MicroFogger 5 Pro Manual
Quick start guide
The following guide will show you how to setup your new MicroFogger 5 Pro for the first
time. Follow each step carefully - failure to do so will cause frustration!
Read ALL parts of this manual to ensure you use this device safely, and correctly
1. Locate the MicroFogger and place it on charge using the included cable. The
STATUS light will turn
charged.
2. Locate the fluid tank and remove the rubber fill port cap. Fill it using the bottle of fog
liquid, taking care not to over-fill. Replace the fill cap. Wait 15 minutes to allow the
atomizer to saturate. This wait period is only required when using a brand new coil.
3. Once the MicroFogger is sufficiently charged, unplug it. Although we recommend
fully charging, you may begin using it at any state of charge.
4. Remove the fluid tank caps (if installed) and screw the fluid tank onto the
MicroFogger, ensuring it is not over-tightened. Place the safety cover over the tank.
orange
to indicate charging and will turn off once fully
Fill port cap
Fluid tank
V1.1
Safety cap
Liquid fill port

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MicroFogger 5 Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for Vosentech MicroFogger 5 Pro

  • Page 1 MicroFogger 5 Pro Manual Quick start guide The following guide will show you how to setup your new MicroFogger 5 Pro for the first time. Follow each step carefully - failure to do so will cause frustration! Read ALL parts of this manual to ensure you use this device safely, and correctly 1.
  • Page 2 V1.1 5. Turn the MicroFogger on using the small switch on the bottom. The screen will come on and the STATUS light will turn green. Before use, keep in mind a few important rules: -Keep it mostly upright (vertical) during operation -Closely monitor the fog liquid level and refill below 1/4 full -Unscrew the fluid tank and turn the device off when not in use -Unscrew the fluid tank for charging...
  • Page 3 V1.1 On-board user interface Switch Slide to the right to turn device on, slide left to turn off Smoke button -Hold to begin smoke production, let go to stop -Press once to return to previous screen in menu Mode button -Press to change between smoke density / speed adjustment -Hold to enter the settings menu -In settings menu, press to cycle through settings...
  • Page 4 V1.1 The top section where the logo is will indicate the status while operating. The battery indicator shows the state of charge. The smoke created will become less dense as the level decreases The left bar shows airflow power (smoke speed). We recommended to keep it full unless specifically needed.
  • Page 5 V1.1 Ensure you have sufficient liquid when using auto-run modes! Continuous mode - selects a duration for which the MicroFogger will stay activated after the trigger is pressed. While running, continuous operation can be cancelled by pressing SMOKE. Usually limited to 10s but with TIME LIMIT off, this is extended to 60s Delay - Selects the duration for which the MicroFogger will wait until continuous mode is activated.

  • Page 6: Normal Operation

    V1.1 feature and can be dangerous if used improperly. We recommend keeping it ON at all times. Charge lock ON/OFF - Sets if the MicroFogger can be activated while charging. Keep this setting ON unless you are both charging and triggering simultaneously.
  • Page 7 V1.1 To charge, unscrew the fluid tank and connect to power with a USB-C cable. The device can be charged either ON or OFF. Charging in the ON position will give a detailed battery level readout but will take marginally longer to charge. Battery swaps Li-ion batteries can be very dangerous when handled improperly.

  • Page 8: Storage And Maintenance

    V1.1 4. Use fingers or a gripping tool to unscrew the heating coil, while it is held in the clear housing as shown 5. Remove and save metal nozzle from bottom of worn coil. Discard worn coil 6. Install saved nozzle into new heating coil, ensuring the wire marked in yellow is wedged between the rubber gasket and nozzle.

  • Page 9: Troubleshooting

    V1.1 To reassemble: 1. Ensure top cover (with screen) is in normal position 2. Screw fluid tank onto front bullhead, ensuring center pin is in place 3. Ensuring good alignment, gently push bulkhead and tank assembly in place 4. Unscrew fluid tank, and screw the 3 screws back into place If the MicroFogger gets oily from small droplets of fog liquid on the exterior, you can wipe it clean with a moist paper towel.
  • Page 10 Safety The MicroFogger 5 Pro is powered by a high-performance Lithium-ion battery. This type of battery presents a potential fire risk if handled improperly. The following safety guidelines aim to prevent any issues from arising:...
  • Page 11 -If the smoke starts smelling burnt, immediately cease operation and replace the heating coil with a new one. Vosentech LLC will not accept any responsibility for property damage or bodily harm caused by the improper use of the MicroFogger or any other of its products.

  • Page 12: Package Contents

    -Carry case with foam insert Additional features The MicroFogger 5 Pro supports several additional features that’ll make it easier for you to incorporate it into your own custom projects should you decide to do so. Please note that although these modifications are officially supported, you will void your MicroFogger’s warranty should you decide to proceed since there is a potential to...
  • Page 13 ON in order to allow the cable to work. External Power The MicroFogger 5 Pro can be configured to operate while charging so it is possible to power it off of a USB battery bank or any other other 5V power supply. If using a battery bank, you can connect it using the included micro USB cable.

  • Page 14: Support And Faqs

    V1.1 Support and FAQs Can the MicroFogger trigger smoke alarms? Yes, if enough smoke is produced then ionization and photoelectric smoke alarms will be activated. Traditional heat-activated smoke alarms and sprinklers won’t be affected Is it possible to change the smoke color? Sort of! With the MicroFogger 5, we have the ColorSmoke attachment available, that will light up the generated smoke in various colors.
  • Page 15 V1.1 Can I control the MicroFogger 5 Pro via a wired remote? Yes, the USB charging port also doubles as a signal input which allows you to trigger the MicroFogger using a switch, relay or microcontroller of your choice. You’ll need our control cable accessory to access this functionality.
