Enttec 79335 Quick Start Manual

DALI 8A 12-36V LED DIMMER
General Information
•
DALI single channel PWM dimmer
•
Smooth full range logarithmic fade curve tuned
to human vision.
•
This device will require an external DC power
supply for normal operation. (not included)
Features
•
1 channel ultra-high PWM output
•
Screw terminal connections.
•
Two holes for wall mounting.
•
IP20 moulded shell.
Wiring Schematic
DALI Power Supply
1
DALI LED Dimmer
Technical Specifications
Item
Input Voltage
Maximum Current
Max Output Channels
Supported
Control
tion
Connectors
Environment
IP Rating
Installation
•
This product should be installed and serviced by a
qualified person.
•
Do not expose this unit to direct sunlight or
ter. If installed outdoors, ensure it is mounted
within a waterproof enclosure.
•
Never connect any cables whilst the power is on and
always assure correct connections before switching
DALI 8A 12-36V LED DIMMER: 79335
Input voltage 12VDC-36VDC
8A (96-288W)
1
Protocols DALI (IEC 60929 & IEC 62386)
Resolu- 8 bit dimming
(256 graduations)
Screw terminals
Ambient: 20 C to +50 C
Humidity: 0-50% non-con-
densing
IP20
Datasheet (510845)
www.enttec.com
Value
wa-
ID: 2345301 Rev:1
