WIRELESS WEATHER STATION
MODEL: WH1150
1. Inventory of contents...................................................................2
2. Feature......................................................................................2
3. Set up guide...............................................................................2
3.1 Battery install.........................................................................2
3.2 Mounting................................................................................3
4. LCD overview..............................................................................3
4.1 LCD overview......................................................................3
4.2 Weather forecasting..............................................................4
4.3 Weather tendency indicator....................................................4
4.4 Examples of changing weather icons......................................4
4.5 Storm warning indicator.........................................................4
5. Program modes...........................................................................4
5.1 Quick display mode..............................................................5
5.2 Setting mode.......................................................................5
5.2.1 Setting Calibrated Humidity ...................................................5
5.2.2 Setting Barometric Pressure ...................................................6
5.3 Alarm mode.........................................................................7
5.4 Min/Max mode.....................................................................8
6. Problems and interference with operation.........................................8
7. Specification............................................................. .....................9
This Operation Manual is part of this product and should be kept in a safe place for
future reference. It contains important notes on setup and operation.
INSTRUCTION MANUAL
- 1 -
Page
Advertisement
Table of Contents
Related Manuals for Misol WH1150
Summary of Contents for Misol WH1150
-
Page 1: Table Of Contents
WIRELESS WEATHER STATION INSTRUCTION MANUAL MODEL: WH1150 Page 1. Inventory of contents…………………………………………..……………..2 2. Feature…………………………………………………………………………..2 3. Set up guide…………………………………………………………………….2 3.1 Battery install……………………………………………………………….2 3.2 Mounting…………………………………………………………………..3 4. LCD overview…………………………………………………………………...3 4.1 LCD overview…………………………………………………………….3 4.2 Weather forecasting……………………………..………….…………..4 4.3 Weather tendency indicator…………………………………………..4 4.4 Examples of changing weather icons………………………………..4 4.5 Storm warning indicator……………………………………….………..4... -
Page 2: Inventory Of Contents
1. Inventory of contents Base station 2) One WH2 remote sensor with mounting bracket 3) Instruction manual 2. Feature 1) Wireless outdoor and indoor humidity (%RH) 2) Wireless outdoor and indoor temperature (° F or ° C) 3) Records min. and max. humidity 4) Records min. -
Page 3: Mounting
3.2 Mounting 1) Base station With one foldable legs at the back of the unit, the base station can be placed onto any flat surface or wall mounted at the desired location by the hanging holes also at the back of the unit. It is important to check that the radio signal can be received before permanently mounting any of the units 2) Remote sensor... -
Page 4: Weather Forecasting
12. Pressure with 24 hour history graph 24. Barometer air pressure 13. Day of week/ time zone signal indicator 25. Pressure display unit (inHg or hPa) 26. Pressure alarm on indicator 4.2 Weather forecasting Sunny Partly Cloudy Cloudy Rain The four weather icons Sunny, partly Cloudy, Cloudy and Rainy represent the weather forecasting. There are also two weather tendency indicators to show the air pressure tendency between the weather icons. -
Page 5: Quick Display Mode
SNOOZE/LIGHT key. And there are four program modes available: Quick Display Mode, Setting Mode, Alarm Mode and Min/Max Mode. The program mode can be exited at any time by either pressing the SNOOZE/LIGHT key, or waiting for the 10-second time-out to take effect. 5.1 Quick Display Mode - While in Normal Mode, press the SET key to enter the Quick Display Mode as follow: 1. -
Page 6: Setting Barometric Pressure
To calibrate indoor or outdoor temperature, in the Set Mode with indoor or outdoor temperature flashing, press the + key or MIN/MAX key to increase or decrease the temperature setting (in increments of 0.1 degC or 0.18 degF) to match the calibrated or known temperature source. 5.2.2 Setting Calibrated Humidity The display console allows you to calibrate both the indoor and outdoor humidity. -
Page 7: Alarm Mode
To change the relative pressure is flashing, press the + key or MIN/MAX key to increase or decrease the relative pressure setting to match the official reporting station. 5.3 Alarm Modes While in Normal Mode press the ALARM key to enter the High Alarm Mode Press the ALARM key again to enter Low Alarm mode Remark: after the initial pressing of ALARM key, the display will be refreshed to show current high, low alarm value. -
Page 8: Min/Max Mode
5.4 Min/Max Mode While in Normal Mode, press the MIN/MAX key to enter the maximum mode, MAX logo and the general Max record will be displayed. Press MIN/MAX key again to enter the minimum mode, MIN icon and minimum record will be displayed Press MIN/MAX key again to return the Normal Mode In the maximum reading Mode, press the + key to display the following maximum values together... -
Page 9: Specification
Poor contrast LCD or no reception or Change batteries low batteries in sensors or receiver Temperature, humidity, or air pressure Check/replace batteries. If multiple remote sensors are in use, check location with corresponding “boxed numbers”. Or move is incorrect. away from sources of heat/cold. Adjust relative air pressure to a value from a reliable source (TV radio, etc.).
