Summary of Contents for ARRI RIA-1
- Page 1 RIA-1 Radio Interface Adapter OPERATING MANUAL September 2, 2022...
- Page 2 ARRI products or any other liability arising from the use of such products. No license, express, implied or otherwise, is granted under any patents, copyrights or other intellectual property right of ARRI or others.
- Page 3 Due to continued product development the information in this document may change without notice. The information and intellectual property contained herein is confidential between ARRI and the client and remains the exclusive property of ARRI. If you find any problems in the documentation, please report them to us in writing.
-
Page 4: Table Of Contents
Pinouts....................11 Eternal Interfaces................11 Scope of Delivery and Warranty............12 2.10 Certifications and Safety Standards............ 12 Safety Instructions................15 RIA-1 Overview..................17 Layout....................17 Mounting and Assembly..............18 Attachment of Accessories..............18 Power Supply..................18 Basic Operation................... 20 Switching On and Off................20 Menu Operation...................21... -
Page 5: About This Document
ARRI camera systems, lenses, lights and accessories. Our Advanced Service training courses are designed to transfer detailed knowledge about how to service and repair all types of ARRI products and give you permanent access to detailed Service instructions, special tools and spare-parts. To learn more,... - Page 6 About this Document Further Details For further details, refer For Tech Tips, refer to to the ARRI website at the ARRI website at https://www.arri.com/ria-1 https://youtube.com/user/arrichannel Document Revision History Document ID: 10005933 Version Release Order # Date Description F07684 K5.0039982 September 2,...
-
Page 7: About This Product
About this Product Introduction The RIA-1 Radio Interface Adapter is a hub for the Hi-5 ecosystem. It is capable of functioning as a radio receiver, transmitter, or motor controller. The RIA-1 is a high versatile component of the Hi-5 ecosystem. It is compact and robust, and supports ARRI's exchangeable radio modules. -
Page 8: Identification
The serial number consists of the last 4 digits of the product number K2.0036186-1234. (here: 1234) Environmental Conditions The RIA-1 should only be used and stored under certain environmental conditions. Check the following conditions before commissioning and operation: Electrical Requirements Supply voltage: 10.5 – 34 V DC Operating Temperature -20°... -
Page 9: Technical Data
Measurements (L x W x H) 41 x 53 x 85 mm / 1.61 x 2.09 x 3.35" (RIA-1 body) 41 x 53 x 143 mm / 1.61 x 2.09 x 5.63" (RIA-1 body with RF-EMIP or RF-2400 41 x 53 x 280 mm / 1.61 x 2.09 x 11.02" (RIA-1 body with RF-900) -
Page 10: Dimensional Drawings
About this Product Dimensional Drawings RIA-1 body without radio module. All dimensions in mm. -
Page 11: Pinouts
About this Product Pinouts The RIA-1 contains two LBUS connector (Lemo 4 pin), one CAM connector (Lemo 7 pin) and one SERIAL (Lemo 4 pin). LBUS connector CAN-L V-BAT CAN-H CAM connector CAM lf1 (CAN RS232 RX) CAM lf2 (CAN1-L) -
Page 12: Scope Of Delivery And Warranty
1x K2.0036186 Radio Interface Adapter RIA-1 Body incl. RF-Cover 1x K2.0039465 RIA-1 Bracket Warranty For scope of warranty, please ask your local ARRI Service Partner. ARRI is not liable for consequences from inadequate shipment, improper use or use of third-party products. - Page 13 About this Product EU-Declaration of Conformity Brand Name: ARRI Radio Interface Adapter RIA-1 Product Description: The product conforms to the specifications of the following European directives: Directive 2014/30/EU of the European Parliament and the Council of 26 February 2014 on the harmonisation of the laws of the Member States relating to...
- Page 14 About this Product UK Declaration of Conformity Brand Name: ARRI Radio Interface Adapter RIA-1 Product Description: The designated products conform to the specifications of the following United Kingdom regulations: The Electromagnetic Compatibility Regulations 2016 The Electrical Equipment (Safety) Regulations 2016...
