Installation, Programming and
Maintenance User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pooltec and is the answer not in the manual?

Questions and answers

Summary of Contents for MICRODOS Pooltec

  • Page 1 Installation, Programming and Maintenance User Guide...

  • Page 2: Table Of Contents

    PROBES AND INJECTIONS..........................8 3.2. ELECTRICITY ....................................9 3.2.1. ELECTRIC CONNECTION OF THE CONTROL UNIT ....................9 3.2.2. CONNECTING UP THE MAIN PUMP TO MICRODOS POOLTEC ................10 3.2.3. FRONT PANEL OPENING/CLOSING ........................10 3.2.4. INTERCONNECTIONS ............................11 3.2.4.1. PH-RX MP2-B PUMPS .............................. 12 3.2.4.2.
  • Page 3 STARTING UP ....................................... 49 6.1. DEFAULT CONFIGURATION ................................ 49 6.2. RECOMMENDED TIME SCHEDULE FOR PRIVATE/PUBLIC POOLS ................... 50 MAINTENANCE OF THE MICRODOS POOLTEC ............................ 50 7.1. MAINTENANCE AND CONTROL PANEL ............................50 7.2. BATTERY REPLACEMENT ................................51 INCOMPATIBILITIES ..................................... 51...
  • Page 4 The electronic plans have been damaged because of external causes such as whatever type of over tensions. At the end of the 24 months from the delivery date, Microdos will be free from any liability and from all the duties as above. This guarantee, that starts from the 1st of January 2006, nullifies and substitutes whatever guarantee, expressed or implicit, and cannot be modified but in writing.

  • Page 5: Important Safety Instructions

    By touchscreen and passwords (expert and installer) Type of programming User-friendly and intuitive WARNINGS FOR GENERAL OPERATION OF MICRODOS POOLTEC VERIFY PROGRAMMING AFTER UPTDATING THE DEVICE: TIME PROGRAMMING, PH AND RX SET POINTS, HEATING, ETC... ACCESS CODE – For menus and special functions:...

  • Page 6: Microdos Pooltec Content

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 2. MICRODOS POOLTEC CONTENT 2.1. INCLUDED ITEMS 1 x CONTROL UNIT 1 x TEMPERATURE PROBE 2.2. OPTIONS PH KIT 1 x pH Peristaltic/Solenoid Pump 1 x pH Probe 2 x Buffer Solution (7 / 9 pH)

  • Page 7: Accessories

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 2.3. ACCESSORIES ENVIRONMENTALLY FRIENDLY FLOW SENSOR LEVEL SENSOR GRIPPING COLAR DESCALING 2.4. MICRODOS POOLTEC DIMENSIONS 2.5. MICRODOS POOLTEC PANEL DIMENSIONS...

  • Page 8: Microdos Pooltec System Installation

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 3. MICRODOS POOLTEC SYSTEM INSTALLATION 3.1. PLUMBING ORIENTATIVE DIAGRAM 1. Control unit 5. pH tank 9. Inlet water 13. Recirculation pump 2. Peristaltic/solenoid pumps 6. Chlorine tank 10. Outlet water 14. Swimming pool 3.

  • Page 9: Electricity

    4. Motor guard We remind installers that Microdos POOLTEC has only one power input, which goes from the control unit to the main power grid. We must be careful not to connect the pump or any component to the main power supply.

  • Page 10: Connecting Up The Main Pump To Microdos Pooltec

    VERY IMPORTANT CONTACTOR 110-230V POOLTEC CIRCULATION PUMP If the recirculation pump already has a timer, do not connect it to POOLTEC or set it to manual (24 hour operation). 3.2.3. FRONT PANEL OPENING/CLOSING OPENING To access the connection compartment it is necessary...

  • Page 11: Interconnections

    Rev. 1.0 EN 3.2.4. INTERCONNECTIONS Below we see the connections that can be made with Microdos POOLTEC. All connections are without electric current, except: the dosing pumps (PH, P1,P2,P3,P4), mains supply (POWER) which are electrically POWERED. The voltage output depends on the mains input. If the mains is 230VAC, the peristaltic pump output will be 230VAC.

  • Page 12: Ph-Rx Mp2-B Pumps

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 3.2.4.1. PH-RX MP2-B PUMPS 3.2.4.2. PH-CL CG CL3 MP2-B PUMPS...

  • Page 13: Ph-Cl Cp Mp2-B Pumps

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 3.2.4.3. PH-CL CP MP2-B PUMPS 3.2.4.4. PH-RX mA PUMPS...

  • Page 14: Ph-Cl Cg Cl3 Ma Pumps

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 3.2.4.5. PH-CL CG CL3 mA PUMPS 3.2.4.6. PH-CL CP mA PUMPS...

  • Page 15: Programming The Control Unit

    HOME PAGE: REAL-TIME INFORMATION Connect MICRODOS POOLTEC to a mains socket, wait until the screen starts up (IT MAY SOMETIMES BE NECESSARY TO WAIT A FEW MINUTES). Once the system has started up, the first thing you will see is HOME PAGE, from which you can operate the touch-screen’s buttons.

