- Page 1 User Manual LANCOM 1630 SDSL ELSA AG Communication Systems Sonnenweg 11 52070 Aachen Germany www.elsa.com User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 1/33...
-
Page 2: Table Of Contents
The Router is not accessible from the LAN..........5 Questions regarding the Router’s configuration..........6 ELSA LANCOM Support..................7 Questions regarding the Access Product............7 Overview of the LANCOM 1630 SDSL ..............8 LAN Interfaces ....................8 WAN protocols....................9 Other features....................9 Operations philosophy .................. - Page 3 PPP over Ethernet (PPPoE) ............... 32 12.6.1 Configuration settings................32 Manual configuration (bridging) ..............33 13.1 LAN Configuration ..................33 13.2 WAN configuration Bridged Ethernet (RFC 1483 bridged) ......33 13.2.1 Configuration settings................33 User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 3/33...
-
Page 4: Getting Started
The SDSL Link is established, when the SDSL-Link LED is permanently green. Please contact your SDSL-Provider in case all of the above has been checked, but the SDSL-Link cannot be established. User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 4/33... -
Page 5: The Lan-Link Does Not Work
The Router is not configured yet (ex factory, or after RESET) ▪ The ELSA LANconfig (on CD-ROM) will find the Router automatically (power on the device when it is connected to a LAN). This requires that the TCP/IP protocol stack is installed on your computer, and that the protocol is bound the network interface card is use. -
Page 6: Questions Regarding The Router's Configuration
The reference manual can be started via the link „Help (Reference Manual)“ at the bottom of the web server’s start page User Manual ▪ The user manual (what you are reading) can be found on the CD-ROM (PDF format). User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 6/33... -
Page 7: Elsa Lancom Support
+44-207 294 0114 ▪ Phone: ELSA LANCOM support From inside Germany, the ELSA LANCOM support can be reached via 0180-500-5125 (0.12 € per minute) 3.1 Questions regarding the Access Product... Depending on your Access Provider, additional services such as e.g. Internet homepages, e-mail addresses or static IP addresses can be part of the access product. -
Page 8: Overview Of The Lancom 1630 Sdsl
TCP/IP Router or bridge for SDSL and G.shdsl ▪ IPSec based VPN upgrade option (LANCOM VPN option kit) ▪ Easy management with ELSA LANconfig, incl. setup wizards and presets ▪ Monitoring and connection logging with ELSA LANmonitor ▪ IP Masquerading (NAPT) and inverse masquerading ▪... -
Page 9: Wan Protocols
“Bridge” connected to “Plain Ethernet” interface ▪ “Ethernet” connected to “Bridge” ▪ Optional: “Router” connected with “Bridge” enables an IP address assignment in order to support easy management and monitoring with ELSA LANtools User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 9/33... -
Page 10: Operations And Management
“a.b.c” is given by your local network’s settings. The device can be found automatically with ELSA LANconfig when powered up connected to a LAN. Please ensure that the address “a.b.c.254” is part of the local subnet (e.g. net mask “255.255.255.0”), and that the address is not initially used otherwise. -
Page 11: Configuration
5.2 Configuration 5.2.1 Configuration with ELSA LANconfig ELSA LANconfig is provided as part of the standard ELSA LANCOM SW package. Currently supported are all actual Microsoft Windows operating systems 5.2.1.1 The Setup Wizards The following Setup Wizards are available in this SW release: The “Basic settings…”... -
Page 12: Device Management With Elsa Lanconfig
The Wizards can be run from the Tools menu manually, too: 5.2.1.2 Device management with ELSA LANconfig ▪ ELSA LANCOM devices are found automatically ▪ Multiple different devices can be grouped together ▪ Multiple devices can be configured at once - simply select the desired devices... -
Page 13: Multi-Cpe Configuration
▪ If multi-configuration is enabled, and tables are being edited, the new values can either be merged in, or diff’ed out. User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 13/33... -
Page 14: Configuration With Elsa Webconfig
5.2.2 Configuration with ELSA WEBconfig Lists and modifies device settings in an interactive session ▪ Set the language under “Settings / General” ▪ Set the “expert modus” under “Settings / General” User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 14/33... -
Page 15: Configuration With Tftp Command Line
TFTP [IP-Addr] GET [Password]readconfig c:\Old.cfg TFTP –I [IP-Addr] PUT [Password]writeconfig c:\New.cfg 5.2.4 Configuration with TELNET command line Lists and modifies device settings in an interactive session Examples: TELNET [IP-Addr] User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 15/33... -
Page 16: Configuration With Serial Connection
Requires terminal program (such as Windows HyperTerminal) 5.2.6 Plug and Play Setup with USB The LANCOM 1630 SDSL is automatically detected as soon as the USB connection is established. After successful installation (you have to provide the path to the ELSA LANCOM CD with the USB drivers), the USB connection is presented as a standard Ethernet LAN interface on the PC. - Page 17 User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 17/33...
