MEGWR TF-X1 Manual

Dog training collar
Hide thumbs

Advertisement

Table of Contents

MEGWR
DOG
Training Collar
MODEL:TF-X1
Retail price
$199.99
The product is designed to foster good habits in pets, not punish them.
Do not overuse this product on pets.
NOTE: PLEASE READ THE MANUAL CAREFULLY BEFORE USE AND SAVE FOR FUTURE REFERENCE!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TF-X1 and is the answer not in the manual?

Questions and answers

Summary of Contents for MEGWR TF-X1

  • Page 1 MEGWR Training Collar MODEL:TF-X1 Retail price $199.99 The product is designed to foster good habits in pets, not punish them. Do not overuse this product on pets. NOTE: PLEASE READ THE MANUAL CAREFULLY BEFORE USE AND SAVE FOR FUTURE REFERENCE!

  • Page 2: Safety Instructions

    MEGWR （EN) USER MANUAL >> >> SAFETY INSTRUCTIONS Safe use statement 1. Use of this product on aggressive dogs is prohibited. Aggressive dogs can cause serious injury or death to their owners or others. If you are not sure whether the product is suitable for your dog, consult a professional training Dog trainer.
  • Page 3 MEGWR （EN) USER MANUAL >> 7.Before playing with the dog, please remove the device to avoid triggering it by mistake. 8.The 1P67 standard indicates that the equipment can be placed in water up to one meter deep for half an hour, and the internal part of the product will not enter water, but also prevent dust.
  • Page 4 MEGWR （EN) USER MANUAL >> >> PARAMETER Receiver 300mAh/3.7V lithium battery DC5V/1A Battery Input voltage 30 Days(Trigger 20 times a day) 25in/62cm Standby time Collar length IP67 -10°C~+50°C Waterproof Grade Service temperature Net weight 2.3oz -20°C~+50°C Storage temperature Product size Wireless frequency 2.83*1.45*0.9inch...

  • Page 5: Receiver Introduction

    MEGWR （EN) USER MANUAL >> >> RECEIVER INTRODUCTION Power key Slip buckle Lock clasp Collar strap Lndicator light Status light Magnetic charging port E-shock contactor Test lamp Test contact >> Transmitter Introduction Setting key Channel key Color screen + key...

  • Page 6: User Operation

    MEGWR （EN) USER MANUAL >> >> User operation 1. Charge the product before using it When the transmitter is charging, the battery column icon flashes water. The charging time is 1.5-2 hours. Battery charge after full, battery column icon long bright.
  • Page 7 MEGWR （EN) USER MANUAL >> User operation >> 5.Channel setting Blue light flashes 5 times • When the channel switching function is enabled, press the key of the transmitter to switch between channel 1, Channel 2 and channel 3; When the receiver receives the channel switching instruction of the transmitter, the cyan light of the prompt lamp flashes 5 times.
  • Page 8 MEGWR （EN) USER MANUAL >> User operation >> 9.Dog Finder White light flash fast RGB breathing light ① In the standby state, press the transmitter button to turn on the receiver dog search function and press the indicator light for the first time，The white light blinks quickly, and the transmitter dog icon...
  • Page 9 MEGWR （EN) USER MANUAL >> >> User operation 11.Matching ① When the receiver is turned on, briefly press the key twice to enter the pairing state. At this time, the blue light flashes. Blue light flashing ② When the transmitter switches to the channel to be paired, only one receiver can be paired for each channel.
  • Page 10 MEGWR （EN) USER MANUAL >> User operation >> 12.Transmitter Factory Reset Within 15 seconds of restarting, press and hold the for 2 seconds, and the backlight flashes for 5 times to indicate that the factory is successfully restored 13.Low battery power...

  • Page 11: Setting Guide

    MEGWR （EN) USER MANUAL >> Setting Guide >> 14.Setup guide Choose the right gear according to the dog's temper and tolerance for shock. Start training at the lowest gear. For example, if the dog responds to the shock gear with ear twitching, tongue licking, neck tightening, etc., this is the right gear.

  • Page 12: Functional Testing

    MEGWR （EN) USER MANUAL >> Functional testing >> After assembly, functional testing is recommended. Follow these steps to test. Chirp for 1 s ① Short press the key of the transmitter to test the sound, and the receiver will beep for 1 second.

  • Page 13: Troubleshooting

    MEGWR （EN) USER MANUAL >> The wearing of receiver >> The neck circumference ranges from 8 "to 25". Before putting on the collar, adjust the buckle and slip buckle so that the collar is the right size. Make sure that the shock contact is firmly attached to your dog's neck.

  • Page 14: Terms Of Use And Limitation Of Liability

    MEGWR （EN) USER MANUAL >> Terms of Use & Limitation of Liability >> Terms of Use & Limitation of Liability 1.Terms of Use Your use of the product constitutes your acceptance of all the terms, conditions and statements contained in this Manual 2.
  • Page 15 MEGWR （EN) USER MANUAL >> Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communica-tions.
  • Page 16 MANUFACTURER: Quanzhou Purplebox Electronics Co.,LTD ADDRESS:Floor 3&4, No.41 Wan Rong Street, Wansheng Community, Wan’ an, Luojiang, Quanzhou, Fujian, China Email:support@megwr.com Website:www.megwr.com...
