BCS-8xx series
I
nstallation and
C
M
onfiguration
anual
Version 1.73 – March 2022
BT-Lab

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCS-8 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BioLogic BCS-8 Series

  • Page 1 BCS-8xx series nstallation and onfiguration anual  Version 1.73 – March 2022 BT-Lab...
  • Page 3 Certificate of Conformity Bio-Logic Science Instruments SAS certifies that all goods detailed below have been inspected and tested, and unless otherwise stated, conform to the order of the customer, the drawings and published specifications. Instruments used to calibrate the equipment are traceable to NIST Standards. CE and UKCA certificates are available in chapter 11...
  • Page 4 Contact Bio-Logic Science Instruments You can find Bio-Logic Instruments contact or Representative for warranty, service or tech- nical support by clicking on the following link: https://www.biologic.net/contact/ Headquarters Bio-Logic SAS Web: www.biologic.net Phone: +33 476 986 831 Fax: +33 476 986 909...
  • Page 5 Safety and Legal Information To avoid injury to an operator the safety precaution given bellow, and throughout the manual, must be strictly adhered to, whenever the equipment is operated. Only ad- vanced user can use the instrument. Bio-Logic SAS accepts no responsibility for accidents or damages resulting from any failure to comply with this precaution.
  • Page 6 Avoid Unsafe Equipment The equipment may be unsafe if any of the following statements apply: Equipment shows visible damage, Equipment has failed to perform an intended operation, Equipment has been stored in unfavourable conditions, Equipment has been subjected to physical stress. If there is any doubt as to the service ability of the equipment, do not use it.

  • Page 7: General Safety Considerations

    General safety considerations This product is a Safety Class 1 instrument, which means it has a protective earth terminal. That terminal must be connected to earth ground through a power source equipped with an earth ground. Before installation or operation, check the power supply and review this guide for safety warnings and instructions.
  • Page 8 Symbols Used NOTE: The following symbols may appear within the documentation or on the appliance. Caution This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instruc- tions in the literature accompanying the appliance. Dangerous Voltage This symbol is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclo-...

  • Page 9: Table Of Contents

    BCS-8xx series installation manual Table of contents Certificate of Conformity ....................i Contact Bio-Logic Science Instruments ............... ii Safety and Legal Information ..................iii General safety considerations ..................v Introduction of the product range ..................4 How to read this manual? .................... 6 Modules description.....................
  • Page 10 BCS-8xx series installation manual ® BT-Lab software installation ..................32 Errors during the installation ..................35 PC installation and configuration ................35 3.3.1 TCP/IP installation and configuration ..............35 Connecting the PC with the instrument ................. 38 Network parameter configuration with the Ethernet connection ......... 38 ...
  • Page 11 BCS-8xx series installation manual 9.1.2 DC verification: Dummy Cell DC-BCS ..............68 9.1.3 Calibration: BCS-Cal ....................68 Data saving ....................... 69 PC Disconnection ...................... 69 Effects of computer save options on data recording ..........69 Appendix .......................... 70 10.1 Simplified Electrical split-phases diagrams ..............70 10.2 Electrical Schematic Documentation .................

  • Page 12: Introduction Of The Product Range

    BCS-8xx series installation manual 1 Introduction of the product range Historically, the first battery tester built by Bio-Logic was a multi-channel instrument. It was designed to study intercalated ion compounds with long experiment times due to slow diffu- sion coefficients. Since that time, many improvements have been made. Following in the steps of our first multi-channel instrument, the BCS-8xx series is a newly developed multi-channel instrument specifically designed for battery cycling.
  • Page 13 BCS-8xx series installation manual Fig. 2: BCS-8xx modules. From top to bottom: BCS-805, BCS-810, and BCS-815. Each BCS-8xx module has 8 channels. Additionally for the BCS-810 and BCS-815, 8 tem- perature probes (K-type thermocouple) are available in standard. For the BCS-805, no tem- perature probe is available.

