Summary of Contents for GFS SMARTDisplay
- Page 1 GfS SMARTDisplay® 770020 GfS SMARTDisplay® 770022 GfS SMARTDisplay® 770024 GfS SMARTDisplay® 770026 GfS SMARTDisplay® Sicherheit an Türen...
-
Page 2: Product Description
12 W opening and sabotage of escape route security solutions such Output 12 V/DC as the GfS EH door monitor, day alarm devices and electric door Current locks are displayed and documented. An input mask can be used Overload protection... - Page 3 PRODUCT DESCRIPTION Lower part Top part 7-inch display Housing screws Spacer/Unit stand Cable entry...
- Page 4 DIMENSIONS 58,5 190,2 184,2 19,9 147,6...
- Page 5 16 units are used. Please read by the power supply unit in the connection box is 16 units. Please the installation instructions for the GfS connection box art. no.: observe the special connection regulations when using external 771457 GfS Junctionbox Art.-Nr.: 771456...
- Page 6 The system automatically recognises the lowest availa- later extensions or modifications. ble number and assigns it to the new interface. GfS SMARTDisplay supplies power to GfS ExitControl179 GfS EH-Türwächter blue –...
- Page 7 CONNECTION BUS/RADIO-BUS GfS SMARTDisplay® Jumper plugged in: E 1 reacts to NC contact, GfS radio BUS interface Art.-Nr.: 990045 E 2 reacts to make contact (Alarm when E 1 open, flashing when E 2 closed) Jumper removed E 1 reacts to make contact ,...
- Page 8 CONNECTION Remove the screws on the left and right of the unit. Now remove the housing cover with the display. Gently lift the clamp on the ribbon cable and carefully remove the ribbon cable. Pull the required cables through the cable entry. Remove the cable connector.
- Page 9 CONNECTION Connect the cable (please note the polarity) and plug the connector back in. Break out the cable entry. Assemble the housing. Remove the protective film from the display.
- Page 10 GfS SMARTDisplay® Sicherheit an Türen << 12:12 12:12 31.08.22 31.08.22 Info 0 ß Ö Ä 12:12 12:12 – 31.08.22 31.08.22 12:12 12:12 31.08.22 31.08.22 +49 40 790 19 50 12:12 12:12 31.08.22 31.08.22...
- Page 11 << 12:12 12:12 31.08.22 31.08.22 12:12 12:12 31.08.22 31.08.22 Start icon for first Siren installation Basic settings Change code Service Date 12:12 31.08.22 List of doors Time Verladetor Blaserei Verladetor Blaserei (Doppeltür) (Doppeltür) Logfile Factory setting Verladetor Blaserei Verladetor Blaserei (Doppeltür) (Doppeltür) Statistics...
- Page 12 COMMISSIONING After you have installed all modules in ascending numbering on the doors and connected the cable to the GfS SMARTDisplay® , you can switch on the device. After switching on, the start screen After the installation is finished, the door list with the detected appears: doors appears.
- Page 13 SETTINGS Door list Door 1 Info E.g. location 0 ß Ö Ä 12:12 12:12 – 31.08.22 31.08.22 To make entries in the door list, press the Home button: You can now name the door and store further information. Pressing the OK button takes you to the next door. Here you make your entries.
- Page 14 SETTINGS Change factory code Set the Date 12:12 12:12 31.08.22 31.08.22 Press the Basic Settings icon Press the Basic Settings icon 12:12 12:12 31.08.22 31.08.22 Press the Change Code icon Press the Date icon (Calendar icon). 7 5 6 8 <<...
- Page 15 SETTINGS Setting the time Switching the alarm tone on and off 12:12 12:12 31.08.22 31.08.22 Press the Basic Settings icon Press the Basic Settings icon 12:12 12:12 31.08.22 31.08.22 Press the symbol for Time Press the Alarm Tone icon 12:12 12:12 31.08.22 31.08.22...
- Page 16 SETTINGS Open log file Open statistics 12:12 12:12 31.08.22 31.08.22 Press the Service icon Press the Service icon 12:12 12:12 31.08.22 31.08.22 Press the symbol for Logfile Press the symbol for Statistics Verladetor Blaserei Verladetor Blaserei (Doppeltür) (Doppeltür) Verladetor Blaserei Verladetor Blaserei (Doppeltür) (Doppeltür)
- Page 17 SETTINGS Calling service number Reset to factory settings 12:12 12:12 31.08.22 31.08.22 Press the Service icon Press the Service icon 12:12 12:12 31.08.22 31.08.22 Press the symbol for Telephone Press the icon for Factory Settings +49 40 790 19 50 12:12 31.08.22 12:12...
- Page 18 ALARMS/NOTIFICATIONS All doors are closed and secured Tür 1 Tür 2 Aussenlager Schlosserei Tür 3 Tür 4 Warenlager Warenlager 1 Tür 5 Tür 6 Rampe Ost Rampe West Tür 7 Tür 8 Notausgang Foyer Notausgang Dachterrasse 12:12 31.08.22 Door 7 reports an alarm Tür 1 Tür 2 Aussenlager...
- Page 19 ALARMS/NOTIFICATIONS Door 2 is permanently open Tür 1 Tür 2 Aussenlager Schlosserei Tür 3 Tür 4 Warenlager Warenlager 1 Tür 5 Tür 6 Rampe Ost Rampe West Tür 7 Tür 8 Notausgang Foyer Notausgang Dachterrasse 12:12 31.08.22 Door 6 reports a sabotage alarm Tür 1 Tür 2 Aussenlager...
- Page 20 GfS – Gesellschaft für Sicherheitstechnik mbH Tempowerkring 15 · 21079 Hamburg Fon +49 40 - 79 01 95 0 · info@gfs-online.com · www.gfs-online.com We accept no liability for printing and typesetting errors. We reserve the right to make price increases, changes and updates.
