SiT8925B
High Frequency, Automotive AEC-Q100 Oscillator
Features
AEC-Q100 with extended temperature range (-55°C to 125°C)
Frequencies between 115.2 MHz and 137 MHz accurate to
6 decimal points
100% pin-to-pin drop-in replacement to quartz-based XO
Excellent total frequency stability as low as ±20 ppm
Industry best G-sensitivity of 0.1 PPB/G
Low power consumption of 3.8 mA typical at 1.8V
LVCMOS/LVTTL compatible output
Industry-standard packages: 2.0 x 1.6, 2.5 x 2.0, 3.2 x 2.5,
5.0 x 3.2, 7.0 x 5.0 mm x mm
RoHS and REACH compliant, Pb-free, Halogen-free and
Antimony-free
Electrical Characteristics
Table 1. Electrical Characteristics
All Min and Max limits are specified over temperature and rated operating voltage with 15 pF output load unless otherwise
stated. Typical values are at 25°C and nominal supply voltage.
Parameter
Output Frequency Range
Frequency Stability
Operating Temperature
Range (ambient)
Supply Voltage
Current Consumption
Duty Cycle
Rise/Fall Time
Output High Voltage
Output Low Voltage
Input High Voltage
Input Low Voltage
Input Pull-up Impedance
Startup Time
Enable/Disable Time
Standby Current
Rev 1.6
Symbol
Min.
Typ.
Max.
f
115.20
Frequency Stability and Aging
F_stab
-20
-25
-30
-50
Operating Temperature Range
T_use
-40
-40
+105
-40
+125
-55
+125
Supply Voltage and Current Consumption
Vdd
1.62
1.8
1.98
2.25
3.63
Idd
6
4.9
LVCMOS Output Characteristics
DC
45
1.5
Tr, Tf
1.5
VOH
90%
VOL
10%
VIH
70%
VIL
30%
Z_in
100
Startup and Resume Timing
T_start
T_oe
I_std
2.6
1.4
0.6
Applications
Automotive, extreme temperature and other high-rel
electronics
Infotainment systems, collision detection devices, and
in-vehicle networking
Powertrain control
Unit
Frequency Range
137
MHz
Refer to
Tables 13 to 15
Inclusive of Initial tolerance at 25°C, 1
+20
ppm
variations over operating temperature, rated power supply voltage
+25
ppm
and load (15 pF ± 10%).
+30
ppm
+50
ppm
+85
°C
AEC-Q100 Grade 3
°C
AEC-Q100 Grade 2
°C
AEC-Q100 Grade 1
°C
Extended cold, AEC-Q100 Grade1
V
All voltages between 2.25V and 3.63V including 2.5V, 2.8V, 3.0V and 3.3V
are supported. Contact
V
8
mA
No load condition, f = 125 MHz, Vdd = 2.25V to 3.63V
6
mA
No load condition, f = 125 MHz, Vdd = 1.62V to 1.98V
55
%
3
ns
Vdd = 2.25V - 3.63V, 20% - 80%
2.5
ns
Vdd = 1.8V, 20% - 80%
Vdd
IOH = -4 mA (Vdd = 3.0V or 3.3V)
IOH = -3 mA (Vdd = 2.8V and Vdd = 2.5V)
IOH = -2 mA (Vdd = 1.8V)
Vdd
IOL = 4 mA (Vdd = 3.0V or 3.3V)
IOL = 3 mA (Vdd = 2.8V and Vdd = 2.5V)
IOL = 2 mA (Vdd = 1.8V)
Input Characteristics
Vdd
Pin 1, OE
Vdd
Pin 1, OE
k
Pin 1, OE logic high or logic low
5
ms
Measured from the time Vdd reaches its rated minimum value
130
ns
f = 115.20 MHz. For other frequencies, T_oe = 100 ns + 3 * cycles
A
Vdd = 2.8V to 3.3V,
A
Vdd = 2.5V,
= Low, Output is weakly pulled down
ST
A
Vdd = 1.8V,
= Low, Output is weakly pulled down
ST
July 18, 2018
Condition
for the exact list of supported frequencies
st
year aging at 25°C, and
SiTime
for 1.5V support
ST
= Low, Output is weakly pulled down
www.sitime.com