  • Page 14: How To Read This Manual

    BCS-8xx series installation manual 1.1 How to read this manual? The aim of this manual is to guide the user through the instrument’s installation and configu- ration. This manual is composed of several chapters. The first part is a general description of the instruments. The second and third parts describe the hardware installation and how to install the software and how to configure the computer.

  • Page 15: Bcs-Com Front Panel Detailed Description

    BCS-8xx series installation manual Once the techniques have been loaded and started from the PC, the experiments are entirely under the control of the BCS-8xx’s on-board computer. The BCS-COM temporarily buffers data and regularly transfers them to the PC, which is used for data storage, on-line visualiza- tion, on-line and off-line data processing and display.

  • Page 16: Bcs-Com Rear Panel Detailed Description

    BCS-8xx series installation manual 1.2.1.2 BCS-COM rear panel detailed description A description of the rear panel of the BCS communication module is given below: Table 2 : Detailed BCS-COM rear panel description Item Description Item Description A to H : Low Power Relay: Not available RJ45 connectors communication, connect to Logical opto-coupler output (normal open con-...

  • Page 17: Bcs-805 Rear Panel Detailed Description

    BCS-8xx series installation manual Table 3: Detailed BCS-805 front panel description Item Description Item Description Cell on/off : Module identification: Button with LED, when blue, the voltage cell power is ON Ventilation grid: Channel number with status channel LED indicator. Detailed Air moves through the openings description, see below.

  • Page 18: Bcs-810 Module

    BCS-8xx series installation manual 1.2.3 BCS-810 module A BCS-810 module is referred to a letter (from A to P) and has eight channels numbered from the left to right (Fig. 8).The letter is located in the left of the front panel (in the white square), between the Cell on/off button and the ventilation grid.

  • Page 19: Bcs-810 Rear Panel Detailed Description

    BCS-8xx series installation manual LEDs associated to each channel are pre- The channel error (blinking red led) may be due sent on the front panel (1 to 8). These LEDs indicate the status of the channel as A cell voltage higher than 10V follows: A cell voltage lower than 0 V ...

  • Page 20: Bcs-815 Module

    BCS-8xx series installation manual or at the end of the experiment. It is used to start or stop an experiment on another instrument. The Trigger signals have high and low levels: + 3.5 V < Trigger high level < + 5 V 0 V <...

  • Page 21: Bcs-815 Front Panel Detailed Description

    BCS-8xx series installation manual 1.2.4.1 BCS-815 front panel detailed description Figure 12 below corresponds to a scheme of the front panel of the BCS-815. Detailed de- scription is given in table 7. Fig. 12: BCS-815 front panel detailed description. Table 7 : Detailed BCS-815 front panel description. Item Description Item...

  • Page 22: Bcs-815 Rear Panel Detailed Description

    BCS-8xx series installation manual 1.2.4.2 BCS-815 rear panel detailed description Table 8: Detailed BCS-815 rear panel description. Item Description Item Description Open IN: Com: Open relays of all the channels Communication input, should be con- when contact closed or logical nected to the BCS-COM (refer to the zero input (TTL level) appropriate module letter)

  • Page 23: Bcs-Pdu Front Panel Detailed Description

    BCS-8xx series installation manual Logic line (UPS) Power line Emergency stop CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN ATTENTION RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR Serial # Bio-Logic SAS www.bio-logic.info Mode l: BCS-PDU Made in France Power line: Logic line (UPS): 3 Phases 40 A 100-260 Vac...

  • Page 24: Bcs-Pdu Rear Panel Detailed Description

    BCS-8xx series installation manual Table 9: Detailed front panel description. item Description item Description 10A Circuit Breaker for Power line 10A Circuit Breaker for Power line Module A Module B 10A Circuit Breaker for Power line 10A Circuit Breaker for Power line Module C Module D 10A Circuit Breaker for Power line...

