Summary of Contents for Axis Aperio
- Page 1 Configure Aperio™ Wireless locks within AXIS Camera Station June 15, 2023 Rev. 1.0 © Axis Communications AB...
-
Page 2: Table Of Contents
Step 1 – Adding/updating & setting up devices To add the devices To update the devices To setup the devices Step 2 – Connecting the Aperio Hub and wireless locks To connect the devices To create doors Considerations and limitations... -
Page 3: Introduction
Short description of the topic Introduction This document will show you how to configure Aperio ™ wireless locks within AXIS Camera Station, set up related doors and cardholder management. Prerequisites AXIS Camera Station 5.54 AXIS Door Controller 11.6.16.1 Aperio™ locks configured to Aperio™ hub via the PAP tool Please note that Axis doesn’t take any responsibility for how this configuration may affect your... -
Page 4: Step 1 - Adding/Updating & Setting Up Devices
To add the devices Follow these steps if you need to add the devices: 1. In Axis Camera Station open the configuration tab via the “+” symbol found at the top of the screen. 2. From the left menu select “Devices” and under this drop-down select “Add Devices”... -
Page 5: To Update The Devices
To update the devices Follow these steps to update your devices: 1. In Axis Camera Station open the configuration tab via the “+” symbol found at the top of the screen. 2. From the left menu select “Devices” and under this drop-down select “Management”... -
Page 6: To Setup The Devices
To setup the devices Follow these steps to setup your devices: 1. In Axis Camera Station open the configuration tab via the “+” symbol found at the top of the screen. 2. From the left menu select “Devices” and under this drop-down select “Management”... - Page 7 Short description of the topic 5. Next to setup is the time & date on the device, we do this but right clicking on the device in Devices – Management and selecting “Set Date and Time…” 6. In the pop-up select yes, In the next pop-up under “Time Mode” choose the first option, “Synchronize with server computer time”...
-
Page 8: Step 2 - Connecting The Aperio Hub And Wireless Locks
To connect the devices Follow these steps to connect the hub and locks: 1. In Axis Camera Station open the configuration tab via the “+” symbol found at the top of the screen. 2. Select Devices – Management and in the list click on the IP address link on the controller you have connected to the Aperio™... - Page 9 In the pop-up window select the RS485 port that has the Aperio hub connected, you can then choose if you wish to give the hub a “nice name”. 7. After you will see the option to connect the locks you have paired already via the Aperio application by clicking the “+ Connect wireless lock”...
- Page 10 Short description of the topic 8. In the next pop-up select the lock address from the drop-down, once selected you can give this lock a “nice name” and using the tick options below enable any functions the chosen lock has, then click save, you can repeat this for all locks that will be connected to this hub.
-
Page 11: To Create Doors
To create doors Follow these steps to create doors: 1. In Axis Camera Station open the configuration tab via the “+” symbol found at the top of the screen. 2. Expand the “Access control” section and select “Doors and zones” in this page select the “+ Add door”... - Page 12 Short description of the topic 4. On the next page under Overview card, select the wireless lock you paired with the hub via the dropdown. And choose the identification profile you wish to use with the door, you can create a custom identification profile. (Please visit the User Manual for how to create this) 5.
- Page 13 6. On the Doors and zones overview page you can now see the configured wireless door, this page also displays the battery status of the lock and if the lock is currently online or offline. For more information on how to configure access management please see the user manual found at AXIS.com...
-
Page 14: Considerations And Limitations
AXIS door controllers only support the AH30 Wired hub . • Up to 16 wireless locks per controller. • Locks required to be configured to the Aperio Hub via Aperio’s software prior to following this guide. • Up to 2 Aperio Hubs per controller.
