WIRED REMOTE CONTROLLER MUENR-H12
Owner´s & installation manual
KJRH-120K/BMKO-E
CL09204
www.mundoclima.com
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KJRH-120K/BMKO-E and is the answer not in the manual?

Questions and answers

Related Manuals for mundoclima KJRH-120K/BMKO-E

Summary of Contents for mundoclima KJRH-120K/BMKO-E

  • Page 1 WIRED REMOTE CONTROLLER MUENR-H12 Owner´s & installation manual KJRH-120K/BMKO-E CL09204 www.mundoclima.com English...

  • Page 2: Table Of Contents

    This manual gives detailed description of the precautions that should be brought to your attention during operation. In order to ensure correct service of the wired controller, please read this manual carefully before using the unit. For convenience of future reference, keep this manual after reading it. CONTENTS GENERAL SAFETY PRECAUTIONS About the documentation...
  • Page 3 MENU STRUCTURE About the menu structure To go to the menu structure BASIC USAGE Screen unlock Turning ON/OFF controls Adjusting the temperature Adjusting the operation mode 6 OPERATION 6.1 PRESET TEMPERATUER 6.2 DOMESTIC HOT WATER(DHW) 6.3 SCHEDULE 6.4 OPTIONS 6.5 CHILD LOCK 6.6 SERVICE INFORMATION 6.7 OPERATION PARAMETER 6.8 FOR SERVICEMAN...

  • Page 4: General Safety Precautions

    1 GENERAL SAFETY PRECAUTIONS 1.1 About the documentation The original documentation is written in English. All other languages are translations. The precautions described in this document cover very important topics, follow them carefully. All activities described in the installation manual must be performed by an authorized installer.

  • Page 5: For The User

    WARNING Indicates a situation that could result in death or serious injury. CAUTION Indicates a situation that could result in minor or moderate injury. NOTE Indicates a situation that could result in equipment or property damage. INFORMATION Indicates useful tips or additional information. 1.2 For the user If you are not sure how to operate the unit, contact your installer.
  • Page 6 The appliance is not intended for use by persons, including children, with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 7 Units are marked with the following symbol: This means that electrical and electronic products may not be mixed with unsorted household waste. Do not try to dismantle the system yourself: the dismantling of the system, treatment of the refrigerant, of oil and of other parts must be done by an authorized installer and must comply with applicable legislation.

  • Page 8: Glance Of The User Interface

    2 A GLANCE OF THE USER INTERFACE 2.1 The appearance of the wired controller Enter the menu structure from the home page Turn on or off the space operation mode or DHW mode; turn on or off the function Navigate the in the menu cursor on the structure...

  • Page 9: Status Icons

    2.2 Status icons Lock icon Weekly schedule icon At the next scheduled action, Timer icon the desired temp. will decrease. the desired temp. Outdoor ambient temp. will not change. the desired temp. WLAN icon will decrease. the desired temp. Domestic hot water will increase.

  • Page 10: Using Home

    3 USING HOME PAGES 3.1 About home pages Select your preferred language, then press “ ” to enter the home pages. If you don't press “ ” in 60 seconds, the system will enter in the currently selected language. Based on the system layout, the following home pages may appear:...
  • Page 11 Home page 1: If the WATER FLOW TEMP. is set YES and ROOM TEMP. is set NON, the system has the functions including space heating, space cooling and domestic hot water, home page 1 will appear: Without DHW function or DHW mode is set available DHW mode is set unavailable...
  • Page 12 Home page 2: If the WATER FLOW TEMP. is set NON and ROOM TEMP. is set YES, the system has the functions including space heating, space cooling and domestic hot water, home page 2 will appear: Without DHW function or DHW mode is set available DHW mode is set unavailable The wired controller should be installed in the room to detect the room...
  • Page 13 Home page 3 ： If the ROOM THERMOSTAT is set DOUBLE ZONE, the system has the functions including space heating, space cooling and domestic hot water, there will be main page and additional page: Main page Main page Addition page Addition page Without DHW function or DHW mode is set available...
  • Page 14 Home page 4: If the unit has no DHW function or DHW is set unavailable, WATER FLOW TEMP. and ROOM TEMP. are both set YES, the system has the functions including space heating and space cooling, there will be main page and additional page:...
  • Page 15 NOTE All the pictures in the manual are for explanation, the actual pages in the screen may have some difference. WATER FLOW TEMP., ROOM TEMP. and DOUBLE ZONE are set in FOR SERVICEMAN, it is not recommended for non-professionals to enter FOR SERVICEMAN.

