Introduction ................................................................................................................................................ 2
Before You Ride .......................................................................................................................................... 3
E-Trike Support ....................................................................................................................................... 3
E-Trike Warranty ..................................................................................................................................... 3
Assembly Instructions ................................................................................................................................. 7
Front Wheel Assembly ............................................................................................................................ 7
Handlebar Installation and Configuration ................................................................................................... 9
Left Side Handlebar Controls ................................................................................................................ 11
Right Side Handlebar Controls .............................................................................................................. 12
Parking Brake Locks .............................................................................................................................. 13
Battery Installation and Charging ............................................................................................................. 14
Charging Instructions ............................................................................................................................ 14
Taking the Batteries on and off the Trike .............................................................................................. 15
Operating Instructions .............................................................................................................................. 17
Riding Tips ................................................................................................................................................. 18
Service and Maintenance ......................................................................................................................... 18
LCD Error Codes ........................................................................................................................................ 21
eTc Companion
User Manual
Advertisement
Table of Contents
Related Manuals for eTrikes eTc Companion
Summary of Contents for eTrikes eTc Companion
-
Page 1: Table Of Contents
Companion User Manual Introduction ..............................2 Before You Ride ............................3 E-Trike Support ............................3 E-Trike Warranty ............................. 3 Assembly Instructions ..........................7 Front Wheel Assembly ..........................7 Handlebar Installation and Configuration ....................9 Left Side Handlebar Controls ........................ 11 Right Side Handlebar Controls ...................... -
Page 2: Introduction
Please take a moment to record the following information. Your Trike Details Frame Serial Number Front Battery Serial Number Rear Battery Serial Number Date of Purchase Order Number CAUTION: Fully charge the batteries for first use eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com... -
Page 3: Before You Ride
Unless otherwise specified, ex-demo and showroom models do not come with any warranty. Standard wear and tear parts like tires, tubes, nuts and bolts, chains, brake cables or hydraulics, bearings, disc brake wear are not covered by warranty. For full warranty details visit https://etrikescanada.com/pages/terms-conditions eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com... - Page 4 We recommend service and maintenance by a professional technician at a local bicycle shop. All components on this e-trike are standard brand name 2-wheel bicycle components so service and maintenance are the same as any e-bike. eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com...
- Page 5 • If the battery is being stored make sure it is in a clean dry space not near any water or heat source, remove the battery from the bicycle and recharge it every month. eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com...
- Page 6 NOT covered by the warranty. DO NOT use chargers or other components that have not been approved and tested by eTrikes Canada. eTrikes Canada is not responsible for damage caused by the use of other products not specifically designed and tested for use with this electric bike.
-
Page 7: Assembly Instructions
Once in position fully tighten the axle bolts. To connect the motor line up the arrows on the connecting cables and plug firmly together until you feel them snap in place. eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com... - Page 8 September 2023 Insert the front forks where the green arrow indicates above. Be sure the notched washer and motor cable are in the downward position. eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com...
-
Page 9: Handlebar Installation And Configuration
To adjust the tilt position of the bars, use a 5mm Allen-key to loosen the side bolt, and a 6mm Allen-key to loosen the bottom plate. Once in position re-tighten both bolts. Be sure to test everything is tight before riding. eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com... - Page 10 September 2023 eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com...
-
Page 11: Left Side Handlebar Controls
2. Rear Turn Signals 3. Horn 4. Increase or Decrease Pedal Assist Levels (motor power) 5. Power button. Press and hold until the LCD screen powers up. Press and hold again to power down. eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com... -
Page 12: Right Side Handlebar Controls
*NOTE: This is a Pedal Assist Trike and is meant to be operated using both pedal power and motor assist. Due to the weight of the trike and riders it is not meant to be operated using only the throttle, especially on challenging terrain, inclines, and hills. eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com... -
Page 13: Parking Brake Locks
Both brake levers have a parking brake feature allowing you to lock them in place when you are not riding the trike. These do not work when you are riding. Squeeze the brake lever to fully apply the brakes and then switch the lever to either the lock or un-lock position. eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com... -
Page 14: Battery Installation And Charging
6. When the bike is not in use, charging the battery is still recommend at least once every month; for a minimum of two hours each time. 7. Do not use non eTrikes Canada tested and recommended chargers this will void your Warranty. 8. Only use this charger in a dry, clean, well-ventilated environment out of direct sunlight. -
Page 15: Taking The Batteries On And Off The Trike
Place the bottom of the battery in the mount and then push the top firmly in place until it clicks and locks in. You will need to turn the key on the frame and the locking switch on the battery to do this. eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com... - Page 16 Once in place turn the key to the locked position. Line the tabs on the battery (red arrows) with the notches on the battery mount on the frame (green arrows) Then carefully push down firmly until the battery snaps into place. eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com...
-
Page 17: Operating Instructions
Failing to do so may cause for a noisy and rough gear transition. Do NOT use the throttle while changing gears or applying the brakes or this may damage the system! eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com... -
Page 18: Riding Tips
All our trikes us standard, brand name two-wheel bicycle components. Service and maintenance are the same as any traditional 2-wheel ebike and can be done by any competent bicycle shop. We carry spare parts for all major components in the event anything needs replacing. eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com... - Page 19 Loose or damaged grips on your handlebars are dangerous! If your grip comes off, you could lose control of your bicycle. eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com...
- Page 20 • Lubricating the front axle, rear-axle once every three months. Oil the trike chain and check hydraulic brake fluid at least once every month. eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com...
-
Page 21: Lcd Error Codes
Motor Temperature Warning Check Motor Speed Sensor Issue Check Speed Sensor BMS Issue Check BMS Lighting Issue Check Lights Lighting Sensor Issue Check Lights Parking Brake Engaged Release Parking Brakes Communication Issue Replace LCD Display eee eTrikes Canada contact@etrikescanada.com W: etrikescanada.com...
