- Page 1 FlexTiny 3 Family Instructions for Use NOTICE ESD (Electro Static Discharge) sensitive product. Refer to chapter 1.4 and follow the safety and handling instructions.
- Page 2 Contact Information STAR ELECTRONICS GmbH & Co. KG A Company of the STAR COOPERATION Group Jahnstraße 86 73037 Göppingen Phone: +49 (0)7031 6288-5656 Phone: +49 (0)7031 6288-5330 (Support) Sales: sales-ee@star-cooperation.com Support: support-ee@star-cooperation.com www.star-cooperation.com/ee-solutions Company Data STAR ELECTRONICS GmbH & Co. KG, registered offices: Göppingen, register court Ulm, HRA 721096 Partner liable to unlimited extent: STAR ELECTRONICS Verwaltungs-GmbH, registered offices: Göppingen, register...
- Page 3 Disclaimer The information contained in this document does not affect or change General Terms and Conditions of STAR ELECTRONICS GmbH & Co. KG. STAR ELECTRONICS GmbH & Co. KG does not guarantee the completeness and accuracy of the content of this document and assumes no responsibility for any errors which may appear in this document or due to this document.
- Page 4 Related Hardware Versions Product Reference No. Version Remarks FlexTiny3 FlexRay 3-00880A01 FlexTiny3 CAN-FD 3-00881E01 FlexTiny3 CAN-FDx4 3-00881G01 FlexTiny3 CAN-FDx4 WU 3-00881G02 FlexTiny3 ETH switched 3-00882B01 100BASE-TX FlexTiny3 ETH BR 3-00882C01 100BASE-T1 FlexTiny3 ETH BR 3-00882C02 PCB is 3-00882C01-40 (100BASE-T1) FlexTiny3 ETH BR switched 3-00882D01 100BASE-T1 FlexTiny3 3 ETH BR switched...
-
Page 5: Table Of Contents
Contents General ..............................6 Intended User Group ..........................6 Intended Use ............................6 Used Pictograms ..........................7 Safety and Handling Instructions ......................8 Meaning of Text Styles ......................... 8 Product Description ..........................9 FlexTiny 3 Family at a glance ........................ 9 Accessory Parts ........................... 9 Physical size, assembly ........................ -
Page 6: General
General Intended User Group This document is written for expert technicians and/or engineers who are familiar with electronic components and systems. Each person involved with setup or operation of the product must be a qualified technician or engineer strictly adhere to this manual ... -
Page 7: Used Pictograms
NOTICE The device is not a calibrated measurement device. STAR ELECTRONICS GmbH & Co. KG accepts no liability whatsoever for the correctness of any measurement results. WARNING The FlexTiny3 is NOT designed, intended, or authorized and may NOT be used for or in connection with the following purposes and/or devices: - use as part of medical systems - life support applications... -
Page 8: Safety And Handling Instructions
Product marking which shows the compliance of the product with the European Waste Electrical and Electronic Equipment Directive 2012/19/EU. Safety and Handling Instructions Please read the instructions for use carefully. To protect the device or the application against damage, or to avoid personal injury the FlexTiny 3 Family has to be handled as described herein. -
Page 9: Product Description
Product Description FlexTiny 3 Family at a glance The FlexTiny 3 Family is a series of small interface modules with physical layer drivers. Module information is stored in an EEPROM. The FlexTiny 3 Family modules are connected between protocol devices and the bus cables. - Page 10 FlexTiny 3 Family modules are inverse polarity protected by polarized connectors. NOTICE The FlexTiny 3 Family modules contain EMC filter parts. Anyhow, regarding the high bus frequencies the most bus lines on the carrier board need to be symmetrical and as short as possible. Use cable with differential pair technology for 2-wire-buses to provide noise immunity! Created by STAR ELECTRONICS GmbH &...
