www.railking.com
Tinplate No. 318E
Electric Locomotives
OPERATOR'S MANUAL
Traditional Version
Compatibility
This engine will operate on any traditional
42" diameter STD. Gauge track system,
including M.T.H. ' s traditional tubular
track. It is also compatible with most
standard AC transformers. (See page 7 for
a complete list of compatible transformers
and wiring instructions.)
PLEASE READ BEFORE USE AND SAVE
Advertisement
Table of Contents
Summary of Contents for MTH Tinplate Traditions 318E
- Page 1 www.railking.com Tinplate No. 318E Electric Locomotives OPERATOR’S MANUAL Traditional Version Compatibility This engine will operate on any traditional 42” diameter STD. Gauge track system, including M.T.H. ’ s traditional tubular track. It is also compatible with most standard AC transformers. (See page 7 for a complete list of compatible transformers and wiring instructions.) PLEASE READ BEFORE USE AND SAVE...
-
Page 2: Table Of Contents
Table of Contents Set Up Checklist....................3 Lubrication......................3 Basic Operation....................4 Activating Features....................4 Maintenance......................5 Lubricating and Greasing Instructions..............5 Cleaning The Wheels and Track................5 Headlight Replacement Instructions..............6 Transformer Compatibility and Wiring Chart............7 Service & Warranty Information................8 Limited One-Year Warranty................... -
Page 3: Set Up Checklist
Set Up Checklist Lubricate the locomotive Apply power to run as described in the Basic Operating Section of this manual Lubrication You should lubricate the engine to prevent it from squeaking. Use DO NOT DO NOT DO NOT light household oil and follow the lubrication points marked “L” OVER OIL OVER OIL OVER OIL... -
Page 4: Basic Operation
Basic Operation The Throttle knob controls how fast your train will travel. The locomotive is stopped, started and reversed by means of the reversing ‘E- Unit’ located inside the locomotive. The E-Unit is a three position sequence relay which cycles whenever current to the locomotive is interrupted. This can be done by operating the ‘direction’... -
Page 5: Maintenance
Maintenance Lubricating and Greasing Instructions The engine should be well oiled and greased in order to run properly. Regularly lubricate all axles and pickup rollers to prevent squeaking. Use light household oil, such as that found in M.T.H.'s maintenance kit. Do not over oil. Use only a drop or two on each pivot point. -
Page 6: Headlight Replacement Instructions
The headlights are easy to remove by unscrewing them from their housings. Replacement light bulbs are available directly from the M.T.H. Parts Department. (Order online: www.mth-railking.com, e-mail: parts@mth-railking.com, Fax: 410-423-0009, Phone: 410-381-2500, Mail: 7020 Columbia Gateway Drive, Columbia MD 21046-1532, ). -
Page 7: Transformer Compatibility And Wiring Chart
RECOMMENDED AC TRANSFORMERS Transformer Min/Max. Power Transformer Center Rail Outside Rail Model Voltage Rating Type MTH Z-500 Red Terminal Black Terminal 0-18v 50-Watt Electronic MTH Z-750 Red Terminal Black Terminal 0-21v 75-Watt Electronic MTH Z-1000... -
Page 8: Service & Warranty Information
M.T.H. Electric Trains. M.T.H. assumes no responsibility, financial or otherwise, for material left in their possession, or work done, by privately owned M.T.H. Authorized Service Centers. If you need assistance at any time email MTH Service at service@mth-railking.com, or call 410 381- 2580. Limited One-Year Warranty All M.T.H.
