- Page 1 IG2 Manual (For Use With the 32-175 Control) RBD Instruments, Inc. 2437 NE Twin Knolls Dr Suite 2 Bend, OR 97701 541-330-0723 WWW.RBDINSTRUMENTS.COM...
-
Page 2: Table Of Contents
Install the 04-165 Ion Source Control ................... 10 Remote Switching the Ion Beam ....................10 Opera�ng the IG2 With the 32-175 Controller ................11 32-175 Front Panel Controls and Meter ..................11 Ini�al Out-gassing of the 04-165 Ion Source ................12 Opera�on of the 32-175 Control and 04-165 Ion Source ............. -
Page 3: Safety No�Ces
Safety No�ces The equipment manufactured by RBD Instruments, Inc. (RBD) are designed with considera�on of the safety of those who come in contact with them. Towards this end, we have defined the skills and knowledge that operators and maintenance personnel must have to interact with our products. -
Page 4: Limited Warranty
Limited Warranty RBD Instruments, Inc. (referred to as “Company”) warrants that the product(s) discussed in this document will perform substan�ally in accordance with the accompanying writen materials and will be free from defects in materials and workmanship for the period of one year from receipt by buyer. In the event applicable law imposes any implied warran�es, the implied warranty period is limited to 90 days... - Page 5 The Company recognizes that expendable items may not func�on for the full year covered by this Limited Warranty. Expendable items, such as filaments, grids, special ceramics, and ionizers, are therefore excluded from the Limited Warranty for the specific product of which they are a part. However, each of these expendable items will have its own warranty and will be replaced or repaired in accordance with its warranty.
-
Page 6: Ig2 Introduc�On
Model 04-165 works with the PHI 20-045, and the PHI 04-161 and 04-162 ion guns work with the RBD Model 32-175. This manual discusses the op�ons available for the IG2, the items required to use RBD’s components with corresponding PHI components, as well as differences in opera�on or other aspects of a component’s use. -
Page 7: 04-165 Diagram
04-165 Diagram The diagram below iden�fies the dimensions of the RBD 04-165 as well as its sec�ons. Please note that the ver�cal dimensions reflect the 04-165 dimensions when the op�onal X-Y aligner (RBD part number IG2-EA) is not used. -
Page 8: Rbd Model 32-175 2 Kv Ion Source Control
Model 32-175 2 kV Ion Source Control The Model 32-175 2 kV Ion Source Control provides all the necessary voltages and currents required to operate the Model 04-165 2 kV Backfill Ion Source or the PHI 04-161/162 ion guns. The beam voltage may be ac�vated manually or remotely. -
Page 9: Unpacking The Ig2
Remove all components and inspect them for damage. If there is any damage, please report it to the shipping company immediately. Verify that you have the following items. If any are missing, please contact RBD Instruments at 541-330-0723 or e-mail us at tech@rbdinstruments.com. -
Page 10: Se�Ng Up The Ig2
Se�ng up the IG2 Install the 04-165 Ion Source 1. Perform a resistance check of the 04-165. a. Using an ohm meter, measure the resistance of the pins on the 04-165 ion source. b. The filament pins (A to B and B to C) should show less than 1 ohm of resistance. -
Page 11: Install The 04-165 Ion Source Control
2. Connect the 04-165 Ion Source to the 32-175 Control using the IG2-CA1 cable. 3. Connect the AC power cord (120 VAC OR 230 VAC) to the 32-175 and then plug the AC power cord into the power outlet. -
Page 12: Opera�Ng The Ig2 With The 32-175 Controller
• Emission Meter: Displays the emission current, 25mA nominal. Ini�al Out-gassing of the 04-165 Ion Source IG2 packages and 04-165 Ion Sources newly purchased from RBD have had ini�al outgassing procedure performed. If the 04-165 Ion Source is up-to-air for an extended period of �me a�er ini�al outgassing, follow the outgassing procedure, no�ng that wait �mes may be reduced by 50%. -
Page 13: Opera�On Of The 32-175 Control And 04-165 Ion Source
7. Repeat this process in increments of 5 mA un�l you have 25 mA of emission current. 8. With the emission current s�ll at 25 mA and the Beam voltage set to 500 V, turn the beam voltage ON. 9. Wait 5 minutes and then turn the beam voltage to 1000V. 10. -
Page 14: Using The 04-165 With A Phi 20-045 Control
Cables to Connect RBD and PHI Components The following cables are required for the connec�ons indicated. (Note that if you are connec�ng the RBD 04-165 and the RBD 32-175, you use the IG2-CA1 cable that is included with your IG2 package). Between These Components... -
Page 15: Principles Of Opera�On
Appendix – Cable Diagrams The cable diagram for the cable included with the IG2 is provided in this appendix. We have also included cable diagrams for the optional cables that are available to integrate the RBD 04-165 ion source with the PHI controller and the RBD 32-175 ion source control with the PHI ion guns.
