Summary of Contents for FULGOR M6

  • Page 1 Digital audio matrix with DSP USER AND INSTALLATION GUIDE V3.0 Software da 3.0.0.4 Firmware da 3.0.0.0...

  • Page 2: Detailed Safety Instructions

    PRECAUTION OF USE WARNING: To reduce the risk of electric shock, do not remove the cover (or rear panel). Inside, there are no parts that can be repaired by the user; Entrust the repair to qualified personnel. CAUTION: To reduce the risk of fire or electric shock, do not expose this unit to rain or moisture. This symbol, when displayed, indicates the presence of a non-insulated hazardous voltage inside the body of the device - sufficient voltage to pose a risk of electric shock.
  • Page 3 Failures caused by improper use or tampering are excluded from the warranty. Fulgor Service s.n.c. Features can be modified without any notice...
  • Page 4 Establishes by means of return verification the declared defect, related to proper use, and the effective validity of the guarantee; It then provides for the replacement or repair of the products, but does not however oblige any compensation for direct or indirect damages resulting from the defect. Features can be modified without any notice V2020319...
  • Page 5 M644 DAW in real time 6 Input on 4 Out DESCRIPTION The M6 digital workstation is equipped with 6 balanced audio input (XLR) fully configurable and addressable to one or more of the 4 balanced outputs (XLR). Main electrical characteristics: ...
  • Page 6 STATUS LED LED PRESET STATUS PC INTERFACE PRECISION POTENTIOMETERS BALANCED INPUTS POWER MULTIFUNCTION PORT BALANCED OUTPUTS GROUND LIFT Features can be modified without any notice V2020319...

  • Page 7: Welcome Window

    SOFTWARE WELCOME WINDOW From this window it is possible to select the serial port to connect to the matrix, or perform an off-line configuration, that is, without the device being connected. MAIN WINDOW You can access this window or from off-line configuration or by connecting to the device. Features can be modified without any notice V2020319...
  • Page 8 Detail This window is always visible in any work environment you are; it is thus possible to check inputs and output level and enable/disable the muting function. In the exmaple shown all inputs are open while all the output are in muting condition. To assign a name to an input or output, right-click on the input or output itself.
  • Page 9 From this section it is possible to choose and/or save the presets, select the factory configuration (default) and save. ☝ It is necessary to save frequently in order not to risk losing the change made; when it is stored the tab is partially obscured. From this section it is possible to change the project name, assign a new password (default ****), save the project on the computer, upload a project from...
  • Page 10 Inputs Tab For each input it is possible to adjust/select:  Gain by writing the value or pressing the up-down buttons (min -50 dB max +50dB)  Mute  Phase  24V Phantom power  Managed by automixer  Controlled by a local or remote potentiometer ...
  • Page 11 Fulgor Service Automatic System To activate the automatic control of the inputs, check the box "Abilitato". From this section it is possible to check and/or modify the parameters of the automatic system developed by Fulgor Service and check the status of the inputs.
  • Page 12 INPUT EQ From this section it is possible to view the equalization curve of the various inputs; by clicking on the name of an input, the relevant equalization curve is displayed. �� Each input has a different graph color �� It is possible to scroll the graph by using the mouse wheel ��...
  • Page 13 Filters Editor 3 filters are available for each input: possible select Frequency (Freq.), merit factor (Q) that determins the slope and type of filter, i.e. low- bass (LP) – high-pass (HP) – parametric (EQ) �� By choosing a low-pass or a high-pass merit factor...
  • Page 14 MATRIX From this section it is possible to direct one or more inputs to one or more outputs by selecting the intersections of the matrix “by putting a check mark”. For each intersection it is possible to attenuate the level By clicking on the tab “Azzera tutto”, all the intersections are deleted (none on none) By clicking on the “Imposta tutto”...
  • Page 15 BYPASS From this section it is possible to direct one or more input to one or more output by selecting the intersections of the bypass matrix “by putting a check mark”. This Bypass matrix skips the entire effects path (equalizer – antilarsen - noise gate and delay) by directly connecting the inputs to the outputs.
  • Page 16 OUTPUTS EQ From this section it is possible to display the equalization curve of the various outputs; by clicking on the name of an output, the relevant equalization curve is displayed. �� Each output has a different graph color �� It is possible to scroll the graph by using the mouse wheel ��...
  • Page 17 Filter Editor 6 filters are available for each outputs: possible select Frequency (Freq.), merit factor (Q) that determins the slope and the type of the filter, i.e. low-pass (LP) – hihg-pass (HP) – parametric (EQ) �� By choosing a low-pass or a high-pass merit factor...
  • Page 18 Fulgor Service DELAY Freq type antilarsen (Frequency) bases its functioning on the frequency shift managed by an algorithm developed by Fulgor Service, which uses the principle of traditional analog antilarsen DELAY �� With Phase antilarsen it is suggested to set the “Delay Antilarsen” to 1,8ms. and the “Velocità...
  • Page 19 DELAY From this section it is possible to enable a delay for each output. The delay is expresssed in meters to facilitate the calculation (reference temperature 20°C) �� The maximum delay that can be set is 64 meters equal to approximately 186ms Features can be modified without any notice V2020319...

