Lennox ELITE EL196UHE Installation Instructions Manual

Lennox ELITE EL196UHE Installation Instructions Manual

Upflow / horizontal air discharge
Hide thumbs Also See for ELITE EL196UHE:
Table of Contents

Advertisement

Quick Links

Download this manual
© 2023 Lennox Industries Inc.
Dallas, Texas USA
Contents
Unit Dimensions - inches (mm) ......................................2
EL196UHE......................................................................3
Shipping and Packing List ..............................................3
Safety .............................................................................3
General ...........................................................................5
Combustion, Dilution, Ventilation Air...............................5
Setting Equipment ..........................................................8
Filters ............................................................................13
Duct System .................................................................13
Pipe Fittings Specifications...........................................14
Joint Cementing Procedure ..........................................16
Venting Practices ..........................................................16
INSTALLATION
INSTRUCTIONS
EL196UHE
ELITE
SERIES GAS FURNACE
®
UPFLOW / HORIZONTAL AIR DISCHARGE
507764-06
01/2023
Supersedes 07/2022
THIS MANUAL MUST BE LEFT WITH THE
HOMEOWNER FOR FUTURE REFERENCE
This is a safety alert symbol and should never be
ignored. When you see this symbol on labels or in man-
uals, be alert to the potential for personal injury or death.
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional HVAC installer (or
equivalent), service agency or the gas supplier.
As with any mechanical equipment, contact with sharp
sheet metal edges can result in personal injury. Take
care while handling this equipment and wear gloves and
protective clothing.
Gas Piping ....................................................................36
Electrical .......................................................................39
Unit Start-Up .................................................................43
Gas Pressure Measurement.........................................45
Proper Combustion.......................................................45
High Altitude .................................................................45
Other Unit Adjustments.................................................47
Service..........................................................................48
Repair Parts List ...........................................................50
Start-Up Checklist.........................................................52
Blower Data ..................................................................54
Page 1
