Hasler HF90 Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

HF90 / HF80
Folder
Operator Guide
5/2010
Part# 8704731V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HF90 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hasler HF90

  • Page 1 HF90 / HF80 Folder Operator Guide 5/2010 Part# 8704731V...

  • Page 3: Table Of Contents

    HF80 CUSTOM FOLD SETUP HF90 CUSTOM FOLD SETUP OPERATOR SETTINGS 14 - 17 Language Standard Fold override Stacker Override ( HF90 only ) Test Sheet Setting Default Settings MULTI-SHEET FEEDING CROSS FOLDING HF80 STACKER WHEEL POSITIONING CHART THICK PAPER / HIGH SPEED MODE...

  • Page 5: Description

    Lower Fold Table The HF90 / HF80 Folder is designed to perform a wide variety of folds using a variety of paper weights. The fold tables are automatically adjusted for standard folds and custom folds. Documents that are 8 ½” x 11”/14” and 11” x 17” (A5, A4, A3, B4, B5 &...

  • Page 6: Unpacking & Setup

    Check package for shipping damage. If there is shipping damage, do not discard the box. Remove the machine and packed components from the box. The fold tables, telescoping stacker, Multi Sheet Feeder (standard feature HF90, option for HF80), power cord and cross-fold guide are wrapped separately in the box.
  • Page 7 Upper Fold Table Receptacle Location 4. Plug the fold table cables in to the receptacles on the side frame (Fig. 3a & 3b). Fig. 3a Plug in Receptacle Lower Fold Table Receptacle Location Fig. 3b Plug in Receptacle 5. Insert the telescoping extension tray into the end of the outfeed conveyor (Fig.

  • Page 8: Control Panel

    CONTROL PANEL No. NAME FUNCTION Standard Fold Button Select the desired pre-programmed fold. LED Interface Displays current settings and used for setup and programming. Start Button Press to start the folder. Stop Button Press to stop the folder. Clear/Reset Button Clears operation and returns to main screen.

  • Page 9: Operation

    HF80 ONLY: Move the stacker wheels to the proper position for the paper size (Fig. 6) (Refer to chart on page 8). Stacker wheels will automatically adjust on the HF90. Stacker Wheels Fig. 6 Set the self-centring paper side guides for the width of the paper and lock in position using thumbscrews.
  • Page 10 Select the type of fold desired by pressing the fold selection button (Fig 8). Fig. 8 Fold selection button 10. Press the “1x” button on the control panel to test and check the folds. Fine adjustments can be made with the adjustment knobs at the end of the tables (Fig 9).

  • Page 11: Interface Menu

    “ button to enter the selection Choose between “ManuBatch” or Set up to 35 custom folds on the “AutoBatch” - see pages 8 and 9 HF90 or up to 25 custom folds on the HF80 (page 10) Adjustable Operator Settings - see page 14...

  • Page 12: Batch Counting

    BATCH COUNTING Two options are available for batch counting: ManuBatch for standard batch counting, and AutoBatch for programmed batch counting. Select “BatchCounting” and press the “ ” button to enter batch counting modes. ManuBatch The “ManuBatch” or “manual batch” feature allows you to program the number of sheets you would like to process in a set.
  • Page 13 AutoBatch “AutoBatch” or “automatic batch” allows you to batch count with automated features. In the Autobatch mode you can program the number of sheets you would like to process in a set, the total number of sets and the delay between each set.

  • Page 14: Hf80 Custom Fold Setup

    HF80 CUSTOM FOLDS SETUP The HF80 has 25 custom fold settings that can be stored into memory for recurring jobs with fold settings that vary from the standard fold settings. To create or edit custom folds select “Custom Folds Setup” from the Program Menu screen and press the “...

  • Page 15: Hf90 Custom Fold Setup

    HF90 CUSTOM FOLDS SETUP The HF90 has 35 custom fold settings that can be stored into memory for recurring jobs with fold settings that vary from the standard fold settings. To create or edit custom folds select “Custom Folds Setup” from the Program Menu screen and press the “...
  • Page 16 HF90 CUSTOM FOLDS SETUP, cont. There are 10 stacker positions available. Select the one that best matches the size of the folded document. Press “ ” buttons to select the correct position # P0 - P9. Press the “ ” button to enter selection and advance to the test screen.
  • Page 17 Measuring Fold Lengths Use the examples below to help determine the fold lengths for custom fold settings. Example 1: “Z” Fold Measure the length of panel “A”, enter this number as the upper Panel A fold table measurement. Measure the length of panel “B”, enter this number as the lower fold table measurement.

  • Page 18: Operator Settings

    OPERATOR SETTINGS A number of operator settings can be adjusted to personalize the HF80 / HF90. The settings include Language, Stacker Override, Standard Fold Override, and Test Sheet Setting. This section will review each setting and how to adjust them.

  • Page 19: Standard Fold Override

    Standard Fold Override It may be necessary to adjust the factory set standard fold settings for a particular fold type and paper size. This can be done in the Standard Fold Override Mode. From the Operator Settings menu select “Standard Fold Override”...

  • Page 20: Stacker Override - Hf90 Only

    Stacker Override - HF90 only The HF90 automated stacker positions may need to be overrid- den to accommodate different types of paper in order to im- prove the outfeed stacking (see pg 19 for HF80 manual stacker wheel adjustments). The positions are preset at the factory and should only be changed if needed.

  • Page 21: Test Sheet Setting

    Test Sheet Setting The number of test sheets can be changed between 1, 2 or 3. From the Operator Settings Menu press the “ ” button to highlight Test Sheet Setting. Press the “ ” button to select. Press the “ ”...

  • Page 22: Multi-Sheet Feeding

    MULTI-SHEET FEEDING The multi-sheet feeder is designed to fold pre-collated stapled or unstapled sets of up to four 20 # (75gsm) sheets of paper. Adjust the side guides on the milti-sheet feeder for the proper paper size. Loosen the brass thumb screw, adjust the guides to fit the paper width and re-tighten the thumbscrew (Fig 11a).

  • Page 23: Cross Folding

    CROSS FOLDING Fold Crease Cross Fold Guide Cross folding refers to folding a document in one pass and then running it through the folder a second time to be folded again. Common Application: Folding a 11” x 17” document in half and then letter folding it to fit in a standard #10 envelope.

  • Page 24: Thick Paper / High Speed Mode

    THICK PAPER / HIGH SPEED MODE Thicker paper requires increased speed to fold. In order to fold thicker paper a “Thick Paper / High Speed Mode” can be accessed by pressing and holding the “+” symbol down for 5 seconds. This mode should only be used to fold heavier paper stock.

  • Page 25: Operator Maintenance

    OPERATOR MAINTENANCE 1. I t is recommended to let forms cool for one-half hour, from the laser printer, before folding. This allows toner to set on the forms and static electricity to discharge. A paper jogger is recommended for best results. The jogger squares the forms and dissipates heat and static electricity created by laser printers.

  • Page 26: Trouble Shooting

    TROUBLE-SHOOTING TROUBLE POSSIBLE CAUSE REMEDY Control panel lights are not No power at the wall outlet. Check wall outlet. illuminated. No power to the machine inlet. Check power cord for frayed/broken wires. Press the button on the circuit breaker. No power to the control panel. Call for service.
