This manual covers the following models:
• TT-MAC-1625
• TT-MAC-2020
• TT-MAC-2025
• TT-MAC-1429
• TT-MAC-1729
• TT-MAC-2129
High performance media air cleaner. Air
cleaner cabinet is fully insulated.
Table of Contents:
by
• TT-MAC-2429
• TT-MAC-1422
• TT-MAC-1722
• TT-MAC-2122
• TT-MAC-2522
Page
2
3
4
5
6
INSTALLATION MANUAL
A trained, experienced technician
must install this product.
Carefully read these instructions. You
could damage this product or cause a
hazardous condition if you fail to follow
these instructions.
IMPORTANT
!
Carefully read these instructions.
You could damage this product
or cause a hazardous condition
if you fail to follow these
instructions.
Need Help?
For assistance with this product please
visit http://www.toptechparts.com or call
customer care at 1-866-239-4440 during
normal business hours.
218413-00 Rev. 1A 06/22
1
Advertisement
Table of Contents
Related Manuals for Toptech TechPure TT-MAC-1625
Summary of Contents for Toptech TechPure TT-MAC-1625
- Page 1 INSTALLATION MANUAL A trained, experienced technician must install this product. Carefully read these instructions. You could damage this product or cause a hazardous condition if you fail to follow these instructions. IMPORTANT Carefully read these instructions. This manual covers the following models: You could damage this product •...
- Page 2 FEATURES AND SPECIFICATIONS Features Easy to maintain, high efficiency media No electricity is consumed. designed to capture small, medium, and Quick and easy filter media replacement. large airborne particles. Fully insulated cabinet Applicable to forced warm air furnaces, heat pumps, electric heat, and cooling systems Positive seal gasket material included.
- Page 3 INSTALLATION Application TechPure MAC Tip The TechPure media air cleaner cabinet is designed Choose a mounting location that to capture a significant amount of airborne particles. is upstream of the furnace and/ The cabinets are sold with MERV 1 filter media. or evaporator coil.
- Page 4 INSTALLATION Installation (continued) 2. Fasten the media cabinet to the furnace Carefully create or use opening in the furnace or air handler to match the filter media cabinet opening. Place enclosed gasket material on the side of the air cleaner that joins up with furnace or air handler. You can attach the media cleaner cabinet directly to the furnace or air handler, or fit a starting collar in the furnace opening.
- Page 5 PRESSURE DROP DATA MERV 11 Pressure Drop Flow Rate Velocity Pressure Drop % of Rated Dust Fed Pressure Drop (CFM (FPM) (mm H2O) (“H2O) Airflow 0.00 0.000 0.00 0.181 0.70 0.028 21.50 0.221 1.65 0.065 73.30 0.386 1281 2.80 0.110 106.30 0.591 1708...
- Page 6 5. Blower compartment is cleaned and the original filter has been removed. 6. Use enclosed cleaning cloth to wipe down access door. Contact Info TopTech 2000 Parks Oaks Ave Orlando, FL 32808 Phone: 866-239-4440 Web: http://www.TopTechParts.com...