  • Page 25: Power Strip

    BCS-8xx series installation manual of Operation cable (JC1F) be connected to BCS-COM module) Logic Line outputs outlets for module Power Line outputs outlets for mod- A up to H and BCS-COM ule A up to H (Female) J17F Warning !: Warning !: Dangerous voltage (depending of the Dangerous voltage (depending of the...

  • Page 26: Software Features

    BCS-8xx series installation manual With BCS-805 and BCS-810, no BCS-PDU is needed because the required power for these modules is relatively low and does not justify a three-phase power supply distribution. The eight channels of a BCS-810 require the same power as one channel of a BCS-815. It is possible to connect different models of BCS-8xx modules to the same BCS-COM.

  • Page 27: Getting Started

    BCS-8xx series installation manual 2 Getting Started 2.1 Hardware installation 2.1.1 Preparing the physical installation of BCSC-38U and BCSC-24U cabinets Questions YES NO Has the incoming electrical power been taken into account? (1) Is the grounding system compatible with the recommendation (2)? Has the power dissipation of the cabinet been taken into account? Have the environmental specifications been taken in count? (Room tempera- ture, room humidity, pollution degree, EMC environment...)

  • Page 28: Ventilation Requirements

    BCS-8xx series installation manual 2.1.3 Ventilation Requirements The BCS-8xx units must be installed at least 0.8 m from the wall. Fig. 21: Ventilation requirements for BCSC cabinets. 2.1.4 Electrical Plugs Caution: We strongly recommend to use National Plug conform to national or IEC standard to con- nect the power cable to the Electrical installation.
  • Page 29 BCS-8xx series installation manual BCSC Cabinet with European PDU (EU version) Three-Phases Plug/Receptacle Countries BCSC-24U BCSC-38U 32A IEC60309 (3P+N+E) 63A IEC60309 (3P+N+E) Legrand 5pins 32A(3P+N+E) 63A IEC60309 (3P+N+E) 32A IEC60309 (3P+N+E) 30A Korean 3 phase (3P+N+E) 63A IEC60309 (3P+N+E) BS 4343 5pins 32A (3P+N+E) 63A IEC60309 (3P+N+E) 32A IEC60309 (3P+N+E) Using IEC60309 International plug/receptacle:...

  • Page 30: Unpacking And Inspection Of Bcsc-38U/Bcsc-24U Cabinets

    BCS-8xx series installation manual 2.2 Unpacking and Inspection of BCSC-38U/BCSC-24U cabinets  Weight is 280 kg for BCSC-38U and 180 kg for BCSC-24U cabinet including four BCS-815: Lifting tools are needed!  Crush hazard! : Take care when unpacking (two persons are needed). The packing of the BCSC-38U and the BCSC-24U cabinets have been designed to facilitate the unpacking.

  • Page 31: Unpacking Procedure When Using A Forklift

    BCS-8xx series installation manual 2.2.2 Unpacking procedure when using a forklift Remove the lid and rim protection Remove the top cover CAUTION! Insert the forklift under the package from the back side and lift until the floor is up – take care to not put the forklift on the screws.

  • Page 32: Bcsc Cabinets Installation

    BCS-8xx series installation manual CAUTION: Two men are required, the first to retain the cabinet, the second to push the cabinet Do not forget to place the shim red) un- der the ramp Push slowly the cabinet to go down Fig.

  • Page 33: Electrical Equipment Requirements

    BCS-8xx series installation manual 2.3.1 Electrical equipment requirements The electrical requirements for installation of the BCSC cabinets with a PDU-Unit, in Europe, in the USA/Canada and in Japan are described in Table 11. Table 11. Electrical equipment requirements BCSC-24U BCSC-38U BCSC-12U BCSC-6U 3 Phases + N + PE...

  • Page 34: Bcs-Pdu Electrical Connections

    BCS-8xx series installation manual 2.4 BCS-PDU electrical connections Two different PDU versions are available, one for North American and one for European electrical system. WARNING! Never use the North American PDU with European electric system: the phase splitting is different: EU is line to neutral (230 VAC), US is line to line (208 VAC). The PDU unit must be connected to three-phase electric power.

