Summary of Contents for Regis Calibre
- Page 1 Regis Calibre INSTRUCTIONS...
- Page 2 DOOR FITTING INSTRUCTIONS 1. Begin by opening the drawer and removing all 2. Twist the support arms Anti-Clockwise to loosen 3. Using a posidrive screwdriver, insert screwdriver items from inside. Pull back the dark grey cover clips the support from the door. Locate and remove the into the area shown above and twist 90 away from on the support arm to reveal the thread.
- Page 3 UNIT MOUNTING INSTRUCTIONS Mounting Bracket Adjustment Hanger Clamp 1. Locate and insert the Mounting Bracket (if not already in place). Make sure the Hanger is facing the wall side as displayed in the second image. Unit Inserts Once in position, lever down the Unit Lock to secure the Mounting Bracket as shown in the third image.
- Page 4 DRAW ADJUSTMENT INSTRUCTIONS Important Information • On receipt of any product, ensure that the product is unboxed carefully and inspected Cam adjustment to raise and lower the drawer box for damages or defects, within one day. In the unlikely event that the product is Adjust drawer front left and right damaged please report this to retailer.
