Linkworld Electronic LK1100 Quick Installation Manual

LK1100 Wireless Keyboard & LM3150 Mouse Kit
Quick Installation Guide

Hardware Installation

1. Turn the mouse & keyboard upside down, then open their battery cover
2. Insert batteries, ensuring they are in the right type & direction.
3. Close their battery cover
4. Plug receiver into computer's port. The"Lock LED"light turns on.

ID Code Configuration

Your PC must be on to change the ID setting.
1. Press ID button on the side of the receiver once.
2. Press ID button on the bottom of the mouse once.
3. Press ID button on the bottom of the keyboard once.
This ID-recognition function helps to portect against interence from other RF
keyboard/mouse in the same environment. Remember to set the ID when you replace
the batteries or your keyboard/mouse kits do not work properly.

Important

1. Whenever you insert battries, always make sure both of them are new.
Alkaline batteries are recommended.
2. Use the mouse on a clean, flat, non-slippery surface in order to
ensure smooth and accurate cursor action.

Mouse power management:

1. Whenever you insert battries or push the ID reset key on mouse ,the power- on
mold always starts on. & the"Sensor LED"light turns on.
2. Whenever you are continually pushing the ID reset key on mouse over 5 seconds,
the power- off mold always starts on. & the"Sensor LED"light turns off.
Warning: There will be a risk of explosion if you use different types of batteries
at the same time (such as alkaline battery plus rechargeable battery)
ID RESET KEY
ID RESET KEY
ID RESET KEY
