest 2 User Manual...
Page 3: Table Of Contents
Table of Contents Contents Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Controllers .
Page 4 Installing & Opening ARTAK . . . . . . . . . . . . . . . . . .
Page 5: Headset
Headset         1. Top Strap 4. Power/Standby 2. Side Straps 5. Lens Spacing 3. Headphone Jacks 6. Volume...
Page 6: Controllers
Controllers Left Right           1. Thumbsticks 4. Battery Covers 2. Menu Button 5. Grip Buttons 3. Oculus Button 6. Triggers Selecting Objects and Icons Press/grab/click objects and icons to interact with them, using triggers (6) and/or “A”...
Page 7: Basic Controls
Basic Controls Home Menu must be closed to interact with map movement Maps Move Live Map - Click/grab the white pill on side of the map to move to desired location Static Map - Click/grab anywhere on the map with one hand and move to desired location Rotate Press/grab/click objects and icons to interact with them...
Page 8: Menus
Menus Open/Close Menus Using your left hand turn palm facing you to open up menu Drop left hand to close windows or use right hand to click the “x” Use back arrow to return to previous menu. When using Controllers, raise your left hand and press and HOLD the Menu Button (2) down.
Page 9: Icon
Icon ToolTip/Function Internet Green - Successfully Connected to Internet Red - Could Not Connect to the Internet Multi-User Green - Multi-User Active and Connected Yellow - Single-User Mode Active Red - Multi-User Not Connected Network Green -Device Connected to a Network Red - Device Not Connected to a Network Server Green - Successfully Connected to Server...
Page 10: Login Screen
Login Screen Check the Use Room Password if you would like  your room to be protected by a password Check Auto Login with Current Settings if you wish to bypass the Login screen next time How would you like to log in - Click to join a Multi- User or Single-User room Icon ToolTip/Function...
Page 11 Icon ToolTip/Function Open partition key panel Setting partition keys will lock all data created in a room using keys behind those keys. Clear Spatial Mesh Clears spatial mesh data Open Debug Panel Shows a log of warnings, errors, stack trace, and full debugging Shows Photon Stats Network Settings Panel click to open network settings panel...
Page 12: Network Setting Panel
Network Setting Panel Offline Mode Operate the application independent of all networking By toggling on you will no longer have Internet options Allow Internet Will allow the app to connect to the Internet...
Page 13: Server Connection Type
Server Connection Type Cloud - Connects to Eolian’s cloud sever. (Requires Internet) CANN - Connects to a CANN on this device’s LAN Custom - Connects to the specified IP Address Single-User Mode App will operate normally but with no Multi-User Functionality Multi-User Connection Type Cloud - Connects to Internet Multi-User service running on a Cloud CANN - Connects to the Multi-User service running on a CANN...
Page 14: Home Menu
Home Menu  If there is no map selected, the Map Menu icon will not appear Icon ToolTip/Function Map Selection Choose from a selection of maps Mission Plans Menu for creating, loading, and deleting mission plans...
Page 15 Icon ToolTip/Function Save a Mission Plan Plan a mission, then press create to get to save panel Enter a save name, then save to cloud or save to local file Load a Mission Plan Choose from saved mission plans, then press load Control Panel Menu for enabling and disabling other...
Page 16 Home Menu Icon ToolTip/Function HMD Syncer Menu for syncing this devices virtual content to the real world location Choose between spatial anchors or image tacking User List List of all users in the multi-user session as well as control over various user settings Toggle mute users/mute all Toggle disable all controls App Settings...
Page 17 Icon ToolTip/Function App Settings Menu containing settings and controls for Virtual Reality aspect Map Menu Menu containing settings and controls for the current map...
Page 18: Vr Settings
VR Settings VR Immersion Controls Left Thumpstick Right Thumpstick Travel though as if walking through the Hold forward on the thumbstick to “jump building to a spot”...
Page 19: Snap To Ground
Snap to Ground Vignette Strength Snap yourself to the map’s ground Control the darkness around the edges...
Page 20: Settings
Settings Icon ToolTip/Function Open debug panel Clear spatial mesh...
