Wireless Nurse Call System
Contents
Infrared Sensor ---------------------------------------------------------------------------
Magnet Sensor ---------------------------------------------------------------------------
Portable Call Button ---------------------------------------------------------------------
Wall Call Button --------------------------------------------------------------------------
Sensor Transmitter ----------------------------------------------------------------------
Sensor Transmitter ----------------------------------------------------------------------
Receiver ------------------------------------------------------------------------------------- 20-23
Portable Receiver ------------------------------------------------------------------------- 24-28
NC-9000 Series
Instruction Manual
2-9
10-11
12
13
14-16
17-19
20181112(US)
Advertisement
Table of Contents
Summary of Contents for Excel NC-9000 Series
-
Page 1: Table Of Contents
Wireless Nurse Call System NC-9000 Series Instruction Manual Contents Infrared Sensor --------------------------------------------------------------------------- (NC-9000TXMS) Magnet Sensor --------------------------------------------------------------------------- 10-11 (NC-9000TXGM) Portable Call Button --------------------------------------------------------------------- (NC-9000TXPB) Wall Call Button -------------------------------------------------------------------------- (NC-9000TXWB) Sensor Transmitter ---------------------------------------------------------------------- 14-16 (NC-9000TXBF) Sensor Transmitter ---------------------------------------------------------------------- 17-19 (NC-9000TXBF_NR) Receiver ------------------------------------------------------------------------------------- 20-23... -
Page 2: Infrared Sensor
Infrared Sensor NC-9000TXMS Distance Sensors (LS / CS / RS) Human Sensors (HS) Infrared Sensor Type A / Type D: Pause Button Type B / Type C: Start Button Top View A/D: Pause Button B/C: Start Button ※ Indicative Lamp AC Adaptor Jack Mode Switch Nurse Call Connector Jack... - Page 3 Features The infrared sensor has four types detection and two types connection. Detection Type: Type A: Detect the movement of patient on the bed, such as get up. Type B: Detect the patient leave from the bed, such as fall over to ground. Type C: Detect the patient who non-return to the bed within set time.
- Page 4 Type A: This type requires human sensor and three distance sensors for detection. When human sensor and one of them distance sensor detected any person move in detective zone, it will be activated. Installation: 2.1.1 Register with receiver. (Refer to the section for Receiver or Portable Receiver.) 2.1.2 Adjust the mode switch to position “0”...
- Page 5 Usage 2.2.1 Connect the power via suitable adaptor. 2.2.2 The PW lamp will light up and the sensor lamp will flash once from HS lamp to LS lamp one by one. That mean is the sensor had readied. 2.2.3 When someone approaches the bed, the HS lamp will flash, but the sensor still won’t be activated.
- Page 6 Installation 3.1.1 Register with receiver. (Refer to the section for Receiver or Portable Receiver.) 3.1.2.1 Type B: Adjust the mode switch to position “4”, “5” or “6”, that three options are depending on desire detection time. (Refer to Mode Data table) 3.1.2.2 Type C: Adjust the mode switch to position “7”, “8”...
- Page 7 Usage 3.2.1 After fix the sensor main unit on the suitable position, press the start button. 3.2.2 HS lamp bright. 3.2.3 The head of patient left the pillow, then the HS lamp off and the AL lamp flash. 3.2.4 If the head of patient back to the pillow within detection time, then the HS lamp bright again and the AL lamp off.
- Page 8 Usage 4.2.1 Connect the power via suitable adaptor. 4.2.2 The PW lamp will light up and the sensor lamp will flash once from HS lamp to LS lamp one by one. That mean is the sensor had readied. 4.2.3 When someone moves in detective zone, the CS lamp bright, then the alarm will be activated.
- Page 9 Mode Data: Detection Sensor Mode Mode Detection Detection Type Human Distance Distance Time 1.22 sec. LS / CS / RS 0.6m / 1.0m / 1.3m 1.66 sec. 0.77 sec. 0.6m / 1.0m / 1.3m 1.22 sec. 2 sec. 0.6m / 1.0m / 1.3m LS / CS / RS 6 sec.
-
Page 10: (Nc-9000Txms) Magnet Sensor
Magnet Sensor NC-9000TXMG Small Clamp Magnet Sensor Transmit Lamp Megnet Unit Spring Knob Features The magnet sensor is designed to alert the caregiver when the patient leaves from bed or wheelchair. When the patient get up, the sensor When the patient fall from the will be activated. - Page 11 Installation ※ Register with receiver. (Refer to the section for Receiver or Portable Receiver.) The sensor main unit need to fix at bed or wheelchair, and magnet unit also hold on the sensor main unit. The small clamp need to clamp the clothes of the patient. Adjust the length of the string appropriately.
