Summary of Contents for Summit Industries 325E
- Page 1 325E X-RAY GENERATOR USER AND ASSEMBLER INFORMATION For X-ray Control Model No.: F280 and X-ray High-voltage Generator Model No. A700 01496-000 Revision G AUGUST 2005 SUMMIT INDUSTRIES, INC. 2901 W. Lawrence Avenue Chicago, IL 60625 773-588-2444 www.Summitindustries.net...
- Page 2 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 TEXT REVISION HISTORY FOR F285 MANUAL REVISION DESCRIPTION RELEASE DATE 4196 UPDATED COVER SHEET AND AUGUST 2004 SCHEMATICS 4484 ADDED ERROR CODES AND TUBE FEBRUARY 2005 PROTECT DIP SW. SETTINGS DUE TO 02249-000 TIMER BOARD.
-
Page 3: Table Of Contents
325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 TABLE OF CONTENTS INTRODUCTION ....................2 USER INFORMATION ..................3 CONTROL FEATURES................3 RECOMMENDED OPERATING PROCEDURES ........6 MAINTENANCE ................... 7 TECHNICAL INFORMATION ............... 9 III. ASSEMBLER INFORMATION................11 CERTIFICATION OF COMPATIBILITY............ -
Page 4: Introduction
325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 I. INTRODUCTION The equipment, which is described in this manual, will perform reliably when installed, operated, and maintained in accordance with the instructions of this manual. This equipment is sold with the understanding that the user assumes sole responsibility... -
Page 5: User Information
325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 II. USER INFORMATION This x-ray generator is both easy to use and very versatile. It consists of an x-ray control and a high voltage generator (H.V. generator). A. CONTROL FEATURES... - Page 6 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 H) X-ray exposure switch – Two level switch: Partial depression (PREP) causes anode rotation and filament current boost. Full depression (EXPOSE) initiates the production of x-rays. I) Exposure time selector switch – Provides the operator capability to select any one of 23 different exposure times.
- Page 7 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700...
-
Page 8: Recommended Operating Procedures
325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 B. RECOMMENDED OPERATING PROCEDURES Note: It is important to turn the generator “on” at least 15 minutes before making an exposure. This will provide sufficient “warm-up” time for the circuitry to stabilize. - Page 9 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 6. Observe the digital display (G) to confirm that the correct mAs has been selected. 7. Select the desired peak tube potential (kVp) by observing the kVp meter (O) while rotating the kVp selectors (M&N)
-
Page 10: Maintenance
325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 C. MAINTENANCE Periodic inspection and preventative maintenance of this equipment is necessary to assure continued safe performance and compliance with applicable state and federal regulations. The following maintenance program must be closely followed. -
Page 11: Technical Information
325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 D. TECHNICAL INFORMATION Rated line voltage – 240 VAC, 60 Hz., single phase. Range of line voltage regulation at max. line current = 1-5% Maximum line current based on input voltage of 240 VAC -140A. - Page 12 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 Exposure Time The maximum deviation of the measured exposure time from its pre-indicated values is + 1 pulse for selected times within the range of 1/120 – 1/10 sec.
-
Page 13: Assembler Information
325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 III. ASSEMBLER INFORMATION A. CERTIFICATION OF COMPATIBILITY The manufacturer certifies that it’s certified x-ray controls and high voltage generators are compatible with all certified x-ray tubes concerning compliance with 21CFR, Chapter I, Sub-chapter J, only if the ratings of the controls, generators and tubes are strictly observed and the control is calibrated within the applicable published limits. -
Page 14: Unpacking And Opening Control
325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 Line Voltage Regulation – Not to exceed 5% at maximum line current. Percent line voltage regulation = V – V X 100 where V represents the line voltage under “no load” conditions, and V represents line voltage under “full load”... - Page 15 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 5. From the inside of the control, remove the two thumbscrews and washers from front panel being careful not to drop them into the cabinet.
-
Page 16: Preliminary Assembly And Tube Protect Selections
325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 6. Grasp the “lift tab” at the center of the front panel (near the top) and lift upwards approximately 1” to unhook the bottom of the front panel from the base of the cabinet. - Page 17 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 2. Connect x-ray tube a) High voltage cables (HV cables) – The high voltage generator requires the use of H.V. cables constructed with federal terminals. Note: Use extreme care when handling the H.V. cables to avoid damaging the plug or terminal pins.