  • Page 16: Menu Structure

    4 MENU STRUCTURE 4.1 About the menu structure You can use the menu structure to read out and configure settings that are NOT meant for daily usage, and you can find the detailed operation methods about the menu structure in this manual. If the unit has no DHW function or DHW mode is set unavailable , there is no DOMESTIC HOT WATER(DHW) menu in the interface.

  • Page 17: Basic Usage

    5 BASIC USAGE 5.1 Screen unlock The icon " "showing on the screen means the controller is locked. Long press " " , it will disappear, then the controller can be used. Long press " " The controller will be locked if it has not been operated for a long time (about 120 seconds).

  • Page 18: Turning On/Off Controls

    5.2 Turning ON/OFF controls Use the controller to turn on or off the operation mode(heat mode , cool mode , auto mode , DHW mode ) of the unit. 1) The unit has DHW function and DHW mode is set available. Press " "...
  • Page 19 2) The unit has no DHW function or DHW mode is set unavailable. The operation methods of turning on or off the operation mode in other menus is similar.

  • Page 20: Adjusting The Temperature

    5.3 Adjusting the temperature Use ''◄'', ''►'' to select the operating mode.
  • Page 21 Use ''▼'', ''▲'' to adjust the temperature value. The operation methods of adjusting the temperature in other menus (including that the unit has no DHW function or DHW mode is set unavailable) is similar.

  • Page 22: Adjusting The Operation Mode

    5.4 Adjusting the operation mode Go to " " > "OPERATION MODE'', then press " ", the following page will appear: OPERATION MODE Operation mode setting： HEAT AUTO COOL CONFIRM There are three operation modes on the controller interface: HEAT mode, COOL mode and AUTO mode, Use ''◄''，...
  • Page 23 If COOL(HEAT) mode is set to NON, only one mode can be selected on the controller interface, the following page will appear: OPERATION MODE OPERATION MODE Operation mode can only be set Operation mode can only be set heat mode: cool mode: HEAT COOL...
  • Page 24 When "ROOM THERMOSTAT" is set "ONE ZONE" or "DOUBLE ZONE" in "FOR SERVICEMAN", the "OPERATION MODE" page is as follows： OPERATION MODE Operation mode setting： HEAT AUTO COOL CONFIRM Under this circumstance, HEAT mode and COOL mode can be selected, but AUTO mode can not be selected.

