PACKING LIST
NAME
NO.
QUANTITY
Main body
1
User instructions
2
3
Bracket assembly
Expanding screw
4
5
Expanding plug
6
Screw ST4*10
7
Plastic Exhaust Pipe
8
Hood
9
Alum. filter
10
Cable ties
11
Drill hole stenci
12
Charcoal Filter
1
1
1
6
6
2
1
2
3
1
1
2
COOKER HOOD
COOKER HOOD
INSTRUCTION
INSTRUCTION
Carefully read this cooker hood user instructions before using
Read and save these instructions
CH90LIN
Advertisement
Table of Contents
Related Manuals for euro air CH90LIN
Summary of Contents for euro air CH90LIN
- Page 1 Main body User instructions Bracket assembly Expanding screw Expanding plug Screw ST4*10 Plastic Exhaust Pipe Hood Alum. filter Cable ties Drill hole stenci Charcoal Filter CH90LIN Carefully read this cooker hood user instructions before using Read and save these instructions...
-
Page 2: Table Of Contents
PREFACE CONTENTS Preface Preface Congratulations on the purchase of our Cooker hood, which is designed to include many superior features that permit you the fullest expression of your living. Please read the attached documents careful b efore installing and/or using the Contents cooker hood , which include important installation, usage, and safety direction. -
Page 3: Information And Advice
KNOW YOUR COOK HOOD INFORMATION AND ADVICE Information and advice Please do not leave the kitchen at will when you cook using animal tallow or vegetable oil, so as to avoid damaging the cooker hood because of All packing materials are environmental protections and therefore recyclable. -
Page 4: Using Method
USING METHOD INSTALLATION Installation position and height Please install the cooker hood at the dry place without direct sunlight. There should be enough intensity and smooth and straight surface about the metope which is used for fixing the cooker hood. Thus it can make the cooker hood stable, without any shaking. -
Page 5: Fixing The Cooker Hood
INSTALLATION INSTALLATION Fixing the cooker hood Ensure the power has been turned off before beginning this installation. Φ8 To install this hood you will require two assistants. You will need the following tools and material to complete this installation: *Drill*Flat head screwdriver*Phillips head screwdriver or cordless drill and Phillips head bit*Tin snips*3/8″nut driver or ratchet with extension *measuring tape*hand saw or jig saw*electrical tape*duct tape 1. -
Page 6: Exhaust Pipe Conjunction
INSTALLATION INSTALLATION Exhaust pipe conjunction Installation of chimney To better discharge fume in the According to the kitchen: dimension of the Please select appropriate exhaust chimney fixed bolster, pipe according to damper diameter make sure the position size. of the chimney. Please connect one end of the exhaust pipe with the cooker hood and tied with cable ties, and the... -
Page 7: Troubleshooting
TROUBLESHOOTING MAINTENANCE C lean the metal filter Troubleshooting ·It is recommendable to clean the metal filter every 2-3 weeks by Before you assume the worst, check this simple fault-finding guide to get to the root of the problem: carrying out the following instructions: -Remove the metal filter from the cooker hood and wash it in a Light bulb doesn't A replacement is probably necessary, but check first...
