Trouble Shooting
Problem
Possible Cause/Solution
No Indicator Lights
Confirm that the AC or cigarette
adapter is firmly connected at
both ends. Confirm that wall
Charge
outlet is working. Check fuse in
Power
car cord (un-screw tip of the
cigarette lighter adapter.
Power Light Only
•
•
Charge
•
Power
remove and remount battery. Clean
battery/charger contacts.
Power and Charge
A
Indicators both Blink
Battery larger than 6000 ma hrs.
Defective battery
Within 1 min. of Charge Start
Charge
Battery is overcharged.
Power
Defective battery
Hissing noise in
Normal operation due to
Charging Mode
advanced switching circuitry.
Technical Specs
Input:
12V DC
Standby Current:
30mA
Charge Current:
800mA @ constant current mode
Charge Termination:
Fixed voltage (4.2V for 3.6V
Size & Weight
No battery inserted
Battery is already fully charged.
Battery mounted incorrectly;
fter 8 hrs of Charge -
(For either condition, see
Charging Battery section on
other side.)
battery, 8.4V for 7.2V battery
5.25" x 2.75" 3.1 oz.
