DRIFLOWER HARVEST RACK Assembly Instructions

THE HARVEST-RACK HARDWARE KIT
• ASSEMBLY INSTRUCTIONS •
PARTS INCLUDED
Harvest-Rack™ Hardware:
2 - Harvest-Rack Brackets ...................... ( A )
2 - Harvest-Brackets ..................................... ( B )
PARTS NOT INCLUDED
(
A V A I L A B L E A T H O M E I M P R O V E M E N T S T O R E S
YOU WILL NEED THE FOLLOWING
WOOD
CUT 2 x 3 STUDS TO THE FOLLOWING LENGTHS
8 - 2 ft. pieces ........................... ( X )
(2" x 3" x 24" )
2 - 3-5 ft. vertical posts
(2" x 3" x var.*)
*variable vertical height based on cola/branch length
2 - 5-7 ft. cross-pieces
(2" x 3" x var**)
**variable cross section based on stick length
SCREWS
28 - 1 " Construction Screws .................. ( ¡ ) 1
4 /
1
2 /
24 - 2 " Construction Screws .................. ( ø )
TOOLS NEEDED ( NOT INCLUDED NOT INCLUDED
Power Driver/Drill
Pencil
Tape Measure
Square/Right Angle Square/Right Angle
PREPARE TO BUILD YOUR HARVEST-RACK
WOOD
&
SCREWS
NOT
INCLUDED
The DriFlower Harvest-Rack Hardware Kit is where streamlining
MAKE SURE TO READ ALL OF THESE INSTRUCTIONS
After reading the instructions, cut all wood and make sure you
have the correct size and amount of screws (listed on front page).
After cutting all wood, you will put together the leg assemblies
It is important to use a GUIDE-PIECE during the leg assemblies
The GUIDE-PIECE is temporary and will not be attached so this
can be any of the other 2x3 pieces not being used.
The space the GUIDE-PIECE creates will be used to connect the
Take your time. Measure twice, cut once. This Harvest-Rack is
about to transform the way you harvest your flower!
)
( ¡ )
..... ( Y )
28 screws
..... ( Z )
( ø )
24 screws
( Z )
2 pcs.
)
Begin by cutting 2x3 studs to the above lengths.
The length of the cross-pieces (Z) will be determined by stick length,
so if you're using 8 ft DriFlower Sticks, cut cross-pieces to 84" (7 ft).
Congratulations!
and organizing your harvest begins.
and then the truss assembly.
to set the legs in the correct position.
leg assembly to the truss assembly.
MAKE YOUR CUTS
( X )
8 pcs.
2" x 3" x 24"
( Y )
2 pcs.
2" x 3" x 36" (var.)
2" x 3" x 60" - 84" (var.)
LEG ASSEMBLY
( A )
Lay the Harvest-Rack Bracket ( ) on a flat surface (open-side up)
A
and place a GUIDE-PIECE in the center.
¡
(x3)
( A )
( X ) ( X )
Diagonally place two 2 ft. pieces ( ) into the bracket (
X
until corners touch the GUIDE-PIECE, evenly spaced.
Using six screws ( ¡ ), connect the legs to the bracket (
through the side holes into the legs. Repeat for both brackets.
( FLIP OVER )
¡
(x2)
( X ) ( X )
Reinforce leg strength by inserting two screws ( ¡ ) through the
two holes pictured above. Repeat for both leg assemblies.
(x2) (x2)
ø ø
( X )
Use a 2 ft. piece ( ) across the inside of the leg assembly
X
and connect with screws (ø) to stabilize the Harvest-Rack.
Repeat for both leg assemblies.
¡
(x3)
x2
)
A
)
A
x2
x2
