- Page 1 User Manual AOM Series Fiber coupled AOM & RF Drivers AeroDIODE - Institut d’optique d’Aquitaine - Rue François Mitterrand 33400 Talence - France - Tél.: +33 (0)6 27 69 41 62 www.AeroDIODE.com...
-
Page 2: Table Of Contents
V1.2 11/06/2023 SER Third version – highlight the critical RF power level Disclaimer : Information in this document is subject to change without notice. Copyright © AeroDIODE Bât. IOA, rue François Mitterrand 33400 Talence – France www.AeroDIODE.com Page 1/12 – v3.3... -
Page 3: General Information
1. General information Please read this manual carefully. It describes the hazard the user might be exposed to while using the product. It also explains in details how to use the product in the safest and most efficient possible way. The safety of any system incorporating the product is the responsibility of the assembler of the system. -
Page 4: Safety Instructions
WARNING The maintenance and servicing of the AOM should NOT be executed by the end user : only AeroDIODE is able to maintain the AOM. 2. Safety Instructions 2.1. AOM Safety instruction... -
Page 5: Contact
2.3. Contact If you have any question about the AOM module, please contact AeroDIODE : www.aerodiode.com 3. Package Content The AOM modules comes with: • 1 AOM module with 900 µm fiber and 2* FC/APC fiber connectors. • A USB Key with the current user manual in pdf The Driver part comes with : •... -
Page 6: Aom Installation
5.1. AOM installation 1. Wear safety Googles 2. Wear a proper and working ESD wrist strap; Caution : Set the module on a heat dissipating surface (an optical table works fine). Letting the AOM in air with no dissipating surface leads to overheating and permanent damage. 4. - Page 7 screw) is normally set in a safe area allowing a correct diffraction efficiency. If ever it is adjusted, this must be done progressively from 0 V up to the maximum diffraction level. 7. Connect the trigger signal and make sure you apply the good electric signal : •...
-
Page 8: Specifications
Figure 2 : Model RFAOM-TA-200 S1-S4 settings RFAOM-TA-200 Configuration switch : • S1：Down : TTL high ; Up : TTL low input signal configuration setting • S2：Down : TTL mode active ; Up : TTL mode disabled • S3：Down : Analog input range : 0 -1V ; Up : Analog input range 0 - 5V. •... - Page 9 Pigtail termination FC/APC Customizable Working temperature °C Storage temperature °C Dimensions (without fiber 60*25*12.5 boots) Mounting holes diameter *: See our tutorial : fiber modulator Model 2, 4, 6 8 : High speed version – (ex : model 8 : 1030/1064 nm) Reference: 1064AOM-2 Technology/Crystal : TeO2* SPECIFICATIONS...
- Page 10 Extinction ration (1 order on/off) Rising time Frequency Frequency shift +/- 80 RF Power Input Impedance Ω Electrical input interface Fiber type PM1550 Customizable Fiber length Customizable Pigtail termination FC/APC Customizable Working temperature °C Storage temperature °C Dimensions (without fiber 60*25*12.5 boots) Mounting holes diameter...
- Page 11 6.2. RF Drivers : Model 1 : Standard version for digital (TTL) Input trigger ; 3 RF models : 80, 100 or 200 MHz Reference: RFAOM - T – 80, 100 or 200 (MHz) SPECIFICATIONS Unit Typ. Maximum Comments Output Frequency 80 or 100 or 200 MHz Choose your version Adjustable with a...
- Page 12 Output Frequency 80 or 100 or 200 MHz Choose your version Adjustable with a Output power screwdriver Impedance matching Extinction ratio >30 dB Synchro Input Analog (0-5V) Synchro input interface RF to AOM interface Working voltage Dimensions 81*58.5*15 Interhole distances / 75*52.5 / 4 Hole diameters Page 11/12 –...
- Page 13 Model 3 : Special version ; for AOMs with 200 MHz RF signal only • Adjustable RF power (multi-turner) • S1 : TTL high / TTL low input • S2 : TTL mode active/inactive • S3 : Analog input range : 0-1V / 0-5V ...
