Thank you for purchasing our furniture, it's an honor to be
in your home!
Every effort has been made to ensure your Wood Furniture is
of the finest quality. If you have any questions or need
any replacement parts, please do not hesitate to contact
us at www.grainwoodfurniture.com .
Model #
Size
M 0611
King
T
King
M 0612
T
King
MT0620
King
MT0624
REV - 05/28/2018
MONTAUK Collection
King Size Panel Bed
PH#2
PH#2
Finish
Rustic Walnut
Rustic Off-White
Rustic Grey
Driftwood
MADE IN BRAZIL
www.grainwoodfurniture.com
page 1/8
Advertisement
Table of Contents
Related Manuals for Grain MONTAUK MT0611
Summary of Contents for Grain MONTAUK MT0611
- Page 1 MONTAUK Collection Assembly Instructions King Size Panel Bed Thank you for purchasing our furniture, it’s an honor to be in your home! Every effort has been made to ensure your Wood Furniture is of the finest quality. If you have any questions or need any replacement parts, please do not hesitate to contact us at www.grainwoodfurniture.com .
- Page 2 Wood Furniture Care: - Clean with a cloth dampened with water or furniture polish following the pattern of the grain. - Do NOT use solvents such as alcohol for cleaning. - Avoid placing under direct sun light, to prevent UV damage.
- Page 3 Parts List BOX A 1 - Headboard Panel 1A - Left Headboard Post 1B- Right Headboard Post 2 - Footboard Panel 2A - Left Footboard Post 2B - Right Footboarad Post 6 - Cover strip BOX B 3 - Side Rails 4 - Slats 5 - Center Legs Hardware...
- Page 4 HARDWARE LIST items shown in actual size 12+1 Ø1/4 x 60MM (Metric) 01+1 Allen Key Ø3,5x16MM Ø4,5x35MM 04+1 Ø7 x 60MM (Soberbo) 08+1 Ø1/4" x 90MM (Metric) 08+1 Ø1/4" (Metric) Wood Cap Ø10 x 40MM MADE IN BRAZIL page 4/8 REV - 05/28/2018...
- Page 5 Step 1 B14+G13 B14+G13 B14+G13 B14+G13 B14+G13 B14+G13 B14+G13 B14+G13 Note: there are no pre-drilled holes for screws A38 on parts 1. Ø1/4 x 60MM (Metric) Allen Key Ø3,5x16MM MADE IN BRAZIL page 5/8 REV - 05/28/2018...
- Page 6 Ø1/4 x 60MM (Metric) Allen Key (x 4) Allen Key Ø7 x 60MM (Soberbo) MADE IN BRAZIL page 6/8 REV - 05/28/2018...
- Page 7 Allen Key Ø1/4" x 90MM (Metric) Ø1/4" (Metric) Ø10 x 40MM MADE IN BRAZIL page 7/8 REV - 05/28/2018...
- Page 8 Note: there are no pre-drilled holes for screws D on part 3. Ø4,5x35MM The wood caps should be flush with the post surface TIP: Use a Rubber Mallet or a piece of wood to protect the finish when hammering the wood cap Wood Cap MADE IN BRAZIL page 8/8...