-
Page 12: Portable Call Button
Portable Call Button NC-9000TXPB Transmit Lamp CALL Call Button Call Button Usage When press the call button, the transmit lamp will blink once. A pulse alarm signal will be transmitted to receiver. ※Note: The Portable Call Button have to register with receiver before use. Please refer the section for Receiver or Portable Receiver. -
Page 13: Wall Call Button
Wall Call Button NC-9000TXWB CALL Call Button Usage When press the call button, a pulse alarm signal will be transmitted to receiver. ※Note: The Wall Call Button have to register with receiver before use. Please refer the section for Receiver or Portable Receiver. Specification Power Source N-Battery (1.5V) x 2pcs... -
Page 14: (Nc-9000Txwb) Sensor Transmitter
Back View Battery lid Features The NC-9000TXBF is transmitter for Excel’s wireless sensor pad. After connected the wireless sensor pad via min-plug, the transmitter can send the alarm signal to registered receiver. ※Note1: The sensor transmitter have to register with receiver before use. - Page 15 Wireless Sensor Pad Classification Floor mode: When make a pressure to the sensor pad, the alarm will be activated immediate. Floor mode pad sensor includes as: Floor sensor mat Side-rail sensor pad Bed mode: The sensor pad is always under pressure. When the pressure is released from the sensor pad, the alarm will be activated.
- Page 16 Usage Floor Mode: Connect the sensor to min-plug. Put the sensor pad to suitable place. After making a pressure to sensor pad, the sensor transmitter takes 2 seconds to send the alarm signal out. The alarm lamp of sensor transmitter will also blink once.
-
Page 17: (Nc-9000Txbf) Sensor Transmitter
Back View Back Cover Features The NC-9000TXBF_ND is transmitter for Excel’s wireless sensor pad. After connected the wireless sensor pad via min-plug, the transmitter can send the alarm signal to registered receiver immediately. ※Note1: The sensor transmitter have to register with receiver before use. - Page 18 Wireless Sensor Pad Classification Floor mode: When make a pressure to the sensor pad, the alarm will be activated immediate. Floor mode pad sensor includes as: Floor sensor mat Side-rail sensor pad Bed mode: The sensor pad is always under pressure. When the pressure is released from the sensor pad, the alarm will be activated.
- Page 19 Usage Floor Mode: Connect suitable AC adaptor and connect the sensor to min-plug. Put the sensor pad to suitable place. After making a pressure to sensor pad, the sensor transmitter will send the alarm signal out immediately. The alarm lamp of sensor transmitter will also blink once.
-
Page 20: Receiver
Receiver NC-9000RX(B) NC-9000RX Antenna Charging Lamp AC Adater Jack (NC-9000RX(B) only) Alarm Number Alarm Number Lamp 1 ~ 8 Lamp 9 ~ 16 Confirm Button Alarm Reset CONFIRM ALARM RESET Button Program Button Power Button PROGRAM POWER Program Lamp Power Lamp Reset Button (Case Bottom) NC-9000RX(B) had built-in the rechargeable battery... - Page 21 Checking Registered Number Press the confirm button till it makes a beep sound. The receiver will show all registered alarm number. It will sound beep and alarm lamps will off automatically after about 4 seconds. Add Transmitter Registration Press and hold program button till it makes a beep sound, program lamp bright and the registered alarm lamp that is smallest number blink.
- Page 22 Alarm Sound Setting Turn off the receiver. Press and hold confirm button then press power button so that the alarm number 1 blink. And it will show current volume level and current alarm sound. When press program button every time, the alarm number will be changed one by one, from lamp-1 to lamp-2 and so on.
- Page 23 Alarm Sound List Melody Buzzer For Elise Pi---------Pi Long Long Ago Pi Pi Pi Pi Vaise du Petit Chien PPi PPi Humoresque Pi-Pi Pi-Pi Chopin Nocturne Op9 #2 Pi-Pi- Pi-Pi- Pi-Pi- Lightly Row (Hanschen klein) Pi---ro Pi---ro Tanuki pup Piro Piro Piro Mary had a Little Lamb Piropiropiropiro Specification...
-
Page 24: Portable Receiver
Portable Receiver NC-9000PRX Holes for a neck strap / lanyard Power Top View Power Switch Antenna Charging lamp Charge Display Belt Clip Down Button Up Button AC Adaptor Stop Button Jack Speaker NC-9000PRX Front View Side View Register with Transmitter Press and hold the stop button, then turn on the power. - Page 25 Delete Registration Press and hold the stop button, then turn on the power. Don’t release the stop button till sound beep. Register The display will show “Register / Delete”. Press Delete the up / down button to select them. When the word Flash “D”...
- Page 26 Select Alert Type When standby state, press up and down button at same time. Hold press it till the portable receiver sound beep and display show three type icons and flash current icon. Select the desire alert type by up / down button. The display will flash selected icon and the type name, such as below: Flash Flash...
- Page 27 Transmitter Low Battery When the transmitter battery capacity is low, the portable receiver display will show the number of low power transmitter and appear the low battery icon, such as below: Low Battery Icon Call When the transmitter replaced new battery, the low battery demonstrate will get away, the display will turn to normally standby demonstrate.
- Page 28 Device Type List Transmitter Model No. Device Type Name Infrared Sensor NC-9000TXMS Infrared Magnet Sensor NC-9000TXMG Magnet Portable Call Button NC-9000TXPB Call Sensor Transmitter NC-9000TXBF Bed / Floor Sensor Transmitter NC-9000TXBF_ND Bed / Floor Wall Call Button NC-9000TXWB Call Specification Input : 100 ~ 240V 50/60Hz AC Adapter Power Source...
