Summary of Contents for Valley Sportsman 1A-FA004
- Page 1 Brand Logo Assembly Instructions & User’s Manual Aluminum Pier Cart MFG#:1A-FA004 Please keep this instruction manual for future reference Customer Service: 888-380-7953 (Made in China) Revision 1 – 10/17...
- Page 2 Brand Logo Instructions de montage et manuel d'utilisation Aluminum Pier Cart MFG#:1A-FA004 Veuillez conserver ce mode d'emploi pour référence ultérieure Customer Service: 888-380-7953 (Made in China) Revision 1 – 10/17...
- Page 3 Table of Contents Warnings………………………………………………………………..…2 Tools and Parts…………………………………………………………3-4 Assembly Instructions………………………………………………….5-6 Care and Maintenance……………………………………………...……7 Table of Contents Note: Before beginning assembly of product, make sure all parts are present. Compare parts with package content list and hardware contents. If any part is missing or damaged do not attempt to assemble the unit.
- Page 4 Table des matières Avertissements…………………………………………………………2 Outils et pièces…………………………………………………………3-4 Instructions de montage……………………………………………….5-6 Entretien et maintenance…………………………………………...…7 Table of Contents Note: Before beginning assembly of product, make sure all parts are present. Compare parts with package content list and hardware contents. If any part is missing or damaged do not attempt to assemble the unit.
-
Page 5: Warnings / Avertissements
Warnings / Avertissements BEFORE STANDING UP THE PIER CART, YOU MUST CHECK ALL HARDWARE TO BE SURE IT IS IN PLACE AND TIGHT. CHECK ALL BOLTS AND NUTS TO BE SURE THEY ARE FIRM AND TIGHT. AVANT DE METTRE EN PLACE LE CHARIOT PIER, VOUS DEVEZ VÉRIFIER TOUT LE MATÉRIEL POUR VOUS ASSURER QU'IL EST EN PLACE ET SERRE.VÉRIFIEZ TOUS LES BOULONS ET ÉCROUS POUR VOUS ASSURER QU'ILS SONT FERMES ET SERRES. - Page 6 Parts List / Liste des pieces Frame / Cadre Picture Wheel / Roue Tire Axle / Pneu Essieu Flat washer / Rondelle plate Cotter Pin / Goupille Handle / Gérer Pin w/ring / Broche avec anneau Support leg / Jambe de force Page 3 of 8...
- Page 7 Hardware List / Liste du matériel Cotter pin / goupille Flat Washer / Rondelle plate, 17mm Pin w/ring / Broche avec anneau, (Dia.*L) 5mmx43mm Page 4 of 8...
- Page 8 Assembly Instructions / Instructions de montage Step 1: Across the axles / Sur les essieux (part #C) Step 2: Mount the wheels (part #B) with the axles (part #C) by using flat washers (part #D). Montez les roues (pièce #B) avec les essieux (pièce #C) en utilisant des rondelles plates (pièce #D).
- Page 9 Assembly Instructions / Instructions de montage Step 3: Affix them by using the cotter pins (part #E). Fixez-les en utilisant les goupilles fendues (pièce #E). Step 4: Attach the handle (part #F) to the support leg (part #H) by using Pin w/ring (part #G) then fasten them. Fixez la poignée (pièce #F) au pied de support (pièce #H) à...
- Page 10 Care and Maintenance / Entretien et maintenance INSPECT BEACH PIER CART FOR ANY LOOSE PARTS OR HARWARE REGULARLY CHECK IF PIER CART IS TAKING WATER ON RAINY DAYS. SEAL GAP WITH SILICONE SEALANT IF NECESSARY STORE PIER CART INDOORSWHEN NOT IN USE CLEAN PIER CART REGULARLY TO AVOID CLOGGING AND DAMAGE TO THE CONTROL UNIT.
