- Page 1 Assembly Instructions max. 275 kg ~ 30 Min. 28.5 kg L 126.7 | W 72.4 | H 101.3 SWF603.01.02 Art. No. SW-F603 Weight Bench F603...
- Page 2 F603...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly STORAGE AND TRANSPORT General Instructions Transportation Wheels TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List... - Page 4 Dear customer, Thank you for choosing a high-quality equipment of the brand BodyCraft®. BodyCraft® offers sports and fitness equipment for the sophisticated home sport and the equipment of fitness studios and business customers. With BodyCraft® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 5 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 6: General Information
GENERAL INFORMATION Technical Data Weight and Dimensions Article weight (gross, incl. packaging): 31.6 kg Article weight (netto, excl. packaging): 28.5 kg Package dimensions (L x W x H) approx.: 118 cm x 54 cm x 21 cm Set-up dimensions (L x W x H) approx.: 126.7 cm x 72.4 cm x 101.3 cm F603... -
Page 7: Personal Safety
Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 8: Set-Up Place
Set-Up Place ⚠ WARNING Do not place the equipment in main corridors or escape routes. CAUTION ⚠ Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 9: Assembly
ASSEMBLY General Instructions DANGER ⚠ Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 10: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠... -
Page 11: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. Step 1: Assembly base frame Attach the Rear Frame (1) to Base Frame (2) using two 1/2”... - Page 12 Step 2: Assembly support frame Attach the Back Support Frame(3) to the Base Frame (2) using one 1/2” X 4-1/2” Hex Bolt (17), two 1/2” Washers (22), and one 1/2” Nylon Nut (24). Tighten this bolt and loosen just enough for the Back Support Frame (3) to rotate freely. Attach the 3/8”...
- Page 13 Step 3: Assembly cushions Attach the Back Pad (6) to the Back Adj. Slider (4) using four 3/8” X 1”’ Hex Threaded Bolts (20), and four Washers (23). Slide the Back Adj. Slider (4) onto the Back Support Frame (3) and lock it into place at your desired height using the Spring Knob (15).
-
Page 14: Storage And Transport
STORAGE AND TRANSPORT General Instructions WARNING ⚠ The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... -
Page 15: Faults And Fault Diagnosis
Faults and Fault Diagnosis The equipment undergoes regular quality controls during production. Nevertheless, faults or malfunctions may occur. Frequently, individual parts are responsible for these disturbances, an exchange is usually sufficient. Please refer to the following overview for the most common errors and how to correct them. -
Page 16: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape. -
Page 17: Ordering Spare Parts
ORDERING SPARE PARTS Serial Number and Model Name In order to provide you with the best possible service, please have the model name, article number, serial number, exploded drawing and parts list ready. The corresponding contact options can be found in chapter 9 of this operating manual. NOTICE The serial number of your equipment is unique. -
Page 18: Parts List
Parts List Name Qty. REAR FRAME BASE FRAME BACK SUPPORT FRAME BACK ADJ. SLIDER HANDLE BAR BACK PAD SEAT PAD SHEET NONSLIP HAND GRIP SLEEVE WHEEL RECT. PLASTIC BUSHION 45 X 75mm END RECT. PLUG STEEL BUSHION SPRING KNOB LONGER POP PIN 1/2"... -
Page 19: Exploded Drawing
Exploded Drawing... -
Page 20: Warranty
WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. Error Descriptions Your fitness equipment is developed for long-term, high-quality training. - Page 21 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
-
