- Page 1 User Manual BG -S- 10 5 & BG -SC - 3 00 www.esslsecurity.com...
- Page 2 1. Descriptions 1.1 Descriptions of Panel Open/Increase Value Close/Decrease Value Stop/Set Save 1.2 Technical Specifications AC 220V 50/60Hz 1.3 Definitions of Buttons Yellow Blue Open/Increase Value Stop/Set/Save Close/Decrease Value...
-
Page 3: Electrical Connections
2. Electrical connections Digital Display Tube Dip switch Remote controller learning Opened statu output Closed statu output Air wave switch Loop Detector FUSE 5A PT Indicator LOOP Indicator Photo cell PHOTO Indicator Stop switch Close switch Open switch AC220V INPUT MOTOR AC-L AC-N... -
Page 4: Main Features
3. Main Features 3.1 Digital positioning, high precision, easy setting. 3.2 Intelligent self-checking and self-protection. 3.3 Delay automatic closing function. 3.4 Safety protection function is available by the external sensors. 3.5 Remote control. 3.6 Counter mode. 4. Remote controller operation Learning transmitter code Press “LEARN”... - Page 5 5. Limits setting Note: For the controller initially installed, manually adjust barrier to middle position before power on. Power on Press and hold button more than 3 seconds, then press the button which on transmitter till “P--1” displays. Swap the motor wire L1 and L2 Y ** Press...
- Page 6 6. Limit fine-tune Settings Note: if you expect the boom to stop behind the original set position, please Y ** press button; if you expect the boom to stop before the original set position, please B *** press button. Power on Press and hold button more than 3 seconds, then press the button which on...
- Page 7 7. Delay automatically close setting Function description: The boom will automatically close after a set time when the barrier open fully. Note1: The factory default value is “0”, means that the function is cancelled. Note2: The maximum delay value is 99 seconds. Power on Press and hold button more than 3...
- Page 8 8. Counter mode setting Function description: When there are multiple open signals, the boom will not close until the same amount of vehicles as the signal’s pass the loop. Power on Press and hold button more than 3 seconds, then press the button which on transmitter till “P--1”...
-
Page 9: Dip Switch Setting
9. Dip switch setting Lamp mode Please set as Please set as setting left figure if an alarm lamp right figure if a red/green is connect. lamp is connect. Selection of Please set as left Please set as left protection figure if the output figure if the output signal type... -
Page 10: Error Codes Table
10. Error Codes Table Code Meaning Solution Err1 Encoder signal is invalid Check the signal wires and connectors Err2 Barrier operation timeout Check the mechanical system 1. Check the mechanical system Err3 Motor Locked Rotor 2. Check motor wires connectors Remove the object that block the Err7 Photocell is triggered... - Page 11 #24,Shambavi Building, 23rd Main,Marenahalli, JP Nagar 2nd Phase, Bangalore - 560078 Phone: 91-8026090500 | Email : sales@esslsecurity.com www.esslsecurity.com...
