Summary of Contents for Nonin 2500C
- Page 1 Operator’s Manual Model 2500C Charger Stand English...
- Page 2 MPS, Medical Product Service GmbH Borngasse 20 D-35619 Braunfels, Germany References to “Nonin” in this manual shall imply Nonin Medical, Inc. Nonin and PalmSAT are registered trademarks or trademarks of Nonin Medical, Inc. © 2020 Nonin Medical, Inc. 7923-201-05...
-
Page 3: Table Of Contents
Intended Use ....................1 Warnings ........................ 1 Cautions ......................... 1 Guide to Symbols ..................3 Using the Model 2500C ................. 4 General Description....................4 Unpacking the Model 2500C .................. 5 Operation......................6 To Charge the Battery Pack Using the Charger Stand........... 6 Cleaning...................... - Page 4 Figures Figure 1. Charger Stand and Pulse Oximeter............. 4 Figure 2. Bottom View Showing the Serial Number, Power Supply Connection, and Symbols ....................4 Figure 3. Using the PalmSAT Pulse Oximeter while Charging the Battery Pack..7...
- Page 5 Tables Table 1. Labeling Symbols ..................3 Table 2. Charging Conditions..................6 Table 3. Electromagnetic Emissions ............... 13 Table 4. Electromagnetic Immunity ................. 14...
-
Page 6: Intended Use
Intended Use Intended Use The Nonin Model 2500C Charger Stand is intended for use with the PalmSAT Models 2500 and 2500A Pulse Oximeters and the Model 2500B Rechargeable NiMH (Nickel Metal Hydride) Battery Pack. Warnings Do not use this product in an MR environment. - Page 7 Follow local, state and national governing ordinances and recycling instructions regarding disposal or recycling of the product and product components, including batteries. Use only Nonin-approved battery packs. In compliance with the European Directive on Waste Electrical and Electronic Equipment (WEEE) 2002/96/EC, do not dispose of this product as unsorted municipal waste.
-
Page 8: Guide To Symbols
Guide to Symbols Guide to Symbols This table describes the symbols that are found on the Model 2500C and in this manual. Table 1: Labeling Symbols Symbol Description Caution! Consult Instructions for Use. Follow Instructions for Use. UL Mark for Canada and the United States with respect to electric shock, fire, and mechanical hazards only in accordance with UL 60601-1 and CAN/CSA-C22.2 No. -
Page 9: Using The Model 2500C
Using the Model 2500C Using the Model 2500C General Description To use, place a PalmSAT Pulse Oximeter containing a rechargeable battery pack into the charger stand. Next, connect the charger power supply to the charger, then plug the power supply into an appropriate AC power source (wall outlet). -
Page 10: Unpacking The Model 2500C
• 1 Model 2500B Rechargeable NiMH Battery Pack • 1 Power Supply* • 1 Model 2500C-INS Operator’s Manual (on CD) Confirm that the items listed are included in the package. If any item on this list is missing or damaged, contact your distributor. Contact the carrier immediately if the shipping carton is damaged. -
Page 11: Operation
NOTES: • The NiMH battery pack must be fully charged before the first use. • Various Nonin-specified power cords are available for use with certain power supplies. See “Accessories” on page 11 or contact your distributor. • It is normal for the battery pack and charger to become warm during the charge cycle. - Page 12 Operation Figure 3: Using the PalmSAT Pulse Oximeter while Charging the Battery Pack...
-
Page 13: Cleaning
Cleaning Cleaning To Clean the Charger Stand 1. Unplug the power supply from the AC power outlet. 2. Clean the product with a soft cloth dampened with isopropyl alcohol. Do not pour or spray any liquids onto the product, and do not allow any liquid to enter any openings in the product. -
Page 14: Service
Fax: +31 (0)13 - 79 99 042 E-mail: technicalserviceintl@nonin.com www.nonin.com All non-warranty work shall be done according to Nonin standard rates and charges in effect at the time of delivery to Nonin. All repairs include a complete retest of the Model 2500C using factory test fixtures. -
Page 15: Warranty
Warranty Warranty For warranty information go to: http://www.nonin.com/warranty/... -
Page 16: Accessories
For more information about Nonin parts and accessories: • See the Parts and Accessories List on the Operator’s Manual CD. • Contact your distributor or Nonin at (800) 356-8874 (USA and Canada), +1 (763) 553-9968, or +31 (0)13 - 79 99 040 (Europe). -
Page 17: Troubleshooting Guide
Nonin Technical Service. If these solutions do not correct the problem with your product, please contact Nonin Technical Service at (800) 356-8874 (USA and Canada), +1 (763) 553-9968, or +31 (0)13 - 79 99 040 (Europe). -
Page 18: Technical Information
Manufacturer’s Declaration Essential Performance Essential performance of the 2500C, when used in conjunction with the Model 2500 or Model 2500A, is defined as SpO2 accuracy and pulse rate accuracy or an indication of abnormal operation. Accuracies may be affected as a result of exposure to electromagnetic disturbances that are outside of the environments listed in the Indications For Use. -
Page 19: Table 4. Electromagnetic Immunity
Technical Information Table 4. Electromagnetic Immunity Immunity Test Compliance Level This device is intended for use in the electromagnetic environment specified in the Indications For Use. Electrostatic Discharge (ESD) ±8 kV contact IEC 61000-4-2 ±15 kV air Electrical Fast Transient/Burst ±2 kV for power supply lines IEC 61000-4-4 ±2 kV for input/output lines... -
Page 20: Specifications
Technical Information Specifications Charge Time 180 minutes Power Requirements 12 VDC / 1.5 A Charge Indicator Bicolor LED (green, amber) -20 to +40 C (-4 to +104 F) Temperature (Operating) Temperature (Storage/Transportation): -40 to +70 C (-40 to +158 F) Humidity (Operating) 10 to 90% noncondensing Humidity (Storage/Transportation): 10 to 95% noncondensing...