  • Page 35: North American Model

    BCS-8xx series installation manual 2.4.2 North American model (Split phase line to line) (in 10.2 Appendix) exhibits a three-phases split simplified diagram Fig. PE: Protective N: Neutral L1: Line 1 L2: Line 2 L3: Line 3 Earth G (Phase 1: X) (Phase 2: Y) (Phase 3: Z) (Not used)
  • Page 36 BCS-8xx series installation manual can be used to connect the BCS-COM and BCS-805/810 modules. The connection has to be made to the logic line part only. The BCS-PDU offers two types of power supply: the Logic Line (UPS) and the Power Line. The communication module is connected to the PDU unit via a Logic Line.

  • Page 37: Communication Connections

    BCS-8xx series installation manual 2.6 Communication Connections The communication module, BCS-COM, is connected (via Ethernet connections) to the com- puter/s and to the BCS-8xx modules via RJ45 ports. On the front panel the communication module there is one Ethernet port for connection be- tween the computer and the instrument.

  • Page 38: Direct Ethernet Connection

    BCS-8xx series installation manual By default, the IP address of the instrument is 192.109.209.128. The USB port available on the front panel of the communication module is disabled and used only for service. 2.6.2.1 Direct Ethernet connection Connect the computer directly to the instrument with the Ethernet cable. The IP addresses of both devices have to be in the same network.
  • Page 39 BCS-8xx series installation manual Fig. 30: Network connection. One instrument to several PCs. Alternatively, a single PC can control several instruments through the network. Fig. 31: Network connection. One PC to several instruments.

  • Page 40: Software Installation On The Computer

    BCS-8xx series installation manual 3 Software installation on the computer ® Before turning on the instrument, it is recommended to install the BT-Lab software on your PC. For this operation, insert the CD-ROM in the computer. The installation is automatically launched with the “Autorun”...
  • Page 41 BCS-8xx series installation manual Fig. 34: BT-Lab® software installation. Step 3. Fig. 35: BT-Lab® software installation. Step 4.
  • Page 42 BCS-8xx series installation manual During the installation, two main folders are created.  “BT-Lab.exe”, TeraTermPro and other files are located in the in the “Program Files” directory.  “Batch”, “Data” (include the data samples), “Documents” (include manuals and getting started document), “Newsletter”, “Settings” (includes the default settings files), “Temp”...

  • Page 43: Errors During The Installation

    BCS-8xx series installation manual The USB driver installation is not necessary to control the BCS-8xx instruments. This con- nection is only available for factory service. 3.2 Errors during the installation During the installation an error may occur if you are not administrator of the computer. In this case it is necessary to contact your network administrator for the installation.
  • Page 44 BCS-8xx series installation manual 2- On the “General” tab click on Properties. This will load the follow- ing window: Fig. 38: Local Area connection status 3- Select Internet Protocol (TCP/IPv4 or TCP/IPv6) and click on the Properties button. The window on the left appears. Fig.
  • Page 45 BCS-8xx series installation manual 4- At this point of the installation, the user has to activate the “Use the following IP address” box. ARNING THERE MIGHT BE ANOTHER TCP " PROTOCOL INSTALLED CALLED IP DIS- ", TANT ACCESS DO NOT CLICK ON THIS LINE 5- Enter the PC IP address, DO NOT EN- (it will automati-...

  • Page 46: Connecting The Pc With The Instrument

    BCS-8xx series installation manual 4 Connecting the PC with the instrument 4.1 Network parameter configuration with the Ethernet connection The Ethernet connection on the communication board is a 10/100 baseT compatible with any network. When it is installed in a Local Area Network (via the Ethernet connection), the in- strument is automatically detected by the computers of the network.
  • Page 47 BCS-8xx series installation manual 2) In the “Devices” frame, click on the “+” button to add the instrument of in- terest in the list. ® Only one session of BT-Lab needed to control several instru- ments. Fig. 42: “Devices” frame for connec- tion.