-
Page 15: Safety Instructions
Safety Instructions Safety Instructions This safety information is in addition to the product specific operating instructions in general and must be strictly observed for safety reasons. Read and understand all safety and operating instructions before you operate or install the system. Retain all safety and operating instructions for future reference. - Page 16 Damaged cables can cause electric shock, short circuit or fire. Do not remove or deactivate any safety measures from the system (incl. warning stickers or paint marked screws). Repairs may only be carried out by authorized ARRI service partners. WARNING Falling System Parts If the system is inadequately assembled, it can fall down and cause serious injuries and damage to the system or property.
-
Page 17: Ria-1 Overview
RIA-1 Overview RIA-1 Overview Layout LBUS Interface CAM Interface SERIAL Interface USB-C Interface ROTARY ENCODER Release Lach M4 Mounting Point 3/8" UNC-16 Mounting Point Display... -
Page 18: Mounting And Assembly
Risk of serious injury and/or damage to any connected products. Use only ARRI-recommended cables and power supply solutions. A list of supported cables can be found in the RIA-1 User Manual and on the ARRI website. Do not supply power outside the specified voltage range. - Page 19 ARRI, as they may damage any connected products and invalidate the warranty. ATTENTION The RIA-1 accepts an input voltage range from DC 10.5 to 34 V DC and can be powered through the CAM or LBUS connector. To properly support cforce motors however the RIA-1 requires a voltage of at least 12V.
-
Page 20: Basic Operation
Switch On the RIA-1 Mount the RIA-1. Mount the RIA-1 on the camera, by using the RIA-1 bracket or an L-Bracket. Best radio connectivity is ensured when the RIA-1 is mounted in such a way, that the antenna is pointing upward. To allow short cable paths, connector slots should point towards the lens. -
Page 21: Menu Operation
Menu Operation The ROTARY ENCODER is used to navigate through the menu: Press the ROTARY ENCODER on the RIA-1 to access the menu. Rotate the ROTARY ENCODER to scroll up or down trough the menu. Press the ROTARY ENCODER to select a certain menu entry. -
Page 22: Cleaning And Repair
RIA-1, damage highly polished surfaces. Do not moisten connectors when cleaning the RIA-1. During cleaning of the RIA-1, always make sure that the protective RF-Cover is on the radio module interface. Compressed air should not be used on the RIA-1. -
Page 23: Repair
Cleaning Information Area Cleaning Procedure RIA-1 body Clean the RIA-1 body with a soft, lint free cleaning cloth and some water. Only when really necessary, e.g. to remove resid- uals of tape, isopropyl alcohol should be used. Narrow spaces, Use a manual air blower, cotton swabs or a soft brush to re- gaps, connectors move dust particles from narrow spaces, gaps or connectors. -
Page 24: Transportion And Storage
Follow the specified environmental conditions. Only transport the camera and accessories in suitable cases. Follow the instructions for transport and storage in this chapter. The RIA-1 can be damaged if not transported and stored properly. Please take note of the following guidelines. Transportation Guidelines: Disconnect all cables and power sources from the RIA-1. - Page 25 Always store the RIA-1 in a suitable case. Do not store the RIA-1 outside of the specified ambient temperature range. Do not store the RIA-1 in places where it may be subject to extreme temperatures, direct sunlight, high humidity, severe vibration, dust or strong magnetic fields.
-
Page 26: Disposal
Disposal Disposal ATTENTION The product can be returned to the manufacturer. When disposing of accessories, please observe the relevant manufacturer's instructions. This product falls within the scope of Directive 2012/19 / EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of June 4, 2012 on waste electrical and electronic equipment (WEEE II). -
Page 27: Service Contacts
Service Contacts Service Contacts Munich, Germany Vienna, Austria Arnold & Richter Cine Technik ARRI Cine + Video Geräte Ges.m.b.H. +49 89 3809 2121 +43 1 8920107 30 service@arri.de service@arri.at Business hours: Business hours: Mo. - Fr. 9:00 - 17:00 (CET) Mo.