  • Page 16: Icons

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.2. ICONS Programming buttons: Functioning buttons: Buttons: Programs, Settings. Auto, Manual Buzzer, Help, Stand-by By pressing the “HIDE ADVANCED CONTROLS” button, you can minimise the second row to display information about IDN/MODEL/TIME.

  • Page 17: Auto Functioning

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.3. AUTO FUNCTIONING By using the button, the system will work automatically in accordance with the operating program, settings and set-points entered. NOTE: When working in Automatic Mode, the Home Page background colour is BLUE.

  • Page 18: Manual Functioning

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.4. MANUAL FUNCTIONING By using the button, from navigation at any time, you will access the MANUAL page. From this page you can display the real-time state of the inputs and outputs of the device and simply by a touch you can activate and deactivate an output (PUMP, HEAT, pH pump, ett.) for example for priming.

  • Page 19: Programming The System

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5. PROGRAMMING THE SYSTEM To configure the various function of MICRODOS POOLTEC, you can access the programming in 2 different ways: Programming buttons: Programs, Settings. By holding the buttons down, you can access...

  • Page 20: Autotemp

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN There are five possible operating programs for the recirculation pump. Operation will depend on the water temperature. The system measures the water temperature after 2 minutes from the filtration beginning and AUTOTEMP automatically calculates the operating time of the pump.

  • Page 21: User Program

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.2.2. USER PROGRAM Configure up to 3 daily timers to program the activation of the recirculation pump. NOTE: 1. To activate the program: With a short press on the day, you access in the settings for the selected day.

  • Page 22: Public Pool

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.2.3. PUBLIC POOL Keep the recirculation pump on 24 hours a day. Recirculation PUMP 24hours a day. NOTE: Always press SAVE to make the modification effective.

  • Page 23: Winter

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.2.4. WINTER NOTE: Only the recirculation pump works. Configure up to 3 daily timers to program the activation of the recirculation pump. 1. To activate the program: With a short press on the day, you access in the settings for the selected day.

  • Page 24: Settings

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.3. SETTINGS Programming button: Settings. By holding the buttons down, you can access corresponding settings channel change commands. When you access the Settings Menu, you can find 2 different sub-menus: allows to program all the...

  • Page 25: General

    Flow alarm operation is normally open. VERY IMPORTANT NOTE: menu “ NO PROGRAM” is ON, the recirculation pump is independent from POOLTEC and in case of a flow alarm on If in POOLTEC, this will stop dosing and all the outputs dependent on water flow.

  • Page 26: Measurement (Ph, Rx, Cl) Function (Basic/Expert)

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.3.3. MEASUREMENT (PH, RX, CL) FUNCTION (BASIC/EXPERT) By pressing the measure button, a window like this will appear: Visualization in the home page. Enables/disables the chemical dosing. Setpoint – desired value. No dosing.

  • Page 27: Probes Calibration

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.3.4. PROBES CALIBRATION 4.5.3.4.1. CALIBRATING THE PH PROBE Press the STAND-BY button. Unscrew the probe holder base, take out the pH probe and insert it into buffer solution pH7 (supplied with the system).

  • Page 28: Calibrate The Rx Probe

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.3.4.2. CALIBRATE THE RX PROBE Press the STAND-BY button. Unscrew the probe holder base, take out the RX probe and insert it into buffer solution 468mV (supplied with the system). With the probe in the 468mV solution, wait for the stabilization of the measurement. Once the measure is stable, Press the “Calibrate”...

  • Page 29: Calibrate The Amperometric Chlorine Probe

    It is recommended to do the gain calibration after at least 2 or 3 hours of optimal working conditions, or alternatively it is possible to do a first gain calibration after having installed Microdos Pooltec and the probe in the plant and then perform the definitive calibration after 24 hours of working of the probe.
  • Page 30 Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN On device: Press the “Calibrate” button inside the CL settings menu. Insert the EXPERT PASSWORD (11222) to enter the calibration procedure. The window will appear as the following: NOTE: it is possible to exit from the calibration procedure simply pushing “CANCEL.”...

  • Page 31: Calibrate The Potentiostatic Chlorine Probe

    It is recommended to do the gain calibration after at least 2 or 3 hours of optimal working conditions, or alternatively it is possible to do a first gain calibration after having installed Microdos Pooltec and the probe in the plant and then perform the definitive calibration after 24 hours of working of the probe.
  • Page 32 Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN On device: Press the “Calibrate” button inside the CL settings menu. Insert the EXPERT PASSWORD (11222) to enter the calibration procedure. The window will appear as the following: NOTE: it is possible to exit from the calibration procedure simply pushing “CANCEL.”...

  • Page 33: Temperature

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.3.5. TEMPERATURE Choose Centigrade degrees or Fahrenheit degrees. Using ▲ ▼it is possible to Real time temperature, measured in the water correct the temperature (same as home page) value by adding an offset.

  • Page 34: Auxiliary Outputs Configurable Types

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.3.6. AUXILIARY OUTPUTS CONFIGURABLE TYPES Inside this menu you can Inside this menu you can set up the functioning of Px configurable set up the functioning of POWERED OUTPUTS. Dx configurable DRY CONTACT OUTPUTS.