  • Page 48: Modification Of The Instrument Ip Address

    BCS-8xx series installation manual 5) The instrument selected appears in the list displayed in the “Device” frame. Then, the connection is estab- lished automatically. Fig. 44: “Devices” frame for connection with the new device. 6) Note if the instrument is already in the list, the user has to select the instrument in the “Device”...

  • Page 49: Windows Security Alert

    BCS-8xx series installation manual indicating that the communication module is reinitialized with the new IP Address. “Configu- ration changed” appears at the bottom of this window. Then click “OK” to display the “New Device” window where you have to click “Refresh” to refresh the window and select your instrument IP address.

  • Page 50: Connection To A Battery Cell

    BCS-8xx series installation manual 5 Connection to a battery cell The cell cables have to be connected to the front panel of the BCS-8xx module and then to the cell. In the first section of this chapter, the cell cable to front panel connection is de- scribed, followed by the connection between cell cable and the cell.

  • Page 51: Bcs-805/810 Cell Cables

    Fig. 50: BCS-810 front panel and structure of the connector. Fig. 51: BCS-810 cell cable. 5.3 BCS-8xx battery holders Numerous battery holders are available to connect batteries to BCS-8xx modules. For more information, please check our website: www.biologic.net...
  • Page 52 BCS-8xx series installation manual CCH-124 (left) and CCH-120 (right) coin cell holder for BCS-805/810. CCH-1 four points coin cell holder for BCS-805/810. CCH-8 8 positions coin cell holder for BCS-805/810 PBH-125 pouch cell holder clamp for BCS-8xx. BH-1i 4 positions cylindrical cell holder for BCS-8xx.

  • Page 53: Cell Cable To A Battery Cell

    BCS-8xx series installation manual 5.4 Cell cable to a battery cell. This paragraph explains how to connect a channel to a cell using the standard cables pro- vided with the instrument. In the standard configuration, a cell cable has four leads which connect to the electrochemi- cal cell: two leads which carry current (power leads, banana plug 4mm) and 2 which meas- ure the potential (sense leads, banana plug 2 mm).

  • Page 54: Advanced Features

    BCS-8xx series installation manual 6 Advanced features 6.1 Control and measurement modes The BCS-8xx technology is designed to be able to work in DC mode and in AC mode. The DC mode controls the current or the voltage in a linear mode. Pulses, staircases and sweeps can be applied in voltage, current, power and load mode to the cell.

  • Page 55: Virtual Bcs-8Xx

    BCS-8xx series installation manual Fig. 56: Cell description in Cell Characteristics tab. 6.3 Virtual BCS-8xx  The user can work with the BT-Lab software without being connected to an instrument. In this case, the software sees a virtual BCS-8xx (BCS-815, BCS-810 and BCS-805) that is not available for experiments but can be used as a user’s interface.
  • Page 56 BCS-8xx series installation manual Fig. 58: Virtual BCS window.

  • Page 57: Maintenance

    BCS-8xx series installation manual 7 Maintenance WARNING! Read this chapter before performing any maintenance.  7.1 Firmware Upgrade/Downgrade with BT-Lab software HEN A USER RECEIVES A NEW UNIT FROM THE FACTORY CURRENT VERSIONS OF THE SOFTWARE AND FIRMWARE ARE ALREADY INSTALLED THE INSTRUMENT IS READY TO BE USED IT DOES NOT NEED TO BE UPGRADED...
  • Page 58 BCS-8xx series installation manual 3) Open “Firmware Upgrade/Downgrade” tool in the “Tools” menu ig. 61: Firmware Upgrade/Downgrade tool in the “Tools” menu. 4) The window displays the pathway of the current firmware flash (here: v1.10). NOTE: The flash file is located in the “Program files” directory. Fig.
  • Page 59 BCS-8xx series installation manual Fig. 63: Flash location in the BT-Lab folder. The pathway of the flash of the ver- sion v1.30 shown in the “Firmware grade/Downg rade” win- dow. Fig. 64: “Firmware Upgrade/Downgrade” window. 7) Click on the “Load” but- ton.
  • Page 60 BCS-8xx series installation manual 8) The grade/downg rade process starts “Upgrad- ing...” pears on the bottom of the window (but the firmware really downgrad- ed). Fig. 66: Flash loading. Fig. 67: Upgrading message on the status bar. 9) Close the “firmware downgrading/upgrading” window and the v1.10. The upgrading procedure is now completed and you can connect the older version to the instrument.

