Madrid Dining table
951601
Assembly instructions
Need HELP?
With:Assembly instructions
Missing or damaged parts
CALL:0333 777 8999
Advertisement
Related Manuals for Next Madrid 951601
Summary of Contents for Next Madrid 951601
- Page 1 Madrid Dining table 951601 Assembly instructions Actual product size H732 x W1190 x D1190mm Need HELP? With:Assembly instructions Missing or damaged parts CALL:0333 777 8999 IMPORTANT – RETAIN FOR FUTURE REFERENCE Produced in China for Next Retail Ltd. 887849-2014-V1...
-
Page 2: Before You Start
To view our full furniture range please visit ww w.next.co.uk Do not use glass as a chopping surface. Do not strike the glass with hard or pointed items. Produced in China for Next Retail Ltd 887849-2014-V1... -
Page 3: Getting To Know Your Product
Madrid Dining table 951601 Assembly instructions GETTING TO KNOW YOUR PRODUCT Components supplied. Please use this guide if you require replacement parts. Dimensions Visual Dimensions Visual x79.5mm ￠1190x20mm 48.5x48.5x8mm 704x494x50mm 48.5x48.5x3mm Produced in China for Next Retail Ltd. 887849-2014-V1... - Page 4 Madrid Dining table 951601 Assembly instructions Fixtures and fittings supplied (actual size) Dimensions Spare Qty M8x32 M8x20 ￠30xM8 10mm 14mm Fixtures and fittings supplied (not to scale) Dimensions Visual M6 x 92mm Produced in China for Next Retail Ltd. 680207-2014-V1...
- Page 5 Madrid Dining table 951601 Assembly instructions E=4PCS Don't Fully Tighten Up The Screws In this step. C=8PCS Produced in China for Next Retail Ltd. 887849-2014-V1...
- Page 6 Madrid Dining table 951601 Assembly instructions B=4PCS F=1PC Tighten Up the Screws With Allen Key Produced in China for Next Retail Ltd. 887849-2014-V1...
- Page 7 Madrid Dining table 951601 Assembly instructions A=1PC D=1PC G=1PC Produced in China for Next Retail Ltd. 887849-2014-V1...