  • Page 35: Microdose Type

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN With a short press on the day, you access in the settings for the selected day. With a second short press on the day, the timer you activate the timer on that day (blue colour).

  • Page 36: Repeat Type

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.3.6.3. REPEAT TYPE This type of output repeats the functioning of the selected inputs or outputs (one or more). The output is activated when an input or an output among the chosen ones is activated.

  • Page 37: Dry Auxiliary Outputs

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.3.6.4. DRY AUXILIARY OUTPUTS Inside this menu you can set up the functioning of Lights and D1/D2 configurable Dry Outputs. IMPORTANT: DRY CONTACTS ARE FREE OF POTENTIAL (RELAYS) WITH A PROTECTION OF 5 AMPERES.

  • Page 38: Heating Function

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.3.6.6. HEATING FUNCTION Program the daily activation of the HEATING program. Enter the values of MIN and MAX temperature thresholds required to start up and shut down the heater. Once the temperature reaches the value of the maximum temperature, heater will shut down and, when it falls to the minimum, it will start up again.

  • Page 39: Ma Output (Optional)

    Rev. 1.0 EN 4.5.3.7. mA OUTPUT (OPTIONAL) It is possible (OPTIONAL) to add up to 2 milliamperes (mA) outputs to connect the Microdos Pooltec to regulation pumps that are controlled by 0/4 – 20mA standard: Select the initial scale value 0mA or Select the measure that you want 4mA.

  • Page 40: Config Menu

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.3.8. CONFIG MENU NOTE: To configure these output types, please consult your Installer. Inside this menu you can display the setup of the configurable Inputs and Outputs. No changes are allowed to the user inside this Menu. Modifications are only allowed to the...

  • Page 41: Device Settings

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.4. DEVICE SETTINGS 4.5.4.1. SET THE SLEEP TIMER OF THE SCREEN The unit has an automatic screen stop system as a function of time that you can program. The screen will then turn off, but the unit will continue to operate normally.

  • Page 42: Date And Time

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN Wi-Fi CONNECTION To establish the internet connection via Wi-Fi: Turn on the Wi-Fi Press the “FIND SSID” button A list of Wi-Fi networks available for connection will appear in the side box.

  • Page 43: Changing The Language

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN MANUAL: If the system is not connected to the internet, you can choose the MANUAL MODE. Press the MANUAL button. First of all set the time zone and then set date and time manually. Press SAVE to make the modification effective.

  • Page 44: Update Software (Download)

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.4.6. UPDATE SOFTWARE (DOWNLOAD) Download and install system updates. For the correct installation of the software: Choose if you want to DOWNLOAD the update from USB or from the pooltec-pro.com server.

  • Page 45: Measurement History

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 4.5.4.8. MEASUREMENT HISTORY History of measurements recorded every 30 minutes It is possible to display PH, REDOX, CHLORINE, TEMPERATURE measurement value graphics of: The day. The week. The month. It is strongly necessary to delete samples at least every 6 months.

  • Page 46: Pooltec Pro

    NEW USER REGISTRATION Click on Register as costumer Fill in all the fields (username, password, e-mail) and then click on Register Wait for the confirmation email sent by postmaster@pooltec-pro.com (check the SPAM folder). To continue registration click on the link.

  • Page 47: New Device Registration

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN Fill in all the fields (name, address, etc.), accept the terms and then click on Register. 5.1.2. NEW DEVICE REGISTRATION Do the Login by entering your username and password. Click on DEVICES and then on ADD NEW DEVICE.

  • Page 48: App

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 5.2. 5.2.1. ANDROID APP Download the app from the Google Play https://play.google.com/store/apps/details?id=com.hustay.swing.d6b234b5ea2814363a9b6bd4a236d74d8&gl=IT 5.2.2. IOS APP To install the App on your iPhone: 1) Open Safari 2) Go to www.pooltec-pro.com 3) Touch 4) Select “Add to Home”...

  • Page 49: Starting Up

    Installation, Programming and Maintenance Microdos Pooltec Rev. 1.0 EN 6. STARTING UP DEFAULT CONFIGURATION 6.1. FUNCTIONING MODE AUTO/MANUAL AUTO PROGRAM SET AUTOTEMP USER PROGRAM PUBLIC POOL WINTER NO PROGRAM GENERAL SETTINGS: REPORT GENERAL FLOW ALARM PH PRIORITY DECALCIFICATION RX DEPENDENCE...

  • Page 50: Recommended Time Schedule For Private/Public Pools

    RECOMMENDED TIME SCHEDULE FOR PRIVATE/PUBLIC POOLS 6.2. For the Pooltec system to be efficient, we need to remember that the hours of daily operation depend directly on the water temperature. The higher the temperature, the greater the number of hours of operation required.

  • Page 51: Battery Replacement

    The device has a buffer battery inside to keep the date and time in memory when it is not powered. To replace the battery it is necessary to open the cover and access the internal compartment. 8. INCOMPATIBILITIES Microdos POOLTEC is fully compatible with any other treatment apart from chlorine, bromine, active oxygen, etc…...
