ART. 462-N
Contatto magnetico in alluminio / Aluminium magnetic contact
SPECIFICHE GENERALI
GENERAL SPECIFICATIONS
Materiale contenitore
Alluminio pressofuso
Housing material
Die-cast aluminium
Funzionamento
NC con i due componenti vicini
Operation
NC when the two components are near
Temp. di funzionamento
-25°C ÷ +50°C
Operating temperature
Grado di protezione
Certificato IPx2 (dichiarato IP34 da Cooper CSA)
IP degree
Certified IPx2 (declared IP34 by Cooper CSA)
V max
42,4 Vpeak - 60 Vdc
1 A
I max
10 W
W max
Numero seriale/lotto su ogni componente
Identificazione
Identification
Serial number/batch on each component
I contatti magnetici sono componenti passivi, le grandezze elettriche indicate sono le massime applicabili
Magnetic contacts are passive components, max applicable voltage and current are displayed in table
EN50131-2-6
GR 2
Cooper CSA Srl Corsico (MI) Italy N.Verde: 800-449433 www.coopercsa.it
CL III
INSTALLAZIONE CONFORME ALLA NORMA
INSTALLATION AS PER STANDARD
OK
OK
La certificazione decade per installazioni diverse da quelle rappresentate nelle figure.
Certification is void if the devices are installed differently.
Advertisement
Summary of Contents for Cooper safety 462-N
- Page 1 ART. 462-N Contatto magnetico in alluminio / Aluminium magnetic contact SPECIFICHE GENERALI INSTALLAZIONE CONFORME ALLA NORMA GENERAL SPECIFICATIONS INSTALLATION AS PER STANDARD Materiale contenitore Alluminio pressofuso Housing material Die-cast aluminium Funzionamento NC con i due componenti vicini Operation NC when the two components are near Temp.
- Page 2 DISTANZE OPERATIVE / OPERATIONAL APPROACH AND REMOVAL DISTANCES Su superfici non ferromagnetiche installare i due corpi a distanza Y inferiore a 30mm (distanza raccomandata 9mm), su superfici ferromagnetiche a distanza Y inferiore a 25mm (distanza raccomandata 8mm). Le distanze operative riportate in tabella per gli assi X e Z sono state calcolate con i corpi installati alla distanza racomandata. Install the two components at Y distance less than 30mm (recommended 9mm) on non-ferromagnetic surfaces, at Y distance less than 25mm (recommended 8mm) on ferromagnetic surfaces.The operating distances displayed in table for axes X and Z have been calculated with the components mounted at the recommended distance.