- Page 18 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 3. Connect high voltage generator to control – a) The 25’ primary cable for the H.V. generator is connected to the control at the factory. The loose end, marked P1, P2, and GND, should be connected to the corresponding terminals of the H.V.
- Page 19 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 7. Auxilary exposure switch – Terminals have been provided in the control for connecting an auxilary exposure switch. They are on TB2 and are marked S1, s2, and S3. Refer to control circuit schematic for connection details.
-
Page 20: Preliminary Electrical Checks And Adjustments
325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 F. Preliminary Electrical Checks and Adjustments 1. Line voltage adjustments – Terminals in the control on TBI are provided for coarse adjustments of line voltage. Measure the line voltage at the disconnect switch and relocate wire marked LVA to the corresponding terminal. - Page 21 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 Note that the 02249-000 timer board will display error codes per the table below. If more than one selection is invalid the highest number will take precedence. For example, an “invalid mA” and “kVp too low” would display as E04. Once the mA error is cleared the kVp low error E03 would then be displayed.
-
Page 22: Calibration
325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 Then reset kVp selectors to result in voltmeter indication of 160 VAC. mA STATION kVp METER INDICATION (kVp) If the kVp meter indication varies by more than 5 kVp from the values given above, proceed to the kVp calibration procedure (page 23). - Page 23 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 1. Calibration of Tube Current Achieving maximum accuracy of tube current involves two types of adjustments: • Overall mA level (bands of filament resistors RXS and RXL), AND •...
- Page 24 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 + 5% SELECTED m A - 5% kV p h) Repeat steps (a) through (g) for the remaining mA stations: Note: In step (b), use the following values in place of 156 mA.
- Page 25 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 METER VOLTAGE kVp METER (VAC) INDICATION 50 kVp 80 kVp 100 kVp 120 kVp b) Verify kVp METER COMP. CIRCUIT input voltage and write down factory kVp METER offset calibration data.
- Page 26 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 c) Verify and adjust kVp meter accuracy 1) Select 150 mA and 50 kVp. While monitoring mA and kVp output, compare the measured kVp to the kVp meter’s preread indication.
- Page 27 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700...
-
Page 28: Final Compliance Tests
325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 H. FINAL COMPLIANCE TESTS It is necessary for the assembler to perform tests on the newly-assembled x-ray system prior to release to the user. These tests must assure compliance with the applicable requirements of the FDA performance standard at the time of installation. - Page 29 325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 TUBE CURRENT The maximum deviation of the tube current from its preindicated value, during an exposure, when the equipment is connected to an adequate power supply (see section IIA) shall not exceed +9% of selected tube current within the range of 50-125 kVp (inclusive), and +19% of selected tube current within the range of 40-50 kVp (exclusive).
-
Page 30: Anchoring Control Cabinet To The Floor
325E X-Ray Generator Summit Industries, Inc. Model Numbers F280 / A700 I. ANCHORING CONTROL CABINET TO THE FLOOR It is necessary, in order to meet regulations set forth by Underwriters Laboratories, to anchor the control cabinet to the floor. A 3/8 diameter hole is located centered in the bottom panel to accept an anchoring screw. -
Page 31: B127 --Schematic, 325 Control Circuit Diagram
PART I.D. for 325 & 360 GENERATOR LID ASSEMBLY 02255-000: kV Tap Switch A367: Milliampre Meter 325 HE73: RED LIGHT, A312: Knob without Pointer 00312-000: mAs Display TUBE LIMIT (Same for Major and Minor) RED LED Replacement B697: Milliampre Meter 360 01376-000: Kit, Kilovolt Meter 01381-000:... -
Page 32: 249-002 -- Component Layout For Timer Driver Pcba
A323 ELECTRICAL CHASSIS for 325 generators filename: A323_ElecChassis 325.JPG ROGERS C:/Pictures/GenerComponents/60Hz/Nova... -
Page 33: B130-- Schematic, Motor Start Crct
F280, B300, K240, 01200 01204... -
Page 35: B132-- Schematic For Kv Comp. Pcb Assy. (01204)
1/4 WT RESISTOR SIZE JUMPER mA Station Gens Gens 200S 5VDC 5VDC 300L 300L 200L 240L 150L 120S 100S 360L Schematic for Timer/Driver PCBA (Summit Part No. 02249-003 Rev. C) -
Page 36: B133--High Tension Transformer Diagram (A700)
Component Layout for Timer/Driver PCBA (Summit Part No. 02249-002 Rev. C)
