Dual Sensor
Water/Soap Dispenser
Installation Manual
750EFDMSDBK / 750EFDMSDC
To assure that the product
operates properly, please make
sure to follow all procedures
within this instruction manual.
Product Specs:
1. Operating Power: 6V / 2A
2. Operating Water Pressure: 10 to 100 PSI
3. Soap Dispensing Time: 0.5-2 seconds
(Factory setting is 2 seconds.)
4. Soap Reservoir Capacity: 1.5L
(Only use foaming soap)
5. Sensor Distance: 1¼-6 in.
(Factory setting is 4 in.)
6. Response Time: 0.2 seconds
7. Shut-Off Time: 1 seconds
8. Operating Temperature: 5-70°C / 41-158°F
rev. 08/23
Advertisement
Summary of Contents for WATERLOO 750EFDMSDBK
- Page 1 Dual Sensor Water/Soap Dispenser Installation Manual 750EFDMSDBK / 750EFDMSDC To assure that the product operates properly, please make sure to follow all procedures within this instruction manual. Product Specs: 1. Operating Power: 6V / 2A 2. Operating Water Pressure: 10 to 100 PSI 3.
- Page 2 Dual Sensor Water/Soap Dispenser Installation Manual Faucet Body Component List Control Module Component List 15. Dial Cover 23. Power Inlet for 16. Outlet for Water AC Adapter 17. Soap Outlet 24. Inlet for Soap 18. Sensor Connector (Black Tube) for Soap Dispenser 25.
-
Page 3: Installation Diagram
Dual Sensor Water/Soap Dispenser Installation Manual Soap Canister Component List Installation Diagram Please note that actual installation may differ based on actual application. Mixing Valve Hot Water & Cold Water Hose Floor 28. Soap Outlet to 31. Mount Holes Control Module 32. - Page 4 Dual Sensor Water/Soap Dispenser Installation Manual Installation Diagram Installation Diagram 1. Shut off water valve. 2. Thread the wires and hoses through your counter hole. Make sure spout body and base gasket are flat on the counter. 3. Tightly secure the spout body by using the fixation washer, gasket, nut and screw (7, 8, 9, 10).
- Page 5 Dual Sensor Water/Soap Dispenser Installation Manual Installation Diagram Installation Diagram 4. Secure the control module to the wall using the provided template. 5. Make sure the control module is tightly fastened. 6. Tightly connect mixing valve (34) to water (25) inlet of the control module. 7.
- Page 6 Dual Sensor Water/Soap Dispenser Installation Manual Installation Diagram 9. Connect tightly the head of sensor cable for soap (white) of the spout body (13) to the sensor connector for soap dispenser (18) of the control module. 10. Connect tightly the head of sensor cable for faucet (14) of the spout body to the sensor connector for faucet (19) of the control module.
- Page 7 Dual Sensor Water/Soap Dispenser Installation Manual Installation Diagram Soap canister mount installation. 12. Drill a screw hole in the wall by using “template for soap canister mount.” 13. Screw in the soap canister mount (29) and make sure it is tightly fastened and does not wobble. 14.
- Page 8 Dual Sensor Water/Soap Dispenser Installation Manual Installation Diagram 16. Place the soap canister on the soap canister mount (29). 17. Insert the fixation pin (30) into the fixation tab at the bottom of soap canister. 18. Connect AC adapter to the the power inlet (23) of the control module.
- Page 9 Dual Sensor Water/Soap Dispenser Installation Manual System Setup The system is a digital system. Do NOT attempt to 1. Remove the Dial Cover. tamper with the electronic components in risk of damaging the components. 2. Setting the Faucet Sensor Distance a.
- Page 10 Dual Sensor Water/Soap Dispenser Installation Manual Template for Soap Template for Control Module Canister Mount...
