Sima STV-58K User Manual

Sima Tripod Models STV-60K & 67K
3-way fluid panhead
(Move up or down for floor to ceiling movement,
adjust base for portrait to landscape positions and
pan left or right for 360 rotation)
o
Pan tension
(Turn knob to tighten or
lock pan movement)
Elevator lock
(Turn knob to lock
geared elevator)
Elevator crank
(Turn to raise or lower
geared elevator)
Carry handle
Quick release
(2 included)
(Pull spring-loaded lever
to load or release camera)
Base tilt adjustment
(Loosen knob, reset
base from 0 to 90
o o
tighten to hold position)
Bubble level
(Bubble in center
circle indicates
level stance)
Central friction
control
(Turn to tighten and
lock position)
Sima Tripod Model STV-58K
3-way panhead
(Move up or down for floor to ceiling movement,
adjust base for portrait to landscape positions and
pan left or right for 360
Pan tension
(Turn knob to tighten or
lock pan movement)
Elevator lock
,
(Twist ring to lock
geared elevator)
Elevator crank
(Turn to raise or lower
geared elevator)
rotation)
o
Quick release
(2 included)
(Pull spring-loaded lever
to load or release camera)
Base adjustment
(Loosen knob, reset
base from 0
tighten to hold
position)
Bubble level
(Bubble in center
circle indicates
level stance)
Central friction
control
(Turn to tighten and
lock position)
Carry handle
to 90 ,
o o