  • Page 20: Noise Gate

    NOISE GATE From this section it is possible to enable a noise gate for each output by clicking on “on”. The adjustment parameters allow you to set the functioning minimum level, the delay in intervening and the “speed” with which it intervenes. “Soglia Intervento”: between -40dB and +1dB;...
  • Page 21 OUTPUTS From this section it is possible to adjust the level of each ouput. As for the inputs, it is possible to invert the phase (check-mark on “Fase 180”) and decide, if necessary, which potentiometer they should be controlled from. The level is adjustable between -60dB and +6dB ��...
  • Page 22 POTENTIOMETERS From this section it is possible to adjust the intervention level of each potentiometer both internal (front) and external (remote). The level that can be set is between 1 and 90 and expressed in dB The chosen level represents the maximum attenuation that the potentiometer brings to that input or output.
  • Page 23 RECAP From this section it possible to control the flow of signals between inputs and outputs to get a global vision “at a glance” �� The matrix connections are highlighted with the colors of respective output equalizers �� Bypass matrix connections are highlighted in gray color ��...

  • Page 24: Remote Control

    REMOTE CONTROL POT EXT 1 POT EXT 2 POT EXT 3 POT EXT 4 POT EXT 5 POT EXT 6 RS485 A RS485 B 10 V PRESET 1 PRESET 2 PRESET 4 EXTERNAL POTENTIOMETERS DIAGRAM The preset control via RP6 takes place with binary logic on 3 contacts for a maximum, then, of 7 presets that can be recalled.
  • Page 25 PC CONNECTION Use an RS232 female-female cable with a DB9 connector. �� Use good quality USB-SERIAL adapters �� Use the latest versione of Fulgor Service Software �� The default password is 123456 Features can be modified without any notice V2020319...
  • Page 26 ACCESSORIES Connect RP6 using the falt cable supplied on the DB15 “Remote Control” socket The RP6 panel supplied allows you to select the first 6 preset. �� For the first 3 preset there is a “standard” screen printing �� The preset LEDs light up simultaneously to those on the front panel ��...
  • Page 27 M CONTROL (Optional) Equipment included in M Control:  Color Smart Display with touch screen on interface  Metal cabinet  Power supply  DB15 connector �� Enable RS485 from the main window of the software! �� When RS485 is enabled, the binary preset control NO LONGER works ��...

  • Page 28: Preset Change

    To select the preset 2, use the string :0102CP01 and the carriage return character. 01 is the target device address, in this case M6, the number that identifies the destination device can be changed in the appropriate box in the potentiometers window.
  • Page 29 To select and change the volume 2 use the string :0102CV0180 and the carriage return character 01 is the target device address, in this case M6, the number that identifies the destination device can be changed in the appropriate box in the potentiometers window.

  • Page 30: Warranty Certificate

    / or point of sale at which the product was purchased. FULGOR SERVICE has also set up a toll-free number 800-804067. By calling this number we will be able to collect your reports regarding warranty issues and possibly arrange direct return / repair methods.

  • Page 31: Product Data

    Fill in every part and join the product. In the case of warranty, please always enclose a copy of the valid proof of purchase and send the product to the following address: FULGOR SERVICE snc., Via Caduti del lavoro 58, 19021 Arcola La Spezia or fax 01 87 952326.
  • Page 32 The Data Controller is the legal representative of FULGOR SERVICE snc., Via Caduti del lavoro 58, 19021 Arcola - La Spezia. www.fulgorservice.it Date _______________ signature______________ Stamp and signature of the reseller The symbol of a jar of a trash trimmed by a cross indicates that the product should not be disposed of with other household waste at the end of the life cycle, but be collected separately.
