CleverMic e-Blackboard Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
e-Blackboard
Manual
（2018）

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the e-Blackboard and is the answer not in the manual?

Questions and answers

Related Manuals for CleverMic e-Blackboard

Summary of Contents for CleverMic e-Blackboard

  • Page 1 Manual （2018）...

  • Page 2: Table Of Contents

    Contents 1、Foreword ................2、Safety Instructions ..............3、Router Setup ................4、Introduction to Product Technology ........10 、Specification ..............10 、Function Introduction ........... 10 、Instructions To Remote Control ........15 、Instruction of Gesture Switch ........19 、Power on ............... 19 、Power off............... 19 、Introductions of Energy Conservation ......

  • Page 3: 1、Foreword

    1、Foreword Notice: This product must not be used under the condition of poor ventilation, dust, high temperature, low temperature or chemical substances. 2. This product should be used in the environment with no electromagnetic interference. 3. Strike this product with hard objects is strictly prohibited.

  • Page 4: 2、Safety Instructions

    • Please read and understand all safety instructions and operations before using Smart e-Blackboard. • The user manual of Smart e-Blackboard should be kept for reference. Declaration ： This is the A class product, which may cause radio interference in the living environment. In this case, it may be necessary for users to take practical measures against the interference.
  • Page 5 Before installation, please check the power voltage, wire size, power sockets, fuses or electrical switches meet requirements for Smart e-Blackboard (please refer to the product specifications) Please ensure that product is moved by at least two persons. Otherwise, this product may fall and cause personal injury or be damaged.
  • Page 6 Smart e-Blackboard along the ground 80- 90cm away. For safety in equipment use, the bearer of the Smart e-Blackboard must be sufficiently load-bearing (please refer to product specifications). Authorized or professional staff are requested for installation.
  • Page 7 Do not use hard or sharp objects to write or crash on the Smart e- Blackboard; please correctly use chalk or liquid pen. When cleaning the surface of the Smart e-Blackboard, please power off first and disconnect the power cord.

  • Page 8: 3、Router Setup

    3、Router Setup Note: 1. For windows OS, both cable network and wireless network are set up trough the embedded router. 2. For windows OS,the network icon in the taskbar shows only the connection status. 3. All network changes are made through the router, including wired network/wireless network change,replace wifi connection.
  • Page 9 1、 Change the language. Choosethe blue chinese “语言设置” and change Chinese to English. Choose “保存”(it means save in Chinese). See Fig 2 and Fig 3. Fig 2 Fig 3...
  • Page 10 2、When Fig 3 is saved, please erease IE historical records, reboot IE browser and login in again. See Fig 4. Fig 4 II. Quick Wizard 1、 This is how to access internet through WLAN. See Fig 5. Fig 5...
  • Page 11 III. Connect Hotspot. Set “Repeater Settings”, enable repeater, scan, available wifi will show up. Choose one to connect and wait. It will work after several seconds. See Fig 6. Fig 6...

  • Page 12: 4、Introduction To Product Technology

    Power/W Weight/KG Commodity Dimension/mm Middle Two sides (Full load) 70" Smart e-Blackboard 75" Smart e-Blackboard 4024x1224x90 86" Smart e-Blackboard 、Function Introduction There may be slightly differences in functions, port numbers and operation of different devices. This introduction is only for standard products, please specify the actual product you have.
  • Page 13 Source Switch signal sources. Mute Switch the equipment to silent mode. Turn on or turn off the Smart e-Blackboard. Make sure the Power Windows OS is shut down before turn off the equipment. IR remote control receiver (Located at the middle part of standard Smart e-Blackboard).
  • Page 14 Highspeed USB interface to connect USB devices USB 3.0 with the embedded computer. Touch connector. Connect external devices with TOUCH USB the touch cable to Smart e-Blackboard for bidirectional touch and display. RJ45/NET Network interface to connect with network cable. AUDIO OUT Multimedia audio output port.
  • Page 15 Multimedia signal input port, access to devices with HDMI output such as computer, set-top box HDMI IN 1 or others, with max resolution to 4K. ANDROID Android system upgrade button. UPGRADE Multimedia signal input port, access to devices HDMI IN 2 with HDMI output such as computer, set-top box or others, TV analog signal (A-TV) (optional).
  • Page 16 （3） OSD menu introduction： Instruction: The shortcut window will pop out when the user slides across the LCD screen from bottom to middle with fingers, to switch between Windows OS and Android OS for equipments with dual systems, to switch signal sources, to move down or up signal screen and power off the operation system.

  • Page 17: Instructions To Remote Control

    、Instructions To Remote Control Besides normal function, the Smart e-Blackboard Remote Controller has the function of keyboard and mouse. （1） Keys presentation...
  • Page 18 （2） Remote control function Aim the remote control at the IR receiver, press this key to enter into remote control mode. Function Power Volume Mute Signal source selection Screen parameter selection Direction Selection Enter Escape Backlight control Switch to Android system Switch to embedded computer operation system Switch to HDMI1 signal input...
  • Page 19 (3) Keyboard, mouse mode function Aim the remote control at the IR receiver, press the remote control mode select key . When “Keyboard/Mouse mode” shows on the screen, the remote control is under Keyboard/Mouse mode. Note: Windows operation system will request to save or close some files, please make sure Windows system is shutdown normally before the equipment is powered off.
  • Page 20 Right click Task manager combination Space Escape (4) Operation Instructions Battery installation： I) Open the rear cover of the remote control； II) Install AAA batteries and make sure the positive and negative poles are placed properly. Do not mix old and new batteries. III) Close the battery compartment after the installation and make the buckle bucked.

  • Page 21: Instruction Of Gesture Switch

    Connect the power cord to standard power socket； （2） Press the Power button to switch on the equipment； Note: If the Smart e-Blackboard you purchase does not contain an embedded computer, it is requested to operate as following steps. Before Smart e-Blackboard installation, connect the attached TOUCH cable with USB interface on the external computer.

  • Page 22: 5、Faq And Trouble Shooting

    conservation standard of GB21520-2015 <Energy efficiency limits and energy efficiency ratings for computer monitors> and GB28380-2012 <Microcomputer energy efficiency limit and energy efficiency rating>. 5、FAQ and trouble shooting 、FAQ (1) Why does the PPT file can’t fully covered the screen? For the display ratio of file has been set 4:3, reset the display ratio to 16:9.
  • Page 23 Our eyes can recognize flickers under 50Hz and the eye muscles twinkle constantly to adjust to environment which causes the eyestrain. Smart e-Blackboard equips LCD screens of 60 Hz and 120 Hz which the human eyes can hardly feel screen flashing. So compared with other screens, Smart e-Blackboard is more friendly to vision.The product is in...

  • Page 24: Trouble Shooting

    Make sure the power of Smart e-Blackboard is normal. （4） Can not Power on ① If Smart e-Blackboard can not be powered on with remote control, please check and make sure the remote control is in good condition. ② If the computer can not boot, force it to power off and restart after 15 minutes.
  • Page 25 ① Please restart the Smart e-Blackboard (power off) and try again. ② If there is anti-virus software in the computer, turn it off and try again. (12) If the surface of the Smart e-Blackboard is broken or damaged, please contact your local dealer.

  • Page 26: Disclaimer

    Disclaimer: The following factors are not covered by warranty:  Damages caused by accident, earthquake, fire, flood, lightning or other natural disasters;  Damages caused by unauthorized production modifications;  Losses caused by repair or attempted repair by unauthorized persons; ...

This manual is also suitable for:

Dc750nhDc700nhDc860nhDc650nhDc980nh
