Sony Handycam DCR-SR82 System Manual

With a 60GB built-in Hard Disk Drive, the DCR-SR82 lets you capture up to 40 hours of stunning video (LP) with
NEW
the 1 Megapixel CCD. With a 2.7" Wide Touch Panel Hybrid LCD Monitor, you'll have total control over every
detail while the One Touch Disc Burn feature shares it all with the touch of a button.
1.0 Megapixel Advanced HAD™ CCD
Step-up
Imager; 1070K Gross
1/6" Advanced HAD™ (Hole Accumulation
Diode) CCD with 690K (effective) video pixels
provides stunning detail and clarity, for
exceptional video (up to 520 lines of
horizontal resolution) and still image
performance. Realize great looking digital
still images with 1,000k effective pixels.
25X Optical/2000X Digital Zoom
The optical zoom helps to bring the action
close up from far away. In addition, the
Digital Zoom interpolation means that
extreme digital zooming is clearer, with less
distortion than previous types of digital
zooms.
Professional Quality Carl Zeiss® Vario-
Tessar® Lens
Carl Zeiss lenses have an advanced optical
multi-layer coating for increased contrast.
This results in vivid image brilliance, true-to-
life color saturation and perfect renditions
of subtle tones.
Handycam® Station
Simply placing the camcorder on the
supplied Handycam Station provides quick
connections to a compatible TV for viewing
or a PC for editing and sharing, all while
charging the battery so your camcorder is
always ready to go.
2.7" Wide (16:9) Touch Panel
SwivelScreen™ LCD Display (123K Pixels)
The 2.7" Wide (16:9)LCD screen provides
excellent viewing clarity. The high
resolution 123K pixel LCD screen rotates up
to 270 degrees for multiple viewing angles
providing sharp, detailed images for
monitoring or playback, and the
widescreen format makes shooting in 16:9
mode and composing shots even easier.
Memory Stick Duo™ Media Slot
Capture still images up to 1152x864
resolution directly onto Memory Stick Duo
media for easy transfer to PCs for emailing,
printing or sharing with other compatible
Memory Stick® media devices.
One Touch Wide Angle Shooting
Easily switch between 16:9 and 4:3 aspect
ratios for shooting, with just the touch of a
button.
Progressive Shutter System
A mechanical shutter system that provides
progressive scan performance while
utilizing an interlaced scanning system.
Digital still images will be sharp and clear
with excellent definition.
Super SteadyShot® Picture Stabilization
System
An advanced version of Sony's SteadyShot®
system that controls an even higher range
of shake and vibration frequencies, to
achieve an even higher level of smoothness
without degradation of video like some
other image stabilization systems.
USB 2.0 Interface
USB 2.0 interface provides an easy way to
connect your Hard Disk Handycam
Camcorder to the computer for fast
transfer of video and still images to your
computer for editing. The camcorder can
also be used as an external storage device,
convenient for archiving, storing and
trasporting your videos and still images.
DVDirect® Compatibility
The DVDirect system allows for easy
transfer to a stand-alone DVD Burner via
USB 2.0. The VRD-VC30 allows for easy
4 transfer of video for DVD Burning. While the
VRD-MC3 allows for seamless transfer of
both Video and Still images for archiving on
a DVD.
Easy PC Backup
Easily back up your footage to your PC
using the supplied software. The footage
will be stored on your PC's hard drive for
archiving purposes and viewing at a later
6
time; the footage is stored by date allowing
for quick access. In addition, only new
footage is transferred to your PC each time
you Backup your footage.
Hard Disk Drive Camcorder - 60GB
One Touch Disc Burn
Easily burn a DVD copy of your footage
using the supplied software. Simply connect
you DCR-SR82 to your PC via the Handycam
Station and supplied USB cable and press
the One Touch Disc Burn button.
HDD Smart Protection
A unique Shock Absorber protects the Hard
Disk Drive from physical damage if the unit
is dropped. When the 3G Sensor detects a
drop (loss of gravity) the power to the Hard
Disk Drive is turned off in order to prevent
damage, during this time the DCR-SR82
remains powered on and recording video to
the built-in buffer. Once the unit has
recovered from the drop the buffer is then
recorded to the Hard Disk Drive.
ADDITIONAL FEATURES
3
Active Interface Shoe
Super NightShot® Plus Infrared System
Manual Focus
On Screen Zoom and Record Buttons
Scene Selection Modes
Picture Effects
Fader Effects
InfoLithium® Battery with AccuPower™
Meter System
Battery Information
Easy Handycam Button
Tele Macro Function
Multi-Language Menu
DCR-SR82
5
3