  • Page 61: Ventilation

    BCS-8xx series installation manual 7.2 Ventilation The user must carefully check that the ventilation grids are not obstructed on the rear of the cabinet. An external cleaning of the front dust-filter should be periodically made with a Vacu- um cleaner if necessary. Replacement has to be done periodically as well. 7.3 Fuses WARNING! To maintain protection from Fuse location...

  • Page 62: Power Contour Plot For Bcs-805

    BCS-8xx series installation manual 7.4.1 Power contour plot for BCS-805 BCS-805 can be provided with coin cell holders or with cell cables (contact us for more de- tails). The figures below show the power contour plots for cell cables with 0.5 m length.

  • Page 63: Power Contour Plot For Bcs-810

    BCS-8xx series installation manual 7.4.2 Power contour plot for BCS-810 BCS-810 can be provided with coin cell holder or with cell cable (contact us for more details). The figures below show the power contour plots for cell cable with 0.5 m length.

  • Page 64: Power Contour Plot For Bcs-815

    BCS-8xx series installation manual 7.4.3 Power contour plot for BCS-815 BCS-815 can be provided with cell cables of different length. The figures below show the power contour plots for 0.3 m, 2.5 m, 5.0 m and 10 m cell cables in standard configuration and with 0V option.
  • Page 65 BCS-8xx series installation manual...
  • Page 66 BCS-8xx series installation manual...

  • Page 67: In Case Of Any Problems

    BCS-8xx series installation manual 7.5 In Case of any Problems Information on your hardware and software configuration is necessary to analyze and finally solve the problem you encounter. If you have any questions or if any problem occurs, that is not mentioned in this document, please contact your local retailer.

  • Page 68: Technical Specifications

    BCS-8xx series installation manual 8 Technical Specifications 8.1 Electrical specifications For more information, please see Section 2.3.1. Electrical equipment requirements Instrument Voltage and power Input Voltage and current Output type Voltage Frequency Power Voltage Max Current/A per Range/ Fuses range/Hz max/W range channel...

  • Page 69: Mechanical Specifications

    BCS-8xx series installation manual 8.2 Mechanical specifications Instrument type Size (HxWxD)/mm Weight /kg BCS-815 176x446x462 BCS-810 88x446x403 BCS-805 44x446x403 BCS-COM 88x446x403 BCS-PDU 176x446x342 6U cabinet 350x550x600 12U Cabinet 610x550x600 24U cabinet 1360x600x610 38U cabinet 1870x600x610...

  • Page 70: Environmental

    BCS-8xx series installation manual 8.3 Environmental Indoor use Operating Temperature: 5°C to +40°C Indoor use (max power derating starts at 23°C and is dependant of cell cable length – see power contour plot in ch. 7.4) Storage Temperature: 0°C to +50°C Pollution degree: 2 (normally only non-conductive pollution occurs) Altitude: <2000 m above sea level Humidity: 10% to 80% non-condensing for temperatures up to 31 °C decreasing...

  • Page 71: Bcs-815 Specifications

    BCS-8xx series installation manual 8.4 BCS-815 Specifications General Functions BCS-815 module Number of channel Cell connection 4 terminal leads Power 1700 W, 100-240 VAC*, 50-60 Hz Cell Control Compliance Standard: 0-9 V (2-7 V without 0V) Maximum current ±15 A continuous* Maximum potential See Power Contour Plots ch.