  • Page 25: Operation

    6 OPERATION 6.1 PRESET TEMPERATUER PRESET TEMPERATUER has 3 items: PRESET TEMP., WEATHER TEMP. SET, ECO MODE. 6.1.1 PRESET TEMP. PRESET TEMP. (PRESET TEMPERATUER) function is used to set different temperature on different time when the heat mode or cool mode is The PRESET TEMP.
  • Page 26 Use ''◄'', ''► '', ''▼'', ''▲'' to scroll and use "▼", "▲" to adjust the time and the temperature, press " " to select the timer. Six timers can be selected.( enable the timer. disable the timer.) PRESET TEMPERATURE PRESET WEATHER TEMP.
  • Page 27 The temperature will change according to the figure below: TEMP. 40°C 35°C INFORMATION When double zone is activated, the PERSET TEMP. function only works for zone 1. The PRESET TEMP. function can be used in heat mode or cool mode. But if the operation mode is switched between heat mode and cool mode, the PRESET TEMP.
  • Page 28 6.1.2 WEATHER TEMP. SET WEATHER TEMP. SET (WEATHER TEMPERATURE SET) function is used to preset the desired water flow temperature depending on the outdoor temperature. Take heat mode as an example: the WEATHER TEMP. SET function can lower the desired water flow temperature when the outdoor temperature increases.
  • Page 29 Use " " to turn on/off the temperature curve. If "ZONE1 C-MODE LOW TEMP." is turned on, cool mode in zone 1 is activated, the following page will appear: WEATHER TEMP. SET WEATHER TEMP. SET TYPE: 1 2 3 5 6 7 8 9 CONFIRM The operation method of other temperature curves is similar.
  • Page 30 PRESET TEMPERATURE PRESET TEMPERATURE PRESET WEATHER PRESET WEATHER TEMP. TEMP. SET MODE TEMP. TEMP. SET MODE 0°C ZONE 1 C-MODE LOW TEMP. ZONE 1 C-MODE CURVE OFFSET ZONE 1 H-MODE LOW TEMP. ZONE 1 H-MODE CURVE OFFSET 0°C 0°C ZONE 2 C-MODE LOW TEMP. ZONE 2 C-MODE CURVE OFFSET 0°C ZONE 2 H-MODE LOW TEMP.
  • Page 31 Heating mode-low water temperature (T4 is the ambient temperature, T1S is the desired water temperature.) ≤ - 20 - 19 - 18 - 17 - 16 - 15 - 14 - 13 - 12 - 11 - 10 1- T1S 2- T1S 3- T1S 4- T1S...
  • Page 32 The automatic setting curve The automatic setting curve is the ninth curve,this is the calculation method: T1SETH1 T1SETH2 T4H1 T4H2 State:In the setting of the wired controller, if T4H2<T4H1, then exchange their value; if T1SETH1<T1SETH2, then exchange their value. (T1SETH1, T1SETH2,T4H1,T4H2 can be set in "FOR SERVICEMAN" .) Cooling mode-low water temperature - 10≤...
  • Page 33 Cooling mode-high water temperature - 10≤ T4＜15 15≤ T4＜22 22≤ T4＜30 30 ≤ T4 1- T1S 2- T1S 3- T1S 4- T1S 5- T1S 6- T1S 7- T1S 8- T1S The automatic setting curve The automatic setting curve is the ninth curve,this is the calculation method: T1SETC1 T1SETC2 T4C1...
  • Page 34 6.1.3 ECO MODE ECO MODE is used to save energy. Go to " "> ''PRESTE TEMPERATURE'' >"ECO MODE". Press '' the following page will appear: PRESET TEMPERATURE PRESET WEATHER TEMP. TEMP.SET MODE CURRENT STATE ECO TIMER 08:00 START 9 1 0 0 ON/OFF Press '' '', the following page will appear:...
  • Page 35 Use " " to turn on/off "CURRENT STATE" or "ECO TIMER" , and use ''▼'', ''▲'' to adjust the start time and end time. PRESET TEMPERATURE PRESET WEATHER TEMP. TEMP.SET MODE CURRENT STATE ECO TIMER START 08:00 ADJUST INFORMATION ECO MODE is valid only in heat mode (one zone). If the ECO MODE is activated, the desired temperature can not be adjusted on the interface.
  • Page 36 6.2 DOMESTIC HOT WATER(DHW) The parameters in "DOMESTIC HOT WATER(DHW)" can be set only when the unit has DHW function and DHW is set available. If the unit has no DHW function or DHW is set unavailable, "DOMESTIC HOT WATER(DHW)" will not be displayed on the interface. DOMESTIC HOT WATER(DHW) contains the following menu: 1) DISINFECT 2) FAST DHW...
  • Page 37 Use " " to turn on/off "CURRENT STATE", and use''▼'', ''▲'' to adjust the operate date and start time of disinfect function. Example: If "OPERATE DAY" is set FRIDAY and "START" is set 23:00, the disinfect function will be activated at 23:00 on Friday. 6.2.2 FAST DHW The FAST DHW function is used to force the system to operate in DHW mode.
  • Page 38 6.2.3 TANK HEATER The TANK HEATER function is used to force the tank heater to heat the water in tank. Even if the heat pump system fails, the TANK HEATER function can still be used to heat the water in tank. The TANK HEATER function can be used only when "TBH FUNCTION"...