-
Page 18: Device Monitoring With Elsa Lanmonitor
After installation of the USB drivers, this interface is represented to the PC as an additional Ethernet interface. 5.3 Device monitoring with ELSA LANmonitor ELSA LANmonitor provides various information regarding the actual device status. User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002... - Page 19 The connections can be logged as well User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 19/33...
-
Page 20: The Ipsec Vpn Option
Background information regarding IPSec based VPNs can be found in the reference manual of the ELSA LANCOM VPN option kit. 6.1.1 VPN installation with ELSA LANconfig ELSA recommends the easy to use setup wizard „Connect two local area networks...“ to set up VPN connections. The following parameters are required: ▪... -
Page 21: Manual Vpn Configuration
0.0.0.0 0.0.0.0 10.1.1.0 255.255.255.0 IPSec Branch1 In this example, all packets for a network 10.1.1.x are transmitted with IPSec encryption to the VPN remote site ‘branch1’. User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 21/33... -
Page 22: 'Back-To-Back' Operation
2.3 Mbps can be achieved over distances up to 3.5 km. In this case, one LANCOM 1630 SDSL is required on each end of the 2-wire line – one in the “Central Office Mode (CO)” mode, and one in the “Customer Premises Equipment (CPE)”... -
Page 23: Led Encodings
USB LAN Link established Link USB- Green USB LAN packet transmission (Rx/Tx) Data Green flashing Establishing VPN tunnel (LANCOM VPN Option) Green VPN tunnel established (LANCOM VPN Option) Otherwise User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 23/33... -
Page 24: Usage Of The Reset Switch
(see configuration access). Preferable upload methods would be either via ELSA LANconfig, or via ELSA WEBconfig. The ELSA FirmSafe supports dual firmware image for safe Flash-ROM updates. In case of unsuccessful firmware uploads – e.g. by unforeseen power-outage or damaged upload images –... -
Page 25: Settings Of The Provider Specific Presets
The LANCOM 1630 SDSL offers two different configurations for each provider, which belong as follows to the number and type of IP addresses from your provider. 11.1 Dynamic or static IP addresse(s)? The features of the LANCOM 1630 SDSL depend on the type and number of IP addresses. IP adresse(s) -
Page 26: Standard" Configuration
IP (DMZ) Local netzwork 10.x.x.x Branch office coupling (LAN) (IPSec-VPN) LANCOM 1630 SDSL Internet Branch office coupling (IPSec-VPN) Secure VPN tunnel LANCOM DSL/I-1611 Office Ethernet-Ethernet Router (VPN optional) User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 26/33... -
Page 27: Qsc Specific Preset
The Multi-IP configuration can be found as a preset configuration on the LANCOM CD-ROM ▪ After configuration upload, the LANCOM 1630 SDSL must be configured with the serial connection then (LANconfig or terminal program). ▪ The static IP addresses for the servers within the DMZ will be assigned automatically via DHCP. -
Page 28: Riodata Specific Preset
Multi IP configuration in order to re-enable the “Basic settings….” Wizard ▪ The public IP addresses for the servers within the DMZ have to be entered within the „Basic settings…“ setup wizard then User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 28/33... -
Page 29: Manual Configuration (Routing)
Communication: Connections: Plain IP: Add Name VPI VCI PCR Type Encapsulation IPOA1 5000 UBR Communication: Connections: Router interfaces: Add Name Status IP address Net mask Gateway IPOA1 Enabled 192.168.3.2 255.255.255.0 192.168.3.1 User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 29/33... -
Page 30: Plain Ethernet Over Atm
Communication: Connections: Plain Ethernet: Add Name VPI VCI PCR Type Encapsulation EOA1 5000 UBR Communication: Connections: Router Interfaces: Add Name Status IP address Net mask Gateway EOA1 Enabled 192.168.3.2 255.255.255.0 192.168.3.1 User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 30/33... -
Page 31: Ppp Over Atm (Pppoa)
If IP address must be configured manually: ▪ Preset IP-address as desired Communication: Connections: Router interfaces: Add Name Status IP address net mask Gateway PPPOA1 Enabled 192.168.3.2 0.0.0.0 0.0.0.0 User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 31/33... -
Page 32: Ppp Over Ethernet (Pppoe)
If IP address must be configured manually: ▪ Preset IP-address as desired Communication: Connections: Router interfaces: Add Name Status IP address Net mask Gateway PPPOEOA1 Enabled 192.168.3.2 0.0.0.0 0.0.0.0 User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 32/33... -
Page 33: Manual Configuration (Bridging)
PC 1 Router 1 13.2.1 Configuration settings Communication: Connections: Plain Ethernet: Add Name VPI VCI PCR Type Encapsulation EOA1 5000 UBR Communication: Connections: Bridge interfaces: Add Name Status EOA1 Enabled User manual LANCOM 1630 SDSL Copyright ELSA AG, 2002 Page: 33/33...