-
Page 11: Technical Data
Technical Data Physical Characteristics Connector Panasonic AXK6S60547YG Mounting position no mechanical limitations Dimensions approx. L x W x H 35 * 30 * 10 mm³ Table 1: Physical characteristics Environmental Conditions Operating: -40°C – +85°C Temperature Non-operating: -40°C – +85°C Storage: -40°C –... -
Page 12: 3-00881G01 Flextiny3 Can-Fdx4 And 3-00881G02 Flextiny3 Can-Fdx4 Wu
terminate the buses with 120 ohm per channel, even if the device is not powered. Sleep and wakeup functionality are supported. The bypass for data switched between the Tinys is supported by this Tiny. FlexTiny III FlexRay & CAN-FD to connector pinouts Binder D-sub Signal Name... -
Page 13: 3-00882B01 Flextiny3 Eth Switched (100Base-Tx)
4-channel FlexTiny 3 previous Tiny Switch PHY-C Filter (CAN-FD) Termi- nation PHY-A Filter (CAN-FD) PHY-B Filter (CAN-FD) Termi- nation PHY-D Filter Switch (CAN-FD) Down next Tiny Figure 2: Block diagram for the CAN-FD FlexTiny 3 with 4 channels and bypass switch link 3.3.3 3-00882B01 FlexTiny3 ETH switched (100BASE-TX) The FlexTiny 3 ETH switched is equipped with one 88E6350RA1 transceiver (PHY) from Broadcom, which... -
Page 14: 3-00882D01 Flextiny3 Eth Br Switch (100Base-T1)
FlexTiny III ETH BR connector pinout (100BASE-T1) Binder D-sub Signal Name Description ETH_A_TRD- Ethernet (100BASE-T1) TRD bus minus signal connection of bus A Not connected Not connected Not connected Not connected GND Line Table 6: FlexTiny III ETH BR connector pinout (100BASE-T1) 2-channel BRR FlexTiny 3 previous Tiny PHY-A... -
Page 15: 3-00882G01 Flextiny3 3 Eth Br Switch (100Base-T1)
FlexTiny III ETH BR switch connector pinout (100BASE-T1) Binder D-sub Signal Name Description GND Line Table 7: FlexTiny III ETH BR switch connector pinout (100BASE-T1) 3-channel BRR sw FlexTiny 3 previous Tiny Switch Filter Switch Filter (int. BRR Phy) Filter Switch Down next Tiny... -
Page 16: 3-00882H01/02 Flextiny3 Eth 1G Br (1000Base-T1)
3.3.7 3-00882H01/02 FlexTiny3 ETH 1G BR (1000BASE-T1) The FlexTiny 3 ETH 1G BR is equipped with two 88Q2112-A0 (H01) or A2 (H02) transceiver (PHY) from Marvell, which supports “100/1000BASE-T1” 2 wire 100/1000 Mbit Ethernet signals. The bypass for data switched between the Tinys is not supported by this Tiny. FlexTiny III ETH 1G BR connector pinout (1000BASE-T1) Binder D-sub... -
Page 17: 3.3.10 Short Overview For Pinout
FlexTiny III K-Line/UART/SPI connector pinouts Binder D-sub Signal Name Description K-Line_C K-Line signal connection of bus C Ground signal Ground signal Table 11: FlexTiny III K-Line/UART/SPI connector pinouts 3.3.10 Short overview for pinout The following tables gives a short overview for the pinout for the D-sub and Binder connector. FD-L FD-S 0A01... -
Page 18: Getting Started
Getting Started Assembly and Line-up Read the instructions of the carrier device for more information (see chapter 7.3). Configuration and Operation 4.2.1 Termination Some modules of the FlexTiny 3 Family can terminate the connected network. Be sure that the total network termination is within the network specification. -
Page 19: Shipping, Maintenance And Disposal
Shipping, Maintenance and Disposal Keep the package in which the FlexTiny 3 Family were shipped. Store and transport the FlexTiny 3 Family in a cool, dry, dark environment. Don’t store or transport it near sources of magnetic fields. NOTICE If you want to customize the components of the device, please contact STAR ELECTRONICS GMBH &... -
Page 20: Troubleshooting
Troubleshooting This chapter contains some frequently asked questions about the FlexTiny 3 Family. Effect The Tiny is not functional For FlexDevices or FlexCards where the Tiny may be changed, check if the FlexTiny is Solution properly connected. Created by STAR ELECTRONICS GmbH & Co. KG Date created 2021-11-18 Date modified... -
Page 21: Ordering Information
Ordering Information FlexTiny 3 Family Product Description Ordering number FlexTiny3 FlexRay 2x FlexRay interfaces 3-00880A01-01 FlexTiny3 CAN-FD 2x CAN-FD (HS comp.) interface 3-00881E01-01 FlexTiny3 CAN-FDx4 4x CAN-FD (HS comp.) interface 3-00881G01-01 FlexTiny3 CAN-FDx4 WU 4x CAN-FD (HS comp.) with WakeUp interface 3-00881G02-01 FlexTiny3 ETH switched 2x 100Mbit Ethernet (100BASE-TX) switch... -
Page 22: Appendix
Appendix Appendix A: Guideline for handling ESD sensitive Products Any tester, equipment, or tool used at any production step or for any manipulation of semi- conductor devices must have its shield connected to ground. The product itself and the carrier system of the product respectively must be placed on a conductive table top or covered by an antistatic surface (superficial resistivity equal to or higher than 0.5 MΩ/cm ), grounded through a ground cable (conductive cable from protected equipment... -
Page 23: List Of Tables
8.2.3 List of Tables Table 1: Physical characteristics ......................... 11 Table 2: Environmental conditions ........................11 Table 3: FlexTiny III FlexRay & CAN-FD to connector pinouts ................12 Table 4: FlexTiny III CAN-FDx4 connector pinouts ....................12 Table 5: FlexTiny III ETH-switched connector pinout (100BASE-TX) ..............13 Table 6: FlexTiny III ETH BR connector pinout (100BASE-T1) ................ - Page 24 3-00882C01 and 3-00882H01. Updated reference number for LIN/SENT-Tiny STAR ELECTRONICS GmbH & Co. KG A Company of the STAR COOPERATION Group Jahnstraße 86 73037 Göppingen Germany Phone: +49 (0) 7031 6288-5656 Info@star-cooperation.com www.star-cooperation.com/ee-solutions Created by STAR ELECTRONICS GmbH & Co. KG...