  • Page 39 INFORMATION If "CURRENT STATE" is OFF, TANK HEATER is invalid. If the T5 (temperature sensor of tank) fails,TANK HEATER is invalid. The TANK HEATER function is valid only for once after it's settled. 6.2.4 DHW PUMP The DHW PUMP function is used to return water from the water net. The DHW PUMP function can be used only when PUMP_D is set valid (PUMP_D can be set in "FOR SERVICEMAN").
  • Page 40 Use ''◄", ''►'', ''▼'', ''▲'' to scroll and use ''▼'', ''▲'' to adjust the start time, press " " to select the timer. Twelve timers can be set. ( enable the timer. disable the timer.) DOMESTIC HOT WATER（DHW） DIS- FAST TANK INFECT HEATER...
  • Page 41 PUMP_D RUNNING TIME is set 30 minutes (PUMP_D RUNNING TIME can be set in "DHW MODE SETTING" in "FOR SERVICEMAN"). The pump will run according to the figure below: PUMP 6:00 6:30 7:00 7:30 8:00 8:30 9:00 9:30 6.3 SCHEDULE SCHEDULE contains the following menu: 1) TIMER 2) WEEKLY SCHEDULE...
  • Page 42 SCHEDULE WEEKLY SCHEDULE CANCEL TIMER SCHEDULE CHECK TIMER START MODE TEMP 00:00 00:00 HEAT 30℃ 00:00 00:00 HEAT 30℃ 00:00 00:00 HEAT 30℃ ONE ZONE is valid ZONE2 SCHEDULE ZONE1 SCHEDULE WEEKLY SCHEDULE CANCEL WEEKLY SCHEDULE CANCEL TIMER TIMER SCHEDULE CHECK TIMER SCHEDULE...
  • Page 43 Go to " "> "SCHEDULE">"TIMER". Press '' '', the following page will appear: SCHEDULE WEEKLY SCHEDULE CANCEL TIMER SCHEDULE CHECK TIMER START MODE TEMP 00:00 00:00 HEAT 40℃ 00:00 00:00 HEAT 40℃ 00:00 00:00 HEAT 40℃ Use ''◄", ''►'', ''▼'', ''▲'' to scroll and use ''▼", ''▲'' to adjust the start/end time, operation mode and temperature,press "...
  • Page 44 The unit will run according to the figure below: 6.3.2 WEEKLY SCHEDULE(Take ONE ZONE as an example) The WEEKLY SCHEDULE function is used to set different operation mode and temperature within one week (One day or more). If "WEEKLY SCHEDULE" and "TIMER" are both set, and "TIMER" is set later than “WEEKLY SCHEDULE", then the "TIMER"...
  • Page 45 Press '' '' again, “MON” is selected as shown below. It means Monday has been selected. SCHEDULE WEEKLY SCHEDULE CANCEL TIMER SCHEDULE CHECK TIMER MON. TUE. WED. THU. FRI. SAT. SUN. ENTER CANCEL MON SELECT Then use " ▼ " to move cursor to “ENTER”, press " ", operation mode and temperature of Monday can be set.
  • Page 46 6.3.3 SCHEDULE CHECK (Take ONE ZONE as an example) The SCHEDULE CHECK function is used to check the weekly schedule. Go to " " > '' SCHEDULE" > "SCHEDULE CHECK". Press '' '', the following page will appear: WEEKLY SCHEDULE CHECK MODE SET START END 30 ℃...
  • Page 47 6.4 OPTIONS OPTIONS contains the following menu: 1) SILENT MODE 2) HOLIDAY AWAY 3) HOLIDAY HOME 4) BACKUP HEATER 6.4.1 SILENT MODE The SILENT MODE function is used to reduce the running sound of the unit. However, it also reduces the heating or cooling capacity of the system. There are two silent mode levels, level 2 is more silent than level1.
  • Page 48 Use '' '' to turn on/off current state of SILENT MODE, Timer1 and Timer2, use "▼", "▲" to select the silent level and adjust the start/end time of the timer. There are two methods to use the silent mode: 1) Silent mode all the time. 2) Silent mode related to timers.
  • Page 49 OPTIONS HOLIDAY SILENT HOLIDAY BACKUP MODE AWAY HOME HEATER CURRENT STATE DHW MODE DISINFECT HEAT MODE ON/OFF Use '' '' to turn on/off current state of HOLIDAY AWAY, HEAT mode(DHW mode) and DISINFECT mode, use"▼", "▲" to adjust the start and end time of the holiday.
  • Page 50 6.4.3 HOLIDAY HOME The HOLIDAY HOME function is used to set different operation mode and temperature during the holiday at home. Go to " " > "OPTIONS" > "HOLIDAY HOME". Press '' '', the following page will appear: OPTIONS OPTIONS SILENT HOLIDAY HOLIDAY...
  • Page 51 SCHEDULE HOLIDAY HOLIDAY SILENT BACKUP AWAY HOME MODE START MODE TEMP 00:00 00:00 HEAT 30℃ 00:00 00:00 HEAT 30℃ 00:00 00:00 HEAT 30℃ INFORMATION If "HOLIDAY AWAY" and "HOLIDAY HOME" are both set, and "HOLIDAY HOME" is set later than "HOLIDAY AWAY", then the "HOLIDAY HOME"...
