INFINOVO MEDICAL Glunovo p3 CGM Quick Start Manual

Quick Start Guide
Applicator Transmitter
2. Remove the Protective Liners
4. Unlock the Applicator
6. Press the Adhesive Tape
p3 CGM
Sensor Releaser
Press the sensor on one side
and remove the protective
liners, then remove the other
piece of liner carefully.
Insert Sensor
Hold the applicator steady and
slide the safety lock button
from "locked" to "unlocked"
Insert Sensor
Press the sensor and rub
around the adhesive tape, to
make sure it is firmly
attached to your skin
Insert Sensor
1. Choose Sensor Site
3. Place the Sensor
5. Press the Top Button
• Press the insertion button on top of the applicator.
• You could hear a clear snap when it is triggered.
• Then remove the disposable applicator
direction
7. Attach the Transmitter
• Clean the bottom of the transmitter with an alcohol wipe and wait until it dries
completely
• Check the pointy side
• Put the pointy side into sensor base. Then press down one slot into the sensor
base until your hear a clear click sound, then press the other slot until you hear a
click sound
Choose a sensor placement site on
the abdomen
Clean the site with alcohol wipes and
let the area dry completely
• 5 cm away from the belly button
• 5 cm away from the insulin injection site
• Avoid fatty cloting site, tattoos, scars
• Shave the spot if it's hairy
Do not use if the package is damaged or expired!
Insert Sensor
Place the sensor horizontally
on your abdomen, and press
the applicator firmly against
your skin
Insert Sensor
from the insertion
Insert Sensor
and 2 slots side
Insert Sensor