Page 21 Icon ToolTip/Function Open audio settings panel Mute Self Master Volume SFX Volume AI Voice Volume VOIP Volume Recenter visual data to the virtual world center Recenter the visual data in front of you Exit the room and return to the login screen...
Page 22: Map Menu
Map Menu Location Search and Bookmark icons will only appear in live maps ...
Page 23 Icon ToolTip/Function Location Search Enter a location to center the map over Use Lat/Lon, MGRS, or type a location to search for a location Bookmark Load and create location bookmarks Node History Choose a historical time window to view live data...
Page 24 Icon ToolTip/Function Map Settings Gives you the right Lat/Lon or MGRS Toggle contour lines, node/node labels, map labels, node directional Able to lock/unlock the map Able to lock/unlock all (nodes, routes, map) Toggle map shape from circular to square Adjust zoom level and map radius (shrink or enlarge map) Able to change the Node Height Node Stem Transparency Toggle map shape (ie circle, or square)
Page 25 Icon ToolTip/Function Point List Enter a location to center the map over Use Lat/Lon, MGRS, or type a location to search for a location Layer Selection Live Nodes Can see breadcrumbs (blue lines that show historical records of positioning) Analytic ex/ NYC Subway Lines Overlay ex/ population density...
Page 26 Icon ToolTip/Function Minimap Shows the area that was scanned from a 2D image Zoom in and out with the pill bar on the bottom after it is opened. Show Lat/Lon See the location with latitude and longitude the whole entire time on your laser pointer Recenter visual data Click to recenter the current visual data to the virtual world center for a location...
Page 27 Node Queue After adding any node to the node queue, a queue will spawn about waist high that will follow you To move and lock the node queue to a specific spot, grab the directional on the top left corner and drag to desired location Click ‘Reset Position’...
Page 28: Point Select
Point Select Click desired node (Assets, Vehicles, Points or Tasks) and then scroll through various options Click desired allegiance Click the plus button to add to node queue...
Page 29: Point Select Settings
Point Select Settings Click any node and a pop up  circle will appear with options Icon ToolTip/Function Target Lock Focus and follow as if live A green ring will appear around the node (Line of Site) LOS Actions Choose between 360, 270, 180, 90, 60 FOV (Field of View) A shaded region will appear representing what the node can see...
Page 30 Icon ToolTip/Function Vehicle Immersion View the map from the perspective of being in the current vehicle View Inventory Add guns, bombs, radios to the vehicle Shows firing range, blast radius, and service range of inventory Manipulate Altitude and Course Grab the green arrow to change node to desired altitude Grab the red circle to rotate the node to desired degree Click the blue arrow to snap node back to ground Click red “x”...
Page 31 Icon ToolTip/Function Lock Node Shows the area that was scanned but from a 2D image Zoom in and out with the pill bar on the bottom after it is opened. Route Options Unlink route points from this node Delete routes from this node Create a route from this node More Information Location, Course, Personal offset, Type, COT_...
Page 32: Route Options
Route Options  Click any route node and a pop up circle will appear with options Icon ToolTip/Function Destroy Point Removes point from the route Detach Link Points Choose between 360, 270, 180, 90, 60 FOV (Field of View) A shaded region will appear representing what the node can see Snap point to ground Node is pinned to the map, and cannot be moved...
Page 33 Icon ToolTip/Function Change color Change the color of the route by using sliders Extend Route Add another point to the route Edit Route Label route Basic Route - white Infill Route - light blue Dismount Route - blue Lock this route Lock/unlock a route into place Destroy this route Clear route from map...
Page 34: Node History
Node History Live Data Source Choose from APRS, ATAK, Live — Vehicle, and Route — Start Then choose a specific call sign...
Page 35 Target Date/Time Choose a specific date of the node desired Enter a target time - then use sliders to up to -13 hours before target time or +13 after target time...
Page 36 Updating & Opening ARTAK Download the ARTAK — VX.X.0.0 zip file from your desired source onto the Windows device Ensure the Quest device is in developer mode Ensure SideQuest Advanced Installer is installed and open on the computer which contains the downloaded apk file...