  • Page 52 6.4.4 BACKUP HEATER The BACKUP HEATER function is used to turn on the backup heater forcibly, it can be used only when IBH (Backup heater) is set valid by DIP switch on the main control board of hydraulic module or AHS (Auxiliary heating source)FUNCTION is set valid in "OTHER HEATING SOURCE"...
  • Page 53 6.5 CHILD LOCK The CHILD LOCK function is used to avoid children’s misoperation. If the unit has no DHW function or DHW is set unavailable, "DHW TEMP. ADJUST" and "DHW MODE ON/OFF" will not be displayed on the interface. Go to " "...
  • Page 54 6.6 SERVICE INFORMATION SERVICE INFORMATION contains the following menu: 1) SERVICE CALL 2) ERROR CODE 3) PARAMETER 4) DISPLAY 6.6.1 SERVICE CALL The SERVICE CALL function is used to show the service phone or mobile number. The installer can input the number in "FOR SERVICEMAN". Go to "...
  • Page 55 6.6.2 ERROR CODE The ERROR CODE function is used to show when the fault or protection happened and show the meaning of the error code. Go to " ">"SERVICE INFORMATION" >"ERROR CODE", press " ", the following page will appear: SERVICE INFORMATION SERVICE ERROR...
  • Page 56 6.6.3 PARAMETER The PARAMETER function is used to display the main parameters. Go to " ">"SERVICE INFORMATION" >"PARAMETER", the following page will appear: SERVICE INFORMATION SERVICE INFORMATION SERVICE ERROR SERVICE ERROR PARAMETER DISPLAY PARAMETER DISPLAY CALL CODE CALL CODE MAIN ACTUAL TEMP. 26℃...
  • Page 57 6.7 OPERATION PARAMETER The OPERATION PARAMETER function is for installer or service engineer to review the operation parameter. You can check the water temperature, water flow, pressure and other parameters by using "OPERATION PARAMETER". INFORMATION 1. POWER CONSUM is for reference only, not used to judge the actual power consumption.
  • Page 58 6.8 FOR SERVICEMAN The FOR SERVICEMAN function is for the installer to set the parameters. Go to " " > "FOR SERVICEMAN", the password is "234". It is not recommended for non-professionals to enter "FOR SERVICEMAN". 6.9 SN VIEW The SN VIEW function is used to view the SN code. SN VIEW SN VIEW IDU NO.
  • Page 59 7 NETWORK CONFIGURATION GUIDELINES The wired controller realizes intelligent control with a built-in module, which receives control signal from the APP. Before connecting the WLAN, please check for it if the router in your environment is active and make sure that the wired controller is well-connected to the wireless signal.
  • Page 60 Activate the WLAN by interface. Go to " "> "WLAN SETTING"> "AP MODE". Press" " the following page will appear: AP MODE Do you want to activate the WLAN network and exit? CONFIRM Use ''◄''， ''►'' to move to"YES", press " "...
  • Page 61 Restore WLAN setting by interface. Go to “ ”> “WLAN SETTING” > “RESTORE WLAN SETTING” . Press" ", the following page will appear: RESTORE WLAN SETTING Do you want to restore the WLAN setting and exit? CONFIRM Use ''◄''， ''►'' to move to "YES", press ” ”...
  • Page 62 7.2 Mobile Device Setting AP Mode is available for wireless distribution on mobile device side. AP Mode connecting WLAN: 7.2.1 Install APP ① Scan the following QR code to install the Smart Home APP. ② Please research "Comfort Home" in APP STORE or GOOGLE PLAY to install the APP.
  • Page 63 7.2.2 Sign in/Sign up Please input your registration code. Or scan the QR code on the controller packaging box if existed. And register your account according to the guidance.
  • Page 64 7.2.3 Add Home Appliances: 1）Add your device following the guidance.
  • Page 65 2）Operate the wired controller according to APP prompts.
  • Page 66 3）Wait for the home appliance to connect, and click “Sure”.
  • Page 67 4) After the appliance is successfully connected, the LCD icon“ ” of the wired controller is constantly on, and the heat pump can be controlled through the APP. 5) If the network distribution process fails, or the mobile connection demands reconnection and replacement, operate “RESTORE WLAN SETTING”...
  • Page 68 Warning and troubleshooting for networking failures When the product is connected to the network, please make sure that the phone is as close as possible to the product. We only support 2.4GHz band routers at present. Special characters (punctuation, spaces, etc.) are not recommended as part of the WLAN name.