  • Page 72: Bcs-810 Specifications

    BCS-8xx series installation manual 8.5 BCS-810 Specifications General Functions BCS-810 module Number of channel Cell connection 4 terminal leads + Ground Power 220 W, 100-240 VAC, 50-60 Hz Cell Control Compliance 0-10 V Maximum current ±1.5 A continuous Maximum potential 10 V Potential resolution 150 µV...

  • Page 73: Bcs-805 Specifications

    BCS-8xx series installation manual 8.6 BCS-805 Specifications General Functions BCS-805 module Number of channel Cell connection 4 terminal leads+ Ground Power 60 W, 100-240 VAC, 50-60 Hz Cell Control Compliance 0-10 V Maximum current ±150 mA continuous Maximum potential 10 V Potential resolution 150 µV Current resolution...

  • Page 74: Pc Requirements

    BCS-8xx series installation manual 8.8 PC requirements Minimum specifications: - Processor Intel® Core i5 - 8 GB RAM - 250 GB Solid State Drive (SSD) - Screen resolution 1920x1080 - Ethernet board 1000 base T - Discrete Graphic Card - Windows Vista, 7, 8, 10 (32 or 64 bits).

  • Page 75: Troubleshooting

    BCS-8xx series installation manual 9 Troubleshooting 9.1 Control / measurement issues 9.1.1 EIS verification: Dummy Cell BCS To verify the working state of the EIS option of your instrument, it is possible to use the DC- BCS Dummy Cell. This Dummy Cell is only designed for verification purpose, and is not ac- curate enough to be used as a metrological standard.

  • Page 76: Dc Verification: Dummy Cell Dc-Bcs

    BCS-8xx series installation manual 9.1.2 DC verification: Dummy Cell DC-BCS Fig. 70: Dummy cell DC-BCS 9.1.3 Calibration: BCS-Cal Fig. 71: BCS-Cal calibration kit...

  • Page 77: Data Saving

    BCS-8xx series installation manual As the accuracy of all measuring devices degrades over time and use, regular calibrations are highly recommended. The BCS-CAL is an automated calibration kit for the BCS-8xx se- ries. It has been designed to perform fast verification and calibration, and outputs NIST traceable certificates.

  • Page 78: Appendix

    BCS-8xx series installation manual 10 Appendix 10.1 Simplified Electrical split-phases diagrams Fig. 68: Simplified split-phase diagram for European PDU. Fig. 69. Simplified split-phase diagram for North American PDU...

  • Page 79: Electrical Schematic Documentation

    BCS-8xx installation manual 10.2 Electrical Schematic Documentation 10.2.1 USA/CAN PDU model: Power Line...

  • Page 80: Usa/Can Pdu Model: Logic Line

    BCS-8xx series installation manual 10.2.2 USA/CAN PDU model: Logic Line...

  • Page 81: European Pdu Model: Power Line

    BCS-8xx installation manual 10.2.3 European PDU model: Power line...

  • Page 82: European Pdu Model: Logic Line

    BCS-8xx series installation manual 10.2.4 European PDU model: Logic line...

  • Page 83: Electrical Symbols Used

    BCS-8xx installation manual 10.3 Electrical Symbols used...
  • Page 84 BCS-8xx series installation manual...

  • Page 85: Ec And Ukca Declaration Of Conformity

    BCS-8xx installation manual 11 EC and UKCA declaration of conformity...
  • Page 86 BCS-8xx series installation manual...

  • Page 87: Glossary

    BCS-8xx installation manual 12 Glossary This glossary is made to help the user understand most of the terms used in this instrument installation and configuration manual. The terms are defined in alphabetical order. Bandwidth: represents the frequency of the regulation loop of the instrument. It depends on the electrochemical cell impedance.
